Use and Care Manual

11
Digital Gauge
The digital gauge on the air compressor is multifunctional.
It serves as a pressure gauge, monitors the amount of
pressure being applied to the item being inated.
To switch from PSI, BAR, or KPA.
1. With gauge ON, press the power button to select the
desired measuring unit (Fig. 9).
To set pressure gauge for automatic shut o:
1. With gauge ON, press and hold down [ + ] or [ – ] buttons
to select desired shuto pressure (Fig. 10).
NOTE: Numbers will ash while setting pressure. Holding
buttons down will make the pressure number increase
faster.
2. When desired setting has been selected, begin inating.
Air compressor will shut o once setting is reached.
LED Light (Fig. 11)
The air compressor is equipped with a LED light above the
trigger switch to provide additional lighting for operation in
low light conditions. The LED light will turn on when the power
button [
] is pressed and will stay on for 30 seconds.
Starting + Stopping
1. Slide the battery into the battery compartment until it
clicks to lock it into position (Fig. 12).
2. To turn the air compressor ON, press the power button
[
] below the LCD display (Fig. 9).
NOTE: The digital gauge will automatically shut o when
not in use for 30 seconds or more.
3. With gauge ON, select the desired shuto pressure by
pressing [ + ] or [ – ] buttons (Fig. 10). Once it is set, wait a
few seconds until the current tire pressure displays.
NOTE: Always check and follow the manufacturer’s
recommended pressure, usually located on the door jamb
of your vehicle.
NOTE: Should the pump fail to reach the desired pressure
setting within 15 minutes, the pump will automatically shut
o.
4. Place air chuck over valve stem and press down, readout
will appear on gauge (Fig. 10).
PSI
BAR
KPA
Fig. 9
Air pressure
measurement
units
Power button
PSI
BAR
KPA
0.0
Fig. 10
Air pressure
(+) Button (–) Button
Fig. 11
LED light
Fig. 12
Battery
Battery
compartment
