Guidance and manufacturer's declaration - electromagnetic immunity
The CORE 2 Console is intended for use in the electromagnetic environment specified below. The customer or the user of the CORE 2 Console should
assure that the console is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment - guidance
Conducted RF
IEC 61000-4-6
3 Vrms 150 kHz to 80
MHz outside ISM bands
80% AM at 1 kHz
6 Vrms
150 kHz to 80 MHz in
ISM bands 80% AM at
1 kHz
3 Vrms 150 kHz to 80
MHz outside ISM bands
80% AM at 1 kHz
6 Vrms
150 kHz to 80 MHz in
ISM bands 80% AM at
1 kHz
IEC 60601-1-2 3rd Edition:
Portable and mobile RF communications equipment should be used
no closer to any part of the CORE 2 Console, including cables, than
the recommended separation distance calculated from the equation
applicable to the frequency of the transmitter.
Recommended separation distance
d = 1.17 √P 150 kHz to 80 MHz
d = 1.17 √P 80 MHz to 800 MHz
d = 2.33 √P 800 MHz to 2.7 GHz
IEC 60601-1-2 4th Edition:
WARNING: Portable RF communications equipment (including
peripherals such as antenna cables and external antennas)
should be used no closer than 30 cm (12 inches) to any part
of the CORE 2 Console including cables specified by the
manufacturer. Otherwise, degradation of the performance of
this equipment could result.
Where P is the maximum output power rating of the transmitter in
watts (W) according to the transmitter manufacturer and d is the
recommended separation distance in metres (m).
Field strengths from fixed RF transmitters, as determined by an
electromagnetic site survey
a
should be less than the compliance level
in each frequency range
b
.
Interference may occur in the vicinity of equipment marked with the
following symbol:
Radiated RF
IEC 61000-4-3
3 V/m 80 MHz to 2.7
GHz 80% AM at 1 kHz
3 V/m 80 MHz to 2.7
GHz 80% AM at 1 kHz
(Non-ionizing electromagnetic radiation)
NOTE 1: At 80 MHz and 800 MHz the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and
people.
a
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and
FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the CORE 2 Console is used
exceeds the applicable RF compliance level above, the CORE 2 Console should be observed to verify normal operation. If abnormal performance is
observed, additional measures may be necessary, such as re-orienting or relocating the CORE 2 Console.
b
Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
