Optima SO218/318 OWNER'S MANUAL Manual No. 513571 Aug. 2001, Rev.
Need Parts or Service? We stock the parts you need. Our Technicians are factory trained and are certified in the Stoelting Technicare program. CALL Distributor: _________________________ Phone No.: _________________________ (fill in or affix label) Model No.: _______________________ Serial No.
OWNER'S MANUAL FOR MODEL SO218/318 STOELTING FLOOR MODEL FREEZER This manual provides basic information about the freezer. Instructions and suggestions are given covering its operation and care. The illustrations and specifications are not binding in detail. We reserve the right to make changes to the freezer without notice, and without incurring any obligation to modify or provide new parts for freezers built prior to date of change.
TABLE OF CONTENTS SECTION DESCRIPTION PAGE 1. INTRODUCTION 1.1 Remote Possibilities .......................................................................................... 1.2 Features ............................................................................................................ 1.3 Dispenser Specifications ................................................................................... 1 1 2 2. INSTALLATION INSTRUCTIONS 2.1 Safety Precautions .......................................
LIST OF ILLUSTRATIONS FIGURE TITLE PAGE 1 Model SO218/318 ............................................................................ 1 2 Dispenser Specifications .................................................................. 2 3 Leveling Unit ..................................................................................... 3 4 Controls ............................................................................................ 5 5 Disassembling Freezer .................................
SECTION 1 INTRODUCTION 1.1 REMOTE POSSIBILITIES The Stoelting Optima delivers frozen drink profits by the pitcher. The Model SO218/318 is a high-volume producer of ready-to-serve frozen cocktails or frozen neutral base for those special drink recipes. From an extra-small space, the Optima’s compact design and high capacity output will give you extra-large profits. Figure 1. Model SO218/318 1.
1.3 DISPENSER SPECIFICATIONS Figure 2. Dispenser Specifications Electrical Refrigeration Crated Dimensions Dimensions 208/230/60/1 20amp circuit & plug 12 running amps 1/2 HP Drive Motor HFC-404A environmentallyfriendly refrigerant 2 HP (14,800 BTUH) highefficiency compressor Air or water cooled. Width: 22" (55.9cm) Depth: 30" (76.2cm) Height: 66" (167.7cm) Weight: 400lbs.(182kg) Width: 17.6"(44.7cm) Depth: 26.1"(66cm) Height: 61.2"(155cm) w/casters Weight: 350lbs.
SECTION 2 INSTALLATION INSTRUCTIONS 2.1 SAFETY PRECAUTIONS Do not attempt to operate the freezer until the safety precautions and operating instructions in this manual are read completely and are thoroughly understood. If danger, warning or caution labels are needed, indicate the part number, type of label, location of label, and quantity required along with your address and mail to: Take notice of all warning labels on the freezer.
E. Connect the power cord. The plug is designed for 208/ 230 volt/20 amp duty. The unit must be connected to a properly grounded receptacle. The electrical cord furnished as part of the freezer has a three prong grounding type plug. The use of an extension cord is not recommended. If one must be used, use one with a size 12 gauge or heavier with a ground wire. Do not use an adaptor to get around grounding requirements. CAUTION DO NOT ALTER OR DEFORM PLUG IN ANY WAY! F.
SECTION 3 INITIAL SETUP AND OPERATION C. Mix Low Light The Mix Low light will illuminate when you are low on mix. 3.1 OPERATOR'S SAFETY PRECAUTIONS SAFE OPERATION IS NO ACCIDENT; Observe these rules: A. Know the freezer. Read and understand the Operating Instructions. CAUTION DO NOT OPERATE FREEZER WHEN THE LOW MIX LIGHT IS ILLUMINATED OR DAMAGE TO THE FREEZER COULD RESULT. B. Notice all warning labels on the freezer. C. Wear proper clothing.
