OPERATION AND PARTS MANUAL PLASTER / MORTAR MIXER MS15H5.5 (Steel-Gasoline) MS15E (Steel-Electric) Effective S/N SED53 FINAL REVISION Revision #2 (08/10/06) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
Engine exhaust and some of its constituents, and some dust created by power sanding, sawing, grinding, drilling and other construction activities contains chemicals known to the State of California to cause cancer, birth defects and other reproductive harm. Some examples of these chemicals are: Lead from lead-based paints. Crystalline silica from bricks. Cement and other masonry products. Arsenic and chromium from chemically treated lumber.
HERE'S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND WHEN CALLING STOW MAIN OFFICE Post Office Box 6254 Carson, Ca 90749 Email: stow@multiquip.com Internet: www.stowmfg.com PARTS DEPARTMENT 800-427-1244 310-537-3700 SERVICE DEPARTMENT 800-421-1244 310-537-3700 TECHNICAL ASSISTANCE 800-478-1244 WARRANTY DEPARTMENT 800-421-1244, EXT. 279 310-537-3700, EXT.
TABLE OF CONTENTS MS15H/MS15E Plaster/ Mortar Mixer Here's How To Get Help ........................................... 3 Table Of Contents .................................................... 4 Parts Ordering Procedures ...................................... 5 Specifications ........................................................... 6 Dimensions .............................................................. 7 Safety Messages Alert Symbols ........................... 8-9 Rules For Safe Operation ...........
MS15H/MS15E MIXER — PARTS ORDERING PROCEDURES When ordering parts, please supply the following information: ❒ ❒ ❒ ❒ ❒ ❒ ❒ Dealer account number Dealer name and address Shipping address (if different than billing address) Return fax number Applicable model number Quantity, part number and description of each part Specify preferred method of shipment: ✓ FedEx or UPS Ground Note: Unless otherwise indicated by customer, all ✓ FedEx or UPS Second Day or Third Day orders are treated as “Standard Orders”, and wil
MS15H/MS15E MIXER — SPECIFICATIONS Table 1. MS15H/MS15E Mixer Specifications Capacity 4.0 cu. ft (113 liters) Bag Capacity 1-1/2 to 2-1/2 bags Weight MS15H 380 lbs. (172 kg.) Weight MS15E 348 lbs. (158 kg.) Length w/Tow Bar x W x H 67 x 30 x 41 in. (170 x 76 x 104 cm.) Height W/Dump Handle 47 in. (119 cm.) Discharge Height 7.5 in. (19 cm.) Drive V-Belt/Gear Dump Action Manual Table 2.
MS15H/MS15E MIXER — DIMENSIONS TABLE 3. DIMENSIONS Description Dimensions in. (cm) A 67 in. (170 cm) B 50 in. (127 cm) C 56 in. (142 cm) C 56 in. (142 cm) Figure 1. Dimensions MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — SAFETY MESSAGE ALERT SYMBOLS FOR YOUR SAFETY AND THE SAFETY OF OTHERS! Safety precautions should be followed at all times when operating this equipment. Failure to read and understand the Safety Messages and Operating Instructions could result in injury to yourself and others.
MS15H/MS15E MIXER — SAFETY MESSAGE ALERT SYMBOLS CAUTION Rotating Parts Hazards NEVER operate equipment with covers, or guards removed. Keep fingers, hands, hair and clothing away from all moving parts to prevent injury. CAUTION CAUTION Equipment Damage Hazards Other important messages are provided throughout this manual to help prevent damage to your light tower, other property, or the surrounding environment.
MS15H/MS15E MIXER — RULES FOR SAFE OPERATION DANGER Read this manual! Failure to follow instructions in this manual may lead to serious injury or even death! This equipment is to be operated by trained and qualified personnel only! This equipment is for industrial use only. The following safety guidelines should always be used when operating the STOW MS-40 mortar and plaster mixer: GENERAL SAFETY ■ DO NOT operate or service this equipment before reading this entire manual.
MS15H/MS15E MIXER — RULES FOR SAFE OPERATION ■ ALWAYS stop the engine before servicing, adding fuel ■ Depending on type of mixer, test the ON/OFF switch for either the gasoline engine or electric motor before and oil. operating. The purpose of these switches is to shut down ■ NEVER run engine without air filter. Severe engine may the engine or motor of the mixer occur. ■ ALWAYS service air cleaner frequently to prevent ■ ALWAYS stand clear of the release drum lock. Move handle downward to empty the drum.
