17.9 Appendix I: Specifications
Model: CORE 2 Console
REF: REF 5400-052-000
Dimensions:
Width: 13.0 inch [330.2 mm]
Height: 5.4 inch [137.2 mm]
Depth: 17.4 inch [442.0 mm]
Weight: 17.3 lb [7.8 kg]
Equipment Type:
Class 1 Type BF Applied Part
Power Supply: Input voltage: 120 V 60 Hz, 6.0 A
100 V 50-60 Hz, 6.0 A
240 V 50-60 Hz, 3.0 A
Motor port output voltage: 40 V
Footswitch port output voltage: 5 V
Fuse Type, Rating, and
Breaking Capacity:
2 x 6.3 A, 250 VAC, 5 x 20 mm, (F) Fast-Acting, (L) Low Breaking Capacity 63 A at 250
VAC, IEC 60127
Enclosure (Ingress)
Protection:
IPX0
Ground Type:
Protective Earth (ground); when connected to facility power
Mode of Operation: Continuous operation with intermittent loading
Duty Cycle: See the duty cycle times defined in the Instructions For Use supplied with the motor and/or
accessories.
Product Safety Certification:
CSA International
Canadian Standards Association (CSA)
CAN/CSA-C22.2 No. 60601-1:14, Medical Electrical Equipment — Part 1: General
Requirements for Basic Safety and Essential Performance; (IEC 60601-1:2005+A1:2012, MOD)
American National Standards Institute (ANSI)/Association for the Advancement of
Medical Instrumentation (AAMI)
ANSI/AAMI ES60601-1:2005/(R) 2012, Medical Electrical Equipment — Part 1: General
Requirements for Basic Safety and Essential Performance; Consolidated Reprint (2009/(R)
2012); Amendment 2 (2010/(R) 2012); Amendment 1 (2012)
