5400-052-700-EN Rev-D EN

www.stryker.com 31

17.11 Appendix K: Compliance Statements

The CORE 2 Console creates and uses radio frequencies and may cause interference with other medical equipment. If

interference occurs, see the information contained within this appendix.

Federal Communications Commission (FCC) & Industry Canada (IC)

Contains RFID Module: 4 Channel RFID Module

FCC ID: Q9R-5400052020

IC: 4919A-5400052020

This device complies with FCC Part 15 and Industry Canada license exempt RSS standard(s). Operation is subject to the

following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,

including interference that may cause undesired operation of the device.

Changes or modifications not expressly approved by Stryker Instruments could void your authority to operate the equipment.

IEC 60601-1-2 3rd Edition: Recommended separation distances between

portable and mobile RF communications equipment and the CORE 2 Console

The CORE 2 Console is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of

the CORE 2 Console can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications

equipment (transmitters) and the CORE 2 Console as recommended below, according to the maximum output power of the communications equipment.

Rated maximum output power of

transmitter

Separation distance according to frequency of transmitter

150 kHz to 80 MHz

d=1.17√P

80 MHz to 800 MHz

d=1.17√P

800 MHz to 2.7 GHz

d=2.33√P

0.01 0.12 0.12 0.23

0.1 0.37 0.37 0.74

1 1. 2 1. 2 2.3

10 3.7 3.7 7.4

100 12 12 23

For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be estimated using the

equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the

transmitter manufacturer.

NOTE 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.

NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and

people.
