48" Sealed Burner Rangetop
The patented, dual-stacked sealed
gas burners of our new sealed burner
rangetop take control to a new level.
Two levels, really. The upper-tier burner
delivers maximum heat transfer at
higher settings; the lower-tier
continuous flame ably handles the
subtleties of simmering and melting.
The Wolf exclusive infrared charbroiler,
infrared griddle and French Top ensure
this rangetop stands out from the rest
in performance and also beauty.
Surface Features
Model SRT486C SRT486G SRT484CG SRT484DG SRT484F
Surface Burners – 15,000 Btu/hr
with 950 Btu/hr delivered at simmer 55333
Surface Burner – 9,200 Btu/hr
with 325 Btu/hr delivered at simmer 11111
Infrared Charbroiler – 16,000 Btu/hr
Infrared Griddle – 15,000 Btu/hr*
Double Griddle – 15,000 Btu/hr*
French Top – 15,000 Btu/hr
Shipping Weight (lbs) 240 260 280 280 280
*Infrared griddle and double griddle are 13,000 Btu/hr for LP gas.
Model numbers are for natural gas sealed burner rangetops, add (-LP) to the model number for LP gas.
Specifications
Exterior Finish Classic Stainless Steel
Overall Dimensions
47
7
/8"W x 8
1
/2"H x 28
1
/2"D
Opening Dimensions
48" W x 7
1
/2" H x 24" D
Electrical Requirements 110/120 V AC
50/60 Hz, 15 amp dedicated circuit
Power Cord 6' cord with grounded plug
Accessories
Classic stainless steel risers in 5" and
10" heights, or 20" riser with shelf
Black control knobs—one set available
at no cost
Chrome or brass bezels—platinum bezels
included with rangetop
One-piece wok grate and single burner
grate
Porcelain-coated cast iron two-burner
S-grate
Hardwood cutting board
(griddle models only)
High altitude conversion kit for natural
and LP gas rangetops for installations
over 8,000'
Accessories are available through your Wolf dealer.
To obtain local dealer information, visit the locator
section of our website, wolfappliance.com.
Product Notes
The Wolf 48" sealed burner rangetop is
available in natural and LP gas with your
choice of several top configurations. Model
numbers indicate the rangetop features; (C)
charbroiler, (G) griddle, (DG) double griddle
and (F) French Top. Natural or LP gas must
be specified when ordering the rangetop.
Sealed burner rangetops are shipped with
island trim installed. A riser is required for
installations against a combustible surface.
Red control knobs with platinum bezels
are shipped with the rangetop, as well as
porcelain-coated, cast iron, continuous top
grates. Optional black knobs, bezels and
grates are available as sales accessories.
Model SRT484F shown
This appliance is certified by Star-K to
meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.
Model SRT486C
Model SRT486G
Model SRT484CG
Model SRT484DG
Model SRT484F
Dual-Stacked
Sealed Burner
