17 Appendices
17.1 Appendix A: Acronyms
ACRONYM DEFINITION
DIR Direction
EMC Electromagnetic Compatibility
ENT Ear, Nose, Throat
ES6 Electronic System 6
FWD Forward
I.D. Identification
IRR Irrigation
MRI Magnetic Resonance Imaging
OSC Oscillating
PPE Personal Protective Equipment
REV Reverse
RF Radio Frequency
RFID Radio Frequency Identification
RPM Rotations Per Minute
TPS Total Performance System
UHT Universal High Torque
UI User Interface
USB Universal Serial Bus
VAR Variable
17.2 Appendix B: Audio Output
TYPE DESCRIPTION
Button Press
A quick low pitched beep to denote
actuation of a button.
Volume Change
A quick low pitched beep to denote
volume of a button press.
Confirm
Slightly elongated chime to denote
completion of a task.
Motor Reverse
Two tone set of beeps to indicate
the motor is rotating in reverse
(counterclockwise).
Notice
Two tone ascending beep to indicate
a notification.
Error
High two tone descending beep to
indicate an error.
Prohibited
Low two tone descending beep to
denote prohibited actions.
17.3 Appendix C: Colors
17.3.1 User Interface Colors
COLOR DEFINITION
Selected/Active
Disabled/Inactive/Inaccessible
17.3.2 Power Button Illumination Colors
COLOR DEFINITION
Console On
Console Standby Mode
17.4 Appendix D: Equipotential
Bonding
Equipotential bonding involves the joining together of all
metalwork and conductive items that are in the same
potential (voltage) everywhere and is an important
countermeasure in reducing the risk of equipment
damage and personal injury. For additional information,
refer to IEC 60601-1 Clause 16.