MS15H/MS15E MIXER — RULES FOR SAFE OPERATION MAINTENANCE ■ NEVER lubricate components or attempt service on a running mixer. ■ ALWAYS allow the mixer a proper amount of time to cool before servicing. ■ Keep the mixer in proper running condition. ■ Fix damage to the mixer immediately and always replace broken parts. ■ Dispose of hazardous waste properly. Examples of potentially hazardous waste are used motor oil, fuel and fuel filters. ■ DO NOT use food or plastic containers to dispose of hazardous waste.
MS15H/MS15E MIXER — OPERATION AND SAFETY DECALS Machine Safety Decals This STOW mixer is equipped with a number of safety decals (Figure 2). These decals are provided for operator safety and maintenance information. The illustration below shows these decals as they appear on the mixer. Should any of these decals become unreadable, replacements can be obtained from your dealer. Figure 2. Safety Decals MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — GENERAL INFORMATION GENERAL GASOLINE ENGINE CARE The MQ STOW Model MS15H5.5 (Honda GX160K1HX2 gasoline engines) and MS15E (electric motor) plaster and mortar mixers are shipped completely assembled and have been factory tested. For care and operation of the gasoline engine, refer to the engine manufacturer’s operating instructions furnished with the engine. We recommend draining and refilling the engine crankcase at least every thirty hours of operation.
MS15H/MS15E MIXER — MIXER COMPONENTS Figure 3. Mixer Components Figure 3 illustrates the basic components and controls of the MS15H/MS15E mixer. 1. Engine Cover — Lift this cover to gain access to the engine compartment. 2. ON/OFF Switch (electric) — This switch is provided on mixers with electric motors. To gain access to this switch, lift the engine cover. When activated it will shut down the electric motor. 3.
MS15H/MS15E MIXER — BASIC ENGINE COMPONENTS Honda GX Series Engine Shown Figure 4. Engine Controls and Components INITIAL SERVICING 5. The engine (Figure 4) must be checked for proper lubrication and filled with fuel prior to operation. Refer to the manufacturers Engine manual for instructions & details of operation and servicing. Fuel Valve Lever – OPEN to let fuel flow, CLOSE to stop the flow of fuel. 6. Choke Lever – Used in the starting of a cold engine, or in cold weather conditions.
MS15H/MS15E MIXER — ELECTRIC MOTOR Electric Motor DO NOT operate electric motor in a explosive environment. Electric Motor Voltage Switch 1. ALWAYS make certain the motor switch is "OFF" and the power cord has been disconnected from the power source. 2. Remove the voltage lock-out bolt (Figure 2). Change the position of the voltage change toggle switch from 115 VAC to 230 VAC. The mixer is factory wired for 115 VAC operation. 3. Replace the voltage lock-out bolt. 4.
MS15H/MS15E MIXER — ELECTRIC MOTOR Figure 5. Single Phase Electric Motor with 18 inch Pigtail Cable PAGE 18 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — PADDLE BLADE ADJUSTMENT Adjust paddles as shown in Figure 6. Figure 6. Paddle Blade Adjustment, Steel Drum MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — INSPECTION Before Starting 1. Read all safety instructions at the beginning of manual. 2. Clean the mixer, removing dirt and dust, particularly the engine cooling air inlet, carburetor and air cleaner. 2. Remove the filler dipstick from the engine oil filler hole (Figure 7) and wipe it clean. 3. Check the air filter for dirt and dust. If air filter is dirty, replace air filter with a new one as required. 4. Check carburetor for external dirt and dust. Clean with dry compressed air. 5.
MS15H/MS15E MIXER — INSPECTION Fuel Check Explosive Fuel Hazard If your mixer has a gasoline engine, determine if the engine fuel is low. If fuel is low, remove the fuel filler cap and fill with unleaded gasoline. Motor fuels are highly flammable and can be dangerous if mishandled. DO NOT smoke while refueling. DO NOT attempt to refuel the mixer if the engine is hot! or running. DANGER V-belt Check A worn or damaged V-belt can adversely affect the performance of the mixer.
MS15H/MS15E MIXER — START-UP PROCEDURES This section is intended to assist the operator with the initial start-up of the MS-15H (gasoline) or MS15E (electric) mixer. It is extremely important that this section be read carefully before attempting to use the mixer in the field. 2. To start a cold engine, move the choke lever (Figure 10) to the CLOSED position. DO NOT use your mixer until this section is thoroughly understood.