SOFT RUBBER SURFACE HARD CARBON SURFACE Figure 7. Rear Seal Assembly 3.4 CLEANING THE FREEZER PARTS Place all loose parts in a pan or container and take to the wash sink for cleaning. To clean freezer parts refer to the following steps: Figure 5. Disassembling Freezer E. Remove the spigot body from the front door bypulling the retaining pin out of the spigot handle. Push the spigot body thru the bottom of the front door. A. Place all parts in warm mild detergent water and clean with brushes provided.
NOTE The United Sates Department of Agriculture and the Food and Drug Administration require that lubricants used on food processing equipment be certified for this use. Use lubricants only in accordance with the manufacturer’s instructions. K. Install hopper cover. L. Connect mix hose to hopper cover (Model SO318 only). 3.7 SANITIZING Sanitizing must be done after the freezer is clean and just before filling with mix. Sanitizing the night before is not effective.
3.8 CLEANING & SANITIZING OF S0318 WITH FILL-O-MATIC II AND FILL-O-MATIC III 3.9 INITIAL FREEZE DOWN AND OPERATION This section covers the recommended operating procedures to be followed for the safe operation of the freezer. A. Empty freezer & mix container of product. A. Sanitize just prior to use. B. Mix 4 gallons of warm detergent water and pour into mix container, brush mix container, pick up hose and draw tube. Pump detergent water into freezer hopper. B.
3.11 SO218/318 OPERATION INFORMATION FOR SERVICE PERSONNEL The SO218/318 is a cocktail/slush freezer. It is available in 208-230 volt, either air-cooled or water-cooled. The air-cooled version has front-to-back airflow requiring three inches of air space in the front and back for proper refrigeration. This unit is not supplied with a pump, however, Stoelting does offer the Fill-O-Matic II (electric) and Fill-O-Matic III (gas) pumps FOR THE SO318.
10
SECTION 4 PREVENTIVE MAINTENANCE 4.1 ROUTINE CLEANING To remove spilled or dried mix from the freezer exterior, simply wash in the direction of the finish with warm soapy water and wipe dry. Do not use highly abrasive materials as they will mar the finish. 2. If the condenser is dirty, using compressed air or CO2 tank, blow out the dirt from the fan side of the condenser. 3. An alternative method of cleaning the condenser is to use a condenser brush and vacuum. 4.
12
SECTION 5 REPLACEMENT PARTS INFORMATION NOTE Minimum billing is $50.00. 5.1 ORDERING PARTS To assure receipt of the proper replacement parts, supply your dealer or distributor with the following information: D. WIRING DIAGRAMS reflect changes in effect with the Serial Number which are also indicated by a suffix. A. MODEL NUMBER of equipment. 5.2 REFERENCE DRAWINGS The following pages contain reference drawings and parts lists that will aid the user when operating the freezer. B.
14
SECTION 6 ACCESSORIES Fill-O-Matic II The Fill-O-Matic II is a self contained auto-fill system designed to be used with the Model SO318 and DQSO318 Freezer. The pump is built onto the cover of a 10 gallon mix vat. A draw tube extends to the bottom of the container to supply the pump with mix, the mix then passes thru a screen, thru the pump and discharges thru a hose to the freezer. The pump is controlled by a pressure switch. The pump starts at 45 PSI and stops at 60 PSI. Cleaning 1.
On/Off Switch È Ç 115 Volt 15 Amp Plug Figure 10.
Fill-O-Matic III The Fill-O-Matic III is a gas powered auto-fill system designed to be used with Slush and Cocktail Freezers. The pump is built to hang on the side of a 10 gallon mix vat. The pump can be driven by either regulated CO2, nitrogen or filtered compressed air. A draw tube extends to the bottom of the container to supply the pump with mix, the mix then passes thru the pump and discharges thru a hose to the freezer.
Ë Mix Outlet Gas Ë Outlet Ë Gas Inlet É Figure 11.
Gas Powered 7 = To Freezer Electric 6 From Auto Fill Note: Tubing Sold Separately 19
WARRANTY MIX TRANSFER PUMPS / COCKTAIL / SLUSH 1.
