ITALIANO ENGLISH DEUTSCH MIDI PEDALBOARD MP-1 DATI TECNICI CONNESSIONI PROGRAMMAZIONE: POSIZIONE DELLE OTTAVE CANALE MIDI CAMBIO PRESET Pag. 14 " 14 " " " 15 15 15 FEATURES Page 38 CONNECTIONS " 38 TURN-ON DEFAULTS " 39 OPERATING INSTRUCTIONS BINARY LED DISPLAY " 39 OCTAVE ASSIGNMENT " 39 CHANNEL ASSIGNMENT " 40 PROGRAM ASSIGNMENT " 40 DIE TECHNISCHEN DATEN Pag. 60 ANSCHLÜSSE " 60 DIE PROGRAMMIERUNG: 1.0 OKTAVLAGE " 61 2.0 MIDI-KANAL " 61 3.
STUDIO 900 B envenuti nel mondo delle MASTERKEYBOARD FATAR. La MASTERKEYBOARD STUDIO 900 è un Midi controller molto semplice e versatile. Possiede un software non sofisticato, ma in grado di soddisfare le esigenze del tastierista che vuole lavorare in modo veloce e con controlli Midi sufficienti per un ottimo lavoro di musica live o di studio.
LISTA DEI MIDI CONTROL NUMBER: PROGRAM CHANNEL CONTROL Pitch A TRANSPOSE ISTRUZIONI PER ELABORAZIONI MIDI: A - Per trasmettere un Program Change, tenere premuto lo switch *PROGRAM* e digitare il numero desiderato con i tasti neri etichettati con i numeri da 0 a 9 (o usando i tasti *DEC* o *INC* per incrementare o decrementare di una unità). Il Program Change è assunto quando lo switch *PROGRAM* viene rilasciato.
STUDIO 90PLUS Param. Value Prog. 1 2 3 4 5 6 7 8 9 0 PLUS Enter RESET GENERALE Spegnere la tastiera. Tenere premuti i tasti "ENTER" e "1" della tastiera numerica. Sempre tenendo premuti i suddetti tasti, riaccendere la tastiera. Importante: una volta resettata la tastiera, tutti i programmi vengono cancellati ed entra in funzione un programma di default.
POSSIBILITA' DI PROGRAMMAZIONE DELLA STUDIO 90 Plus PARAMETRI E VALORI DELLA STUDIO 90 Plus DISPLAY PARAMETRO FUNZIONE VALORE 00 Split Sinistro 00-88 01 Split Destro 00-88 02 Transposer 1 00-11 03 Transposer 2 00-11 04 Transposer 3 00-11 Param. Value Prog.
Esempio: Nel programma N. 12 il punto di divisione sinistro si trova sul tasto 17 e il punto di divisione destro nel tasto 42. A Operazione SPLIT 1 PAR. 00 SPLIT 2 PAR. 01 CHANNEL MIDI 1 PAR. 08 CHANNEL MIDI 2 PAR. 09 CHANNEL MIDI 3 PAR. 10 TRANSPOSER 1 PAR. 02 TRANSPOSER 2 PAR. 03 TRANSPOSER 3 PAR. 04 OCTAVE 1 PAR. 05 OCTAVE 2 PAR. 06 OCTAVE 3 PAR. 07 B SPLIT 2 PAR. 01 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 Tasto PROG. 12 ENTER PARAM. 00 ENTER VALUE 17 ENTER PARAM.
OCTAVE 1, 2, 3 (Parametri 05, 06, 07) Con questo parametro si possono effettuare trasposizioni per ottave. E' possibile trasportare il suono fino a sette ottave sopra e sette sotto. PRESET 1, 2, 3 (Parametri 11, 12, 13) La scelta dei suoni dei vari expanders e strumenti collegati alla STUDIO 90 Plus, avviene attraverso questi parametri, che offrono una possibilità di scelta tra 100 suoni (00-99). Esempio: Nel programma N.