MS15H/MS15E MIXER — START-UP PROCEDURES 4. Turn the engine switch (Figure 12) to the ON position. NOTE Be sure to stand clear of the dump handle when the mixer is operational. Any binding of material between the mixer blades and the drum will cause the drum handle to move to the discharge position, thus causing bodily harm. Stopping the Mixer (Electric Motor) 1. Place the engine ON/OFF switch (Figure 14) in the OFF position. Figure 12. Engine ON/OFF Switch (ON) 7.
MS15H/MS15E MIXER — MAINTENANCE (ENGINE) Use Table 8 as a general maintenance guideline when servicing your engine. For more detail engine maintenance information, refer to the engine owner's manual supplied with your engine. Table 8. Engine Maintenance Schedule DESCRIPTION (3) OPERATION BEFORE CHECK X FIRST EVERY MONTH 3 MONTHS OR OR 10 HRS. 25 HRS. EVERY 6 MONTHS OR 50 HRS. EVERY YEAR OR 100 HRS. EVERY 2 YEARS OR 200 HRS.
MS15H/MS15E MIXER — MAINTENANCE (MIXER) Drum Head Seals There is 1 set of drum head seals (Figure 15) that will require lubrication. IMPORTANT- DRUM HEAD CAUTION SEAL CARE Grease seals every 40 hours of operation using any grade #1 lithium base grease. Apply grease until visible of mixing tub (over grease). This will purge seal system of contamination.
MS15H/MS15E MIXER — MAINTENANCE (MIXER) MAIN GEAR AND DRIVE PINION ALIGNMENT 1. 2. 3. Disconnect the spark plug wire (gasoline engines). If mixer is equipped with an electric motor remove power cord from AC power receptacle. In addition make sure the clutch engagement lever is dis-engaged to relieve Vbelt tension. The countershaft and drive pinion are mounted on a slotted base.
MS15H/MS15E MIXER — TROUBLESHOOTING (ENGINE) Practically all breakdowns can be prevented by proper handling and maintenance inspections, but in the event of a breakdown, please take a remedial action following the diagnosis based on the Engine, Mixer and Electric Motor Troubleshooting (Tables 6, 7 and 8) information shown below and on the proceeding pages. If the problem cannot be remedied, please leave the unit just as it is and consult or company's service department. TABLE 6.
MS15H/MS15E MIXER — TROUBLESHOOTING (ENGINE) TABLE 6. ENGINE TROUBLESHOOTING (CONTINUED) SYMPTOM Insufficient power output "compression" and overheats Burns to much fuel Exhaust color is continiously "WHITE" Exhaust color is continiously "BLACK" POSSIBLE PROBLEM SOLUTION Malfunction in cooling fan? Check or replace cooling fan. Air in-take filter clogged? Clean or replace air in-take filter. Over accumulation of exhaust products? Clean and check valves. Check muffler, replace if necessary.
MS15H/MS15E MIXER — TROUBLESHOOTING (MIXER/MOTOR) TABLE 7. MIXER TROUBLESHOOTING SYMPTOM POSSIBLE PROBLEM SOLUTION Worn or defective V-belt? Replace V-belt. No power? Check electric or gasoline engine. Worn or defective paddle shaft seals? Replace seals. Defective or worn drum suppor t brackets? Apply grease to bracket or replace. Blades adjusted too tight? Adjust blades until they almost touch side walls of drum. Blades will not rotate. Material leaking from drum ends.
MS15H/MS15E MIXER — WIRING DIAGRAM (ELECTRIC MOTOR) Figure 23. Electric Motor Wiring Diagram PAGE 30 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
NOTE PAGE MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
EXPLANATION OF CODE IN REMARKS COLUMN How to read the marks and remarks used in this parts book. Section 1: Items Found In the “Remarks” Column Serial Numbers-Where indicated, this indicates a serial number range (inclusive) where a particular part is used. Model Number-Where indicated, this shows that the corresponding part is utilized only with this specific model number or model number variant.
