UM1724 Hardware layout and configuration
60
25 PC14
(3)
- 26 25 PB10 PB15 26
27 PC15 PA0 28 27 PB4 PB14 28
29 PF0 PA1 30 29 PB5 PB13 30
31 PF1 PA4 32 31 PB3 AGND 32
33 VBAT PB0 34 33 PA10 PC4 34
35 PC2
PC1 or
PB9
(4)
36 35 PA2 PF5 36
37 PC3
PC0 or
PB8
(4)
38 37 PA3 PF4 38
1. Default state of BOOT0 is 0. It can be set to 1 when a jumper is on pin5-7 of CN7.Two unused
jumpers are available on CN11 and CN12 (bottom side of the board).
2. U5V is 5 V power from ST-LINK/V2-1 USB connector and it rises before +5V.
3. PA13 and PA14 share with SWD signals connected to ST-LINK/V2-1, it is not recommend to
use them as IO pins if ST-LINK part is not cut.
4. Please refer to Table 9: Solder bridges for detail
Table 23. STMicroelectronics Morpho connector on NUCLEO-F070RB
CN7 odd pins CN7 even pins CN10 odd pins CN10 even pins
Pin No. Name Name Pin No. Pin No. Name Name Pin No.
1 PC10 PC11 2 1 PC9 PC8 2
3 PC12 PD2 4 3 PB8 PC6 4
5 VDD E5V 6 5 PB9 PC5 6
7BOOT0
(1)
GND 8 7 AVDD U5V
(2)
8
9--109GND-10
11 - IOREF 12 11 PA5 PA12 12
13 PA13
(3)
RESET 14 13 PA6 PA11 14
15 PA14
(3)
+3V3 16 15 PA7 PB12 16
17 PA15 +5V 18 17 PB6 PB11 18
19 GND GND 20 19 PC7 GND 20
21 PB7 GND 22 21 PA9 PB2 22
23 PC13 VIN 24 23 PA8 PB1 24
25 PC14 - 26 25 PB10 PB15 26
27 PC15 PA0 28 27 PB4 PB14 28
29 PF0 PA1 30 29 PB5 PB13 30
31 PF1 PA4 32 31 PB3 AGND 32
33 VDD PB0 34 33 PA10 PC4 34
Table 22. STMicroelectronics Morpho connector on NUCLEO-F030R8 (continued)
CN7 odd pins CN7 even pins CN10 odd pins CN10 even pins
Pin No. Name Name Pin No. Pin No. Name Name Pin No.