MIDI PEDALBOARD MP-1 POSSIBILITA' DI PROGRAMMAZIONE DELLA MIDI PEDALBOARD POSIZIONE DELLE OTTAVE Dopo l'attivazione del tasto "OTTAVA" premendo semplicemente uno dei tasti della pedaliera, si decide l'ottava da assegnare: CHANNEL MIDI OCTAVE PRESET MP 1 8 4 2 1 OCTAVE CH. MIDI - DO = Ottava più bassa - DO = Ottava sopra - RE = Ottava sopra - e così via fino ad arrivare all'ultimo - DO = Ottava più alta. PRESET CANALE MIDI Dopo l'attivazione del tasto "CH.
STUDIO 900 W elcome to the world of the Fatar Studio Series Keyboard Controllers. Congradulations on purchasing the ST-900, one of the finest master keyboard controllers in the world today. The action is a result of many years of design and engineering to bring the musician a keyboard mechanism that feels as close to an acoustic piano as possible.
To select a bank of prograrns, hold the [PROGRAM ]switch, press [BANK] key, and enter the appropriate bank number using the O through 9 keys. The bank command will be transmitted when the [PROGRAM] switch is released. The [INC]/ [DEC] keys may be used instead of entering the bank number. PROGRAM CONTROL Pitch Control # Commands: There are 127 controller functions that are rnade up of continuous and switch control commands. See Figure # 3.
CONTROLLER NUMBER 0 1 2 3 4 5 6 7 8 9 10 11 12- 15 16 17 18 19 20- 31 32 33- 63 64 65 66 67 68 69 70 - 7 80 81 82 83 84 - 91 92 93 94 95 96 97 98 - 121 122 123 124 125 126 127 CONTROLLER FUNCTION Bank Modulation Breath controller Undefined Foot controller Portamento rate Data Entry MSB Volume Balance Undefined Pan Expression Undefined Gen'l Purpose #l Gen'l Purpose #2 Gen'l Purpose #3 Gen'l Purpose #4 Undefined Bank Least significant byte for valuesO to 31 Sustain (damper) Portamento On/ Off Sostenuto Soft
STUDIO 90PLUS CONNECTIONS: Param. Value Prog. 1 2 3 4 5 6 7 8 9 0 PLUS Enter INPUT VDC LED POWER Thank you for purchasing the FATAR Studio-90 Plus, the finest feeling master controller on the market today. The action is a result of many years of engineering that went into the keyboard mechanism. There are actually hammers that strike a surface that simulates a piano string. The FATAR Studio-90 Plus master controller is very simple to operate once you understand its capabilities.
Look at figure #2 and #3. The functions are the same, but the location of the midi outs and foot switch controls are separated from the power section. You will find this configuration on the ST-90 Plus in the cabinet. MIDI OUT FOOT-SWITCH fig. #2 1 2 POWER 3 MIDI CONTROL PROGRAM CHANGE 9V DC 200mA ON fig. #3 OFF Note: If you want merging capabilities with the Studio-90 Plus, you must use a merge box. A good merge box we recommend is the Pocket Merge from Anatek Microcircuits, Inc.
can get the feel of moving through programs. (You will find that the ENTER button must be pressed every time you want a function to work properly regardless what you are attempting to do.) Another way to advance programs, is to use a foot switch plugged into the program change jack, located on the back of the controller. This will advance the programs in numerical order only. PARAMETERS: Now you can start programming parameters within a program. Let us start by first picking a program, let's try program 00.
TRANSPOSER: Locate parameter 02 through 04 on the parameter chart at top of the keyboard that are clearly marked as TRANSPOSER 1, 2, and 3. Use these functions for transposition. Why are there three TRANSPOSER functions? The answer is, there are three zones, so there must be a control for transposition for each zone. Again, look at the parameter chart on top of the keyboard. The number 02 refers to the parameter number, TRANSPOSER refer to the transposition function and 1 refers to zone #1.
In order to get a result like that you must program the program change map so that the transmitting number 99 equals sound 127. There can be any type of number combinations. It is all a matter of your needs. FOOT SWITCH CONTROL: Parameter 14, 15, and 16 allows the possibility to enable or disable the sustain foot switch and or the wheel function for each zone. The programming routine is the same as the other parameters.