MS15H/MS15E MIXER — SUGGESTED SPARE PARTS MS15H/MS15E MIXER 1 TO 3 UNITS WITH HONDA GX160K1HX2 ENGINE Qty. P/N Description 2 ............ 491010 ............ RUBBER LATCH ASSY. 1 ............ 508473 ............ V-BELT, ELECTRIC MOTOR A37 1 ............ 80000-008 ...... WIPER KIT 3 ............ 9807956846 .... SPARK PLUG HONDA 5.5HP 3 ............ 17210ZE1505 . ELEMENT, AIR HONDA 5.5 HP 1 ............ 28462ZH8003 . ROPE, RECOIL STARTER, HONDA 5.
MS15H/MS15E MIXER — NAMEPLATE AND DECALS NAMEPLATE AND DECALS. PAGE 34 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — NAMEPLATE AND DECALS NAMEPLATE AND DECALS. NO PART NO PART NAME QTY. REMARKS 1 504713 DECAL: WARNING READ 1 * DECAL: STOW (MULTIQUIP) SMALL 3 2 * 510165 3 512527 DECAL: STOW (MULTIQUIP) BIG 1 * DCL160A WARNING ENGINE SHUTOFF 2 5 * 25259-001 DECAL: 6 DECAL: WARNING GRATE 1 * 7 DECAL: NAMEPLATE ............................... 1 ............ CONTACT MQ PARTS DEPT. 8 DECAL: POWDER COATED 1 * 13118 DCL160 DECAL:PROP. 65 WARNING 1 9 * SEE DECAL ILLUSTRATIONS ON PAGE 13.
MS15H/MS15E MIXER — STEEL TUB ASSY. STEEL TUB ASSY. PAGE 36 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — STEEL TUB ASSY STEEL TUB ASSY. NO PART NO 26084-352 2 * 3 26085-351 12 23180-001 18 * 19728-001 19+ * 19722-001 20 33177-001 * 21+ * 33044-001 22 25492-001 24 33048-001 * 33084-001 25 26 33084-002 27 * 18937-001 37 * 07745-001 39 17985-008 * 40 17985-010 42 07029-006 * 07033-006 43 * 07030-008 46 48 07030-006 50 07028-055 56 06501-008 * 07594-012 62 * 19721-001 63 * 25648-501 26083-502 PART NAME QTY.
MS15H/MS15E MIXER — PADDLE SHAFT ASSY. PADDLE SHAFT ASSY. PAGE 38 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — PADDLE SHAFT ASSY. PADDLE SHAFT ASSY. NO. PART NO. 1 29062-351 2 492584 3 530181C 4 492400 5 EM200292 6 530180C 7 504322 8 EM200297 9 530179C 10 505196 11 3019092 12 514725 * 514726 13 14 1456 15 0166A 16 530182C 17 530201 18 * 33017-001 19 80000-008 PART NAME QTY.
MS15H/MS15E MIXER — FRAME ASSY. FRAME ASSY. PAGE 40 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — FRAME ASSY. FRAME ASSY. NO PART NO 1 EM98195 2 530467 3 530226 4 492381 5 EM969013 6 530168 7 530166 8 501299 9 491002 10 490957 11 492356 12 504451 13 2101402 14 492561 15 513699 PART NAME GRIP, RUBBER BLACK HANDLE, FRONT-LEFT HANDLE, FRONT-RIGHT SCREW, 3/8 NC 2-1/2 G5 NUT, NYLOCK FRAME HANDLE BACK WASHER, FLAT WHEEL , TIRE ASSY. SNAP RING 5100-100 BOLT, 1/4" X 3/4" WASHER, FLAT 1/4" WASHER, LOCK 1/4" NUT, HEX HEAD 1/4"-20 BUSHING QTY.
MS15H/MS15E MIXER — ENGINE COVER ASSY. ENGINE COVER ASSY. PAGE 42 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — ENGINE COVER ASSY. ENGINE COVER ASSY. NO PART NO 1 07028-057 2 18604-005 3 26922-351 4 491010 PART NAME COTTER PIN 5/32 x 1/2 RETAINER CHAIN ENGINE HOUSE ASSY. LATCH ASSY. QTY. 2 1 1 1 REMARKS MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — HONDA ENGINE ASSY. HONDA ENGINE ASSY. PAGE 44 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — HONDA ENGINE ASSY. HONDA ENGINE ASSY. NO PART NO 1 GX160K1HX2 2 10057-016 3 18941-004 4 07030-005 5 07029-005 6 07033-005 7 06499-006 8 33054-001 9 06500-012 10 26921-001 PART NAME QTY. REMARKS ENGINE-5.5 H.P. HONDA .................. 1 ............
