2020 CUTOUT SHEET
summersetgrills.com 17322 Gothard St., Huntington Beach, CA. 92647 800.966.8126
SIDE BURNERS
REGRIGERATION
Alturi Double Side Burner w/ LED Illumination (ALTSB2)
13-1/4"(W) x 10-1/4"(H) x 23"(D)
Alturi Sear Side Burner w/ LED Illumination (ALTSS)
13-1/4"(W) x 10-1/4"(H) x 23"(D)
TRL Double Side Burner (TRLSB2)
11-3/4"(W) x 9"(H) x 19 "(D)
TRL Sear Side Burner w/ LED Illumination (TRLSS)
11-3/4"(W) x 9"(H) x 19 "(D)
Sizzler Double Side Burner (SIZSB2)
10-3/4"(W) x 8-1/4"(H) x 21(D)
Single Side Burner (SSSB1)
8"(W) x 2 1/2"(H) x 15-3/4"(D)
Power Burner (TRLPB2)
14"(W) x 19 1/4"(H) x 18 1/4"(D)
Sizzler Pro Series Double Side Burner w/ LED Illumination (SIZPROSB2)
10-3/4"(W) x 8-1/4"(H) x 21"(D)
AMG Power Burner (AMGPB2)
21"(W) x 10 1/4"(H) x 22 1/2"(D)
Alturi 42" Built-in Grill (ALT42T) 40-5/8”(W) x 10-3/16”(H) x 23-1/4”(D)
Alturi 36" Built-in Grill (ALT36T) 34-5/8”(W) x 10-3/16”(H) x 23-1/4”(D)
Alturi 30" Built-in Grill (ALT30T) 28-5/8”(W) x 10-3/16”(H) x 23-1/4”(D)
TRLD 44" Built-in Grill (TRLD44A) 45-1/4"(W) x 11"(H) x 20"(D)
TRL 38" Built-in Grill (TRL38) 38-1/2"(W) x 10"(H) x 20-3/4"(D)
TRL 32" Built-in Grill (TRL32) 30-1/2"(W) x 10"(H) x 20-3/4"(D)
Sizzler 32" Built-in Grill (SIZ32) 30-5/8"(W) x 8-1/2"(H) x 20-3/4"(D)
Sizzler 26" Built-in Grill (SIZ26) 23-3/4"(W) x 8-1/2"(H) x 20-3/4"(D)
Sizzler 40" Built-in Grill (SIZ40) 37-7/8”(W) x 8-1/2”(H) x 20-3/4”(D)
SBG 30" Built-in grill (SBG30) 28-1/2"(W) x 10-3/16"(H) x 23-1/16"(D)
Sizzler Professional Series 32" Built-in Grill (SIZPRO32) 30-5/8"(W) x 8-1/2"(H) x 20-3/4"(D)
Sizzler Professional Series 40" Built-in Grill (SIZPRO40) 37-7/8”(W) x 8-1/2”(H) x 20-3/4”(D)
36” American Muscle Grill - Built-in (AMG36) 35"(W) x 15 "(H) x 25"(D)
54” American Muscle Grill - Built-in (AMG54) 53"(W) x 15"(H) x 25 "(D)
BUILT-IN GRILLS
20x27" Vertical Access Door (SSDV-20M) 17-1/4”(W) x 24-1/4”(H) x n/a(D)
33" Double Access Door (SSDD-33M) 30-3/8”(W) x 19-1/4”(H) x n/a(D)
45" Double Access Door (SSDD-45M) 42-3/8”(W) x 19-1/4”(H) x n/a(D)
17" Double Drawer w/ Masonry Frame Return (SSDR2-17M) 15-5/8”(W) x 19-1/4”(H) x 19-3/4”(D)
27” Horizontal Door (SSDH-27M)
17" Vertical 2-Drawer & Paper Towel Holder Combo w/ Masonry Frame Return
(SSTDC-17M)
15-1/4"(W) x 27-3/4"(H) x 20-3/4"(D)
20" Trash (or) LP Tank Pullout Drawer w/ Masonry Frame Return (SSTD1-20M) 18-1/8”(W) x 24-1/2”(H) x 19-3/8(D)
33" 2-Drawer & Access Door Combo (SSDC2-33M) 30-3/4”(W) x 19-1/2”(H) x 19-1/2”(D)
12” Island Vent (SSIV-12M) 000”(W) x 000”(H) x 000(D)
MASONRY COMPONENTS
STORAGE DRAWERS
ACCESS DOORS
COMBOS
These dimensions are subject to change—make sure to reference the latest information on the Summerset website at
www.summersetgrills.com/cutouts
16" x 18" Vertical Access Door (SSDV-16) 14-1/4"(W) x 16-1/4"(H) x n/a"(D)
Vertical Door (SSDV-18) 14-1/2”(W) x 19-1/2”(H) x n/a(D)
20x27" Vertical Access Door (SSDV-20) 17-3/8”(W) x 24-3/8”(H) x n/a(D)
22” Horizontal Drawer (SSDH-22)
Horizontal Door (SSDH-27) 24-3/8”(W) x 17-3/8”(H) x n/a(D)
26" Double Access Door (SSDD-26) 23 3/8”(W) x 19 3/8”(H) x n/a”(D)
30” Double Access Door (SSDD-30) 27-1/4”(W) x 19-3/8”(H) x n/a(D)
