Ordering information UM1724
2/61 DocID025833 Rev 9
1 Ordering information
Table 1 lists the order codes and the respective targeted MCU.
The meaning of NUCLEO-TXXXRY codification is as follows:
• TXXX describes the STM32 MCU product line
• R describes the pin count (R for 64 pins)
• Y describes the code size (8 for 64K, B for 128K, C for 256K, E for 512K, G for 1MB, Z
for 192K)
The order code is printed on a sticker placed at the top or bottom side of the board.
Table 1. Ordering information
Order code Targeted MCU
NUCLEO-F030R8 STM32F030R8T6
NUCLEO-F070RB STM32F070RBT6
NUCLEO-F072RB STM32F072RBT6
NUCLEO-F091RC STM32F091RCT6
NUCLEO-F103RB STM32F103RBT6
NUCLEO-F302R8 STM32F302R8T6
NUCLEO-F303RE STM32F303RET6
NUCLEO-F334R8 STM32F334R8T6
NUCLEO-F401RE STM32F401RET6
NUCLEO-F410RB STM32F410RBT6
NUCLEO-F411RE STM32F411RET6
NUCLEO-F446RE STM32F446RET6
NUCLEO-L053R8 STM32L053R8T6
NUCLEO-L073RZ STM32L073RZT6
NUCLEO-L152RE STM32L152RET6
NUCLEO-L476RG STM32L476RGT6