MS15H/MS15E MIXER — ELECTRIC MOTOR ASSY. ELECTRIC MOTOR ASSY. PAGE 46 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
MS15H/MS15E MIXER — ELECTRIC MOTOR ASSY. ELECTRIC MOTOR ASSY. NO PART NO PART NAME QTY. 20 33060-001 PILLOW BLOCK 2 21 17985-010 CARRIAGE BOLT 3/8-16 x 1-1/4 4 30 33054-001 DRIVE PINION GEAR 1 32 07030-005 FLAT WASHER 5/16 4 33 07029-005 LOCK WASHER 5/16 4 34 07033-005 HEX NUT 5/16-18 4 49 07029-004 LOCKWASHER 1/4 6 51 07033-004 NUT, HEX 1/4-20 6 71 26044-001 BRACKET 1 82 22743-002 MOTOR & CONTROL ASSY. 1.
HONDA GX160K1HX2 ENGINE — CYLINDER HEAD ASSY. CYLINDER HEAD ASSY. HONDA ENGINE — CYLINDER HEAD PAGE 48 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — CYLINDER HEAD ASSY. CYLINDER HEAD ASSY. NO 1 2 * 3 * 4 5 6 7 8 9 10 11 12 14 15 PART NO 12210ZH8000 12204ZE1306 12205ZE1315 12216ZE5300 12251ZF1800 12310ZE1010 12391ZE1000 15721ZH8000 90016ZE1000 90043ZE1020 90047ZE1000 9430110160 957230806000 9807956846 9807956855 PART NAME QTY. REMARKS CYLINDER HEAD, COMP ......................... 1 .......... INCLUDES ITEMS W/ * GUIDE, IN. VALVE (OVER SIZE) 1 GUIDE, EX.
HONDA GX160K1HX2 ENGINE — CYLINDER BARREL ASSY. CYLINDER BARREL ASSY. PAGE 50 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — CYLINDER BARREL ASSY. CYLINDER BARREL ASSY. NO 1 2 3 4 * 5 # * 7 # * 8 * 9 10 11 * 12 13 * 14% 15% 16 17 18 * 19 20 PART NO 06165ZE1000 12000ZH8811 15510ZE1023 16510ZE1000 16511ZE1000 16513ZE1000 16531ZE1000 16541ZE1000 90131ZE1000 90451ZE1000 90601ZE1000 90602ZE1000 91001ZF1003 91202883005 91353671003 9405010000 9410106800 9425108000 957010601200 PART NAME QTY. REMARKS GOVERNOR KIT .................................................. 1 ......... INCLUDES ITEMS W/ * CYLINDER ASSY.
HONDA GX160K1HX2 ENGINE — CRANKCASE COVER ASSY. CRANKCASE COVER ASSY. PAGE 52 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — CRANKCASE COVER ASSY. CRANKCASE COVER ASSY. NO 1 3 4 5 9# 10% 11 * 12 13 14 * PART NO 11300ZE1633 11381ZH8801 15600ZE1003 15600ZG4003 15625ZE1003 15625ZE1003 91202883005 9430108140 957010803200 961006205010 PART NAME QTY. REMARKS COVER ASSY, CRANKCASE (W TYPE) ... 1 .........INCLUDES ITEMS W/ * GASKET CASE COVER 1 CAP ASSY, OIL FILLER ............................ 1 .........INCLUDES ITEMS W/# CAP ASSY, OIL FILLER ............................ 1 .........
HONDA GX160K1HX2 ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. PAGE 54 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. NO. 5 PART NO. 13310ZE1621 PART NAME CRANKSHAFT (H- TYPE) QTY. 1 REMARKS MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — PISTON ASSY. PISTON ASSY. PAGE 56 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — PISTON ASSY. PISTON ASSY. NO 1 1 1 1 2 2 2 2 3 4 5 * 6 PART NO 13010ZF1023 13011ZF1023 13012ZF1023 13013ZF1023 13101ZH8000 13102ZH8000 13103ZH8000 13104ZH8000 13111ZE1000 132A0ZE1000 90001ZE1000 90551ZE1000 PART NAME QTY. REMARKS RING SET, PISTON (STD) 1 RING SET, PISTON (0.25) 1 RING SET, PISTON (0.50) 1 RING SET, PISTON (0.75) 1 PISTON (STD) 1 PISTON (0.25) 1 PISTON (0.50) 1 PISTON (0.75) 1 PIN, PISTON 1 ROD ASSY, CONNECTING ....................... 1 .........