Three Sounds Split at B3 and B6 00 = 27 01 = 63 02 = 00 03 = 00 04 = 00 05 = 01 06 = 00 07 = 30 08 = 02 09 = 01 10 = 03 11 = 08 12 = 00 13 = 33 14 = 03 15 = 03 16 = 03 17 = 50 18 = 50 - Note: Part 1, 2 & 3 used across keyboard. One Sound Across keyboard, Two more Layered Above C5 00 = 88 01 = 40 02 = 00 03 = 00 04 = 00 05 = 00 06 = 00 07 = 00 08 = 01 09 = 02 10 = 03 11 = 00 12 = 10 13 = 02 14 = 01 15 = 02 16 = 02 17 = 50 18 = 50 - Note: Part 1 across keyboard, part 2 & 3, C#5 to top of keyboard.
PARAMETER CHART MIDI IMPLEMENTATION CHART ST-90 Plus FUNCTION Channel Mode Default Messages Note Number Velo. Note On Note off After Key,s Touch Ch's Pitch Bender 1 Control 2 Change: 4 5 6 7 64 65 Velocity Dyn. Velocity Rel. Program Chg. Sys. Ex.
MIDI PEDALBOARD MP-1 TURN-ON DEFAULTS: - MIDI Channel = 1 - Note Range = 24-36 (Octave 2) - Program = none - Velocity = 64 (Fixed) CHANNEL MIDI OCTAVE PRESET MP 1 OPERATING INSTRUCTIONS: 8 4 2 1 OCTAVE CH. MIDI PRESET BINARY LED DISPLAY: Those familiar with older style “bass pedals” may, on first glance, think that the 8-42-1 LEDs on the left side of the MIDI PEDALBOARD are “footage” indicators.
As a frame of reference, Note 60 is Middle C on the piano; a piano has a range of Note 21 (lowest A) to Note 108 (highest C); and a typical 5 - octave synthesizer has a range of Note 36 (lowest C) to 96 (highest C). Depending on the MIDI device connected to your MIDI PEDALBOARD, some octaves may not play, or may give unusual results. CHANNEL ASSIGNMENT: Depress and release the CH. MIDI footswitch and the current MIDI Channel will be diplayed by the Binary LEDS for 3 seconds.
STUDIO 900 Willkommen in der Welt des "FATAR STUDIO 900". Wir bedanken uns herzlich Lieferumfang: Zusätzlich zu dem oben bereits erwähnten Netzadapter, sind im Lieferumfang folgende Dinge enthalten: für Ihre kluge Kaufentscheidung zugunsten des technisch hochwertigen "FATAR STUDIO 900" MIDI-Keyboard-Controllers. Auf den folgenden Seiten möchten wir Sie mit den einzelnen Bedienschritten und Funktionen dieses Gerätes vertraut machen.
exakt umgekehrt (Vom letzten Slave bis zum Master). Auf diese Art werden ungewollte Abstürze eines der Geräte verhindert. VERKABELUNG: (Alle Geräte ausgeschaltet) INPUT VDC LED SWITCH ON-OFF MIDI OUTPUTS POWER SUSTAIN 1 9V DC 200mA BEDIENUNG: Betrachten Sie zunächst kurz die Bedienelemente des STUDIO 900: (siehe auch Grafik 01) VOLUME 2 AFT PITCH MOD VOL.
Bitte beachten Sie: PROGRAM CHANNEL CONTROL Pitch A TRANSPOSE Die Betätigung einer dieser Tasten (bei gleichzeitig gedrücktem Funktionstaster 02 "CONT") wird das Funktionsrad 02 ("A") mit dem entsprechenden Controller belegt. * Die nächsten 10 schwarzen Tasten: c# (3. Oktav / 6. schwarze Taste) bis a# (4. Oktav / 15. schwarze Taste) sind jeweils mit einer Ziffer ("1" bis "0") beschriftet.
Um einen Bankwechselbefehl zu senden, gehen Sie bitte wie folgt vor: Halten Sie den Funktionstaster 03 "PROG." gedrückt, betätigen nun kurz die "Bank"-Taste (f# / 4. Oktav / 18. schwarze Taste) und tippen Sie daraufhin die gewünschte Zahl mit den durch die entsprechenden Ziffern gekennzeichneten, schwarzen Keyboardtasten ein (ab der 6. schwarzen Taste). Sowie Sie nun den Funktionstaster "PROG." loslassen, wird der Bankwechselbefehl gesendet.