33” Double Access Door (SSDD-33) 30 1/4”(W) x 19 3/8”(H) x n/a”(D)
36” Double Access Door (SSDD-36) 33 3/8”(W) x 19 1/2”(H) x n/a”(D)
39” Double Access Door (SSDD-39) 36 1/4”(W) x 19 3/8”(H) x n/a”(D)
42” Double Access Door (SSDD-42) 39 3/8”(W) x 19 3/8”(H) x n/a”(D)
45" Double Access Door (SSDD-45) 42-3/8”(W) x 19-3/8”(H) x n/a(D)
39" Double Access Door (SSDD-39) 36-1/4”(W) x 19-3/8”(H) x n/a(D)
36" Double Access Door (SSDD-36AMG) 34-1/2”(W) x 18”(H) x n/a(D)
30” Vented Double Access Door (SSDD-33V) 33 3/8”(W) x 19 1/2”(H) x n/a(D)
17" Single Drawer (SSDR1-17) 15 1/4"(W) x 10-1/2"(H) x 20-1/4"(D)
17" Double Drawer (SSDR2-17) 15 1/4"(W) x 19-1/2"(H) x 20-1/2"(D)
17" Triple Drawer (SSDR3-17) 15-1/4”(W) x 27-1/4”(H) x 20-1/2”(D)
32" Double Horizontal Drawer (SSDR2-32H) 30-1/8"(W) x 6-1/4"(H) x 20-1/8"(D)
26" Utensil Drawer (SSDR1-26U) 23-1/4"(W) x 4"(H) x 20-3/4"(D)
36x20" Extra Large Storage Drawer w/ Matching AMG Handle (SSDR1-36AMG) 34-3/4"(W) x 17-3/4"(H) x 221/2"(D)
36" Warming Drawer (SSWD-36) 34-3/8"(W) x 10"(H) x 21"(D)
20" Vented Liquid Propane Tank Or Trash Drawer (SSDR1-20LP) 18"(W) x 24-3/4"(H) x 20-1/2"(D)
20" Trash Recycling 2-Bin Pullout Drawer (SSTD2-20) 18 1/4”(W) x 24-3/8”(H) x 24-3/8”(D)
17" Vertical 2-Drawer & Paper Towel Holder Combo (SSTDC-17) 15-1/4"(W) x 27-3/4"(H) x 20-3/4"(D)
33" 2-Drawer & Access Door Combo (SSDC2-33) 30-3/4”(W) x 19-3/4”(H) x 20-1/2”(D)
33" 3-Drawer & Access Door Combo (SSDC3-33) 30-5/8”(W) x 19-3/4”(H) x 20-1/2”(D)
33" 2-Drawer & Vented LP Tank Pullout Drawer Combo (SSDC2-33LP) 30-1/4”(W) x 19-3/4”(H) x 20-1/4”(D)
36” Door/Drawer Combo (SSDC2-36)
34”(W) x 19-1/2”(H) x 20-1/2”(D)
42” Door/Drawer Combo (SSDC2-42)
39 1/2”(W) x 19-3/4z”(H) x 20-1/2”(D)
30” Door/Drawer Combo (SSDC2-30)
28”(W) x 19-1/2”(H) x 20-1/2”(D)
36” 2-Drawer Dry Storage Pantry & Enclosed Cabinet Combo (SSDP-36DC) 36 1/4”(W) x 19 1/4”(H) x 20 1/2”(D)
36” 2-Drawer Dry Storage Pantry & Access Door Combo (SSDP-36AC) 36 1/4”(W) x 19 1/4”(H) x 20 1/2”(D)
15” Outdoor Fridge (SSRFR-15S)
15” Glass Outdoor Fridge (SSRFR-15SG)
15” Wine Cooler (SSRFR-15W)
15” Dual Zone Wine Cooler (SSRFR-15WD)
24” Wine Cooler (SSRFR-24W)
24” Dual Zone Wine Cooler (SSRFR-24WD)
Summerset 21” 4.5 Compact Refrigerator (Right-to-Le Opening)
(SSRFR-21S-R)
Summerset 21" 4.5 Compact Refrigerator (Le-to-Right Opening)
(SSRFR-21S)
22"(W) x 33-1/2"(H) x 24"(D)
Summerset 24" 5.3c Outdoor Rated Refrigerator (SSRFR-24S) 25"(W) x 35 "(H) x 26"(D)
Summerset 24" 5.3c Deluxe Outdoor Rated Refrigerator (SSRFR-
24D)
25"(W) x 35 "(H) x 26"(D)
Summerset 24" 5.3c Deluxe Outdoor Rated 2-Drawer Refrigerator
(SSRFR-24DR2)
25"(W) x 35 "(H) x 26"(D)
Summerset 24" 5.3c Deluxe Outdoor Rated Wine Cooler (SSRFR-
24DWC)
25"(W) x 35 "(H) x 26"(D)
Summerset 24" 6.6c Deluxe Outdoor Rated Kegerator w/ Single
Tap Tower (SSRFR-24DK1)
25"(W) x 35 "(H) x 26"(D)
Summerset 21" 4.5c Deluxe Compact Refrigerator (Right-to-Le
Opening) (SSRFR-21D-R)
22"(W) x 33-1/2"(H) x 24"(D)
Summerset 21” 4.5c Deluxe Compact Refrigerator (Le-to-Righdt
Opening) (SSRFR-21D)
Summerset 24" 6.6c Deluxe Outdoor Rated Kegerator w/ Double
Tap Tower (SSRFR-24DK2)
25"(W) x 35 "(H) x 26"(D)