HONDA GX160K1HX2 ENGINE — CAMSHAFT ASSY. CAMSHAFT ASSY. PAGE 58 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — CAMSHAFT ASSY. CAMSHAFT ASSY. NO 1 2 3 4 5 6 * 7 8 9 10 11 12 13 14 15 PART NO 14100ZE1812 14410ZE1010 14431ZE1000 14441ZE1010 14451ZE1013 14568ZE1000 14711ZF1000 14721ZF1000 14751ZF1000 14771ZE1000 14773ZE1000 14781ZE1000 14791ZE1010 90012ZE0010 90206ZE1000 PART NAME QTY. REMARKS CAMSHAFT ASSY. ................................... 1 ......... INCLUDES ITEMS W/ * ROD, PUSH 2 ARM, VALVE ROCKER 2 LIFTER, VALVE 2 PIVOT, ROCKER ARM 2 SPRING, WEIGHT RETURN 1 VALVE, IN. 1 VALVE, EX.
HONDA GX160K1HX2 ENGINE — RECOIL STARTER ASSY. RECOIL STARTER ASSY. PAGE 60 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — RECOIL STARTER ASSY. RECOIL STARTER ASSY. NO 1 2 * 3 * 4 * 5 * 6 * 7 * 8 * 9 * 10 * 11 * 12 PART NO 28400ZH8013ZB 28410ZH8003ZB 28420ZH8013 28422ZH8013 28433ZH8003 28441ZH8003 28442ZH8003 28443ZH8003 28461ZH8003 28462ZH8003 90003ZH8003 957010600800 PART NAME QTY. REMARKS STARTER ASSY, RECOIL NH1(BLACK) ... 1 ......... INCLUDES ITEMS W/ * CASE COMP.
HONDA GX160K1HX2 ENGINE — FAN COVER ASSY. FAN COVER ASSY. PAGE 62 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — FAN COVER ASSY. FAN COVER ASSY. NO 2 4 7 8 10 11 14 PART NO 19610ZE1000ZC 19612ZH8810 90601ZH7013 19630ZH8000 32197ZH8003 36100ZE1015 90022888010 PART NAME COVER COMP., FAN NH1(BLACK) PLATE, SIDE (STD) CLIP, HARNESS SHROUD COMP. SUB-HARNESS SWITCH ASSY., ENGINE BOLT, FLANGE 6X20 QTY. 1 1 1 1 1 1 1 REMARKS MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — CARBURETOR ASSY. CARBURETOR ASSY. PAGE 64 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — CARBURETOR ASSY. CARBURETOR ASSY.
HONDA GX160K1HX2 ENGINE — AIR CLEANER ASSY. AIR CLEANER ASSY. PAGE 66 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — AIR CLEANER ASSY. AIR CLEANER ASSY. NO 1 2 3# 4 5# 6 * 7 * 8 9 11 12 13 PART NO 16271ZE1000 17210ZE1505 17218ZE1821 17230ZE1820 17232891000 17238ZE7010 17239ZE1000 17410ZE1020 90201415000 90325044000 90325044000 957010602000 PART NAME QTY. REMARKS GASKET ELBOW 1 AIR CLEANER ELEMENT DUAL ............ 1 ......... INCLUDES ITEMS W/# FILTER OUTER 1 COVER AIR CLEANER DUAL 1 GROMMET, AIR CLEANER 1 COLLAR, AIR CLEANER 1 COLLAR B, AIR CLEANER 1 ELBOW COMP. AIR CLEANER .............. 1 ..
HONDA GX160K1HX2 ENGINE — MUFFLER ASSY. MUFFLER ASSY. PAGE 68 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — MUFFLER ASSY. MUFFLER ASSY. NO 1 3 7 8 11 12 15 PART NO 18310ZH8810 18320ZF1H01 18355ZE1000 18381ZH8800 90050ZE1000 90055ZE1000 94001080000S PART NAME MUFFLER COMP. PROTECTOR, MUFFLER ARRESTER, SPARK GASKET, MUFFLER SCREW, TAPPING 5X8 SCREW, TAPPING 4X6 NUT, HEX (8MM) QTY. 1 1 1 1 4 1 REMARKS 2 MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — FUEL TANK ASSY. FUEL TANK ASSY. PAGE 70 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — FUEL TANK ASSY. FUEL TANK ASSY. NO 1 2 3 5 6# 11 12 13 14 15 PART NO 16854ZH8000 16955ZE1000 17510ZE1020ZF 17620ZH7013 17631ZH7003 91353671003 9405006000 950014500840M 9500202080 957010602500 PART NAME QTY. REMARKS RUBBER, SUPPORTER 1 JOINT, FUEL TANK 1 TANK COMP., FUEL NH1 (BLACK) 1 CAP COMP., FUEL FILLER ...................... 1 ......... INCLUDES ITEMS W/# GASKET, FUEL FILLER CAP 1 O-RING (14MM) ARAI 1 NUT, FLANGE (6MM) 2 BULK HOSE, FUEL (4.5X8000) (4.