- die Erste (c# / "AFT") steht für Channel-Aftertouch die Zweite (d# / "PITCH") für Pitchbend (Tonhöhenbeugung) die dritte schwarze Taste (f# / "MOD") für Modulation (CC 01) die Vierte (g# / "VOL") für Volume (CC 07 = Lautstärke) die Fünfte (a# / "PAN") für Panorama (CC 10 = Position des Instruments im Stereobild) Also, sollten Sie diese Controller wünschen, betätigen Sie während des Haltens des Funktionstasters 02 "Cont." einfach eine dieser ersten fünf schwarzen Tasten.
STUDIO 90 Plus Param. Value Prog. 1 2 3 4 5 6 7 8 9 0 PLUS Enter GENERALPROGRAMMIERUNG (STUDIO 90 Plus) Das Manual ausschalten. Die Tasten "ENTER" und "1" von der Nummerntastatur gedrückt halten. Die o.g. Tasten immer gedrückt halten und gleichzeitig das Manual einschalten. Wichtig: Die Generalprogrammierung löscht alle Programme die Sie gespeichert haben. ANSCHLÜSSE Bevor Sie mit dem Spiel auf Ihrem STUDIO 90 Plus beginnen können, müßen Sie die notwendigen Anschlüßen herstellen.
DIE PROGRAMMIERUNG PARAMETERN UND WERTE (STUDIO 90 Plus) PARAMETER FUNKTION VALUE (WERT) 00 Splitpunkt left 00-88 01 Splitpunkt right 00-88 Param. Value Prog. 02 Transposer 1 00-11 03 Transposer 2 00-11 04 Transposer 3 NUMERIC KEYS DISPLAY 00-11 1 2 3 4 5 6 7 8 9 0 Enter ENTER KEY PROGRAM KEY VALUE KEY PARAMETER KEY 54 05 Octave 1 70-00-07 06 Octave 2 70-00-07 07 Octave 3 70-00-07 08 Midi out 1 01-16 09 Midi out 2 01-16 10 Midi out 3 01-16 11 Instr.
Beispiel: Im Programm Nr. 12 soll der linke Spitpunkt bei Taste Nr. 17 und der rechte Splitpunkte bei Taste Nr. 42 liegen. Schritt 1 SPLIT 1 PAR. 00 SPLIT 2 PAR. 01 CHANNEL MIDI 1 PAR. 08 CHANNEL MIDI 2 PAR. 09 CHANNEL MIDI 3 PAR. 10 TRANSPOSER 1 PAR. 02 TRANSPOSER 2 PAR. 03 TRANSPOSER 3 PAR. 04 OCTAVE 1 PAR. 05 OCTAVE 2 PAR. 06 OCTAVE 3 PAR. 07 2 SPLIT 2 PAR. 01 SPLIT 1 PAR. 00 CHANNEL MIDI 1 PAR. 08 CHANNEL MIDI 1-2-3 PAR. 08-09-10 CHANNEL MIDI 3 PAR. 10 TRANSPOSER 1 PAR.
OCTAVE 1, 2, 3 (Parameter 05, 06, 07) Diese Parameter erlauben für jeden Manualbereich eine oktavweise Transponierung bis zu maximal 7 Oktaven nach oben oder unten. Voraussetzung ist jedoch, daß das angeschlossene Instrument über den entsprechenden Tonumfang verfügt. Soll nach oben transponiert werden, ist der Wert (VALUE) in der Reihenfolge "null-Oktavwert" einzugeben, also 01, 02,03 … und so weiter. Beispiel: (Wir befinden uns im Programm Nr.02).
MIDI-PEDAL MP-1 PROGRAMMIERMÖGLICHKEITEN 1.0 OKTAVLAGE Nach dem Betätigen des Tasters "OKTAVE" läßt sich die Oktavlage des Basspedals über die Pedaltasten einstellen: CHANNEL MIDI OCTAVE PRESET - C = tiefste Oktave - Cis = eine Oktave höher u.s.w. MP 1 Nach jedem Betätigen des Tasters "OKTAVE" kann man immer nur einen OktaveWert einstellen. Ggf. erneut den "OKTAVE"-Taster drücken. 8 4 2 1 OCTAVE CH. MIDI PRESET 2.0 MIDI-KANAL Nach Betätigen des Tasters "Ch.
