9 Revision history
Table 31. Document revision history
Date Revision Changes
10-Feb-2014 1
Initial release.
13-Feb-2014 2
Updated Figure 1, Chapter 4 and Table 9.
11-Apr-2014 3
Extended the applicability to NUCLEO-F302R8. Updated Table 1:
Ordering information, Section 5.10: Arduino connectors and
Section 5.11: STMicroelectronics Morpho connector.
Updated Figure 1
10-June-2014 4
Updated the board figure: Figure 1.
Updated HSE and LSE configuration description: Section 5.6.1,
Section 4 and Section 5.6.2. Extended the applicability to
NUCLEO-F334R8, NUCLEO-F411RE and NUCLEO-L053R8.
20-June-2014 5
Updated the electrical schematics figures: Figure 25, Figure 26,
Figure 27 and Figure 28.
Refer to the AN2867 for oscillator design guide for STM32
microcontrollers in Section 5.6.1: OSC clock supply and
Section 5.6.2: OSC 32 kHz clock supply.
30-Sept-2014 6
Extended the applicability to NUCLEO-F091RC and NUCLEO-
F303RE;
Updated Table 1: Ordering information;
Updated Table 10: Arduino connectors on NUCLEO-F030R8,
NUCLEO-F070RB, NUCLEO-F072RB, NUCLEO-F091RC;
Updated Table 24: STMicroelectronics Morpho connector on
NUCLEO-F072RB, NUCLEO-F091RC, NUCLEO-F303RE,
NUCLEO-F334R8;
Updated Figure 4: Typical configuration;
Added Figure 11: NUCLEO-F091RC;
Added Figure 14: NUCLEO-F303RE;
Updated Section 5.6.2: OSC 32 kHz clock supply;
Updated Figure 25: Electrical schematics (1/4) ,Figure 26:
Electrical schematics (2/4);