HONDA GX160K1HX2 ENGINE — FLYWHEEL ASSY. FLYWHEEL ASSY. PAGE 72 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — FLYWHEEL ASSY. FLYWHEEL ASSY. NO 1 2 4 5 8 PART NO 13331357000 19511ZE1000 28451ZH8003 31100ZE1000 90201878003 PART NAME KEY, SPECIAL WOOD RUFF, 25X18 FAN, COOLING PULLEY STARTER FLYWHEEL COMP. NUT, SPECIAL, 14MM QTY. 1 1 1 1 1 REMARKS MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — IGNITION COIL ASSY. IGNITION COIL ASSY. PAGE 74 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — IGNITION COIL ASSY. IGNITION COIL ASSY. NO 1 2 7 11 PART NO 30500ZE1033 30700ZE1013 36101ZE1010 90121952000 PART NAME COIL ASSY., IGNITION CAP ASSY., NOISE SUPPRESSOR WIRE, STOP SWITCH (370MM) BOLT, FLANGE, 6X25 QTY. REMARKS 1 1 1 2 MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — CONTROL ASSY. CONTROL ASSY. PAGE 76 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — CONTROL ASSY. CONTROL ASSY. NO 2 4 5 6 7 8 * 9 * 10 * 11 * 12 * 13 * 14 * 15 * 17 18 19 * 22 * 23 * 24 PART NO 16500ZH8821 16551ZE0010 16555ZE1000 16561ZE1020 16562ZE1020 16571ZH8000 16574ZE1000 16575ZH8000 16576891000 16578ZE1000 16580ZH8811 16584883300 16592ZE1810 90013883000 90015ZE5010 90114SA0000 93500050250H 938930501600 9405006000 PART NAME QTY. REMARKS CONTROL ASSY., REMOTE ..................... 1 .........
HONDA GX160K1HX2 ENGINE — GEAR REDUCTION ASSY. GEAR REDUCTION ASSY. PAGE 78 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — GEAR REDUCTION ASSY. GEAR REDUCTION ASSY. NO. 1 2 3 4 5 6 7 8 9 10 11 12 13 PART NO. 21521883741 21591ZH8740 21621883741 21692ZH8800 23710883740 90002883740 90131883000 91202883005 9410912000 957010803208 957010803500 961006204000 961006305000 PART NAME CASE, REDUCTION GASKET, REDUCTION CASE COVER, REDUCTION GASKET, REDUCTION COVER SHAFT, P.T.O.
HONDA GX160K1HX2 ENGINE — LABEL ASSY. LABEL ASSY. PAGE 80 — MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
HONDA GX160K1HX2 ENGINE — LABEL ASSY. ENGINE LABELS ASSY. NO. 1 3 6 7 8 15 PART NO. 87521ZH8020 87522ZH9000 87528ZE1810 87530ZH8810 87532ZH8810 887586ZH7W00 PART NAME ENBLEM 5.5 LABEL, CAUTION MARK, CHOKE LABEL, SPECIFICATION (EXTERNAL) MARK, OIL ALERT (E) LABEL, FUEL CAUTION QTY. 1 1 1 1 1 1 REMARKS MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
Effective: July 15, 2003 TERMS AND CONDITIONS OF SALE — PARTS Terms and Conditions of Sale STOW Construction Equipment PAYMENT TERMS Terms of payment for unit sales are 2% 15 days net 30 days from date of invoice unless otherwise specifically stated on our invoice. Parts invoices have terms of net 10 days. Minimum parts billing is $15.00 net. Applicable discounts will be computed on merchandise value only. Late charges will be assessed at prevailing rates.
NOTE PAGE MQ STOW MS15H/MS15E MIXER — PARTS & OPERATION MANUAL — REV.
