20 Cluster Platform 4500/3 User’s Guide • July 2001
4. Modify the default IP address that will be used in your network. Use the addr
command to modify the network configuration of the terminal concentrator. Use
the
addr -d command to verify the network configuration:
5. Copy the Ethernet address entered above for the terminal concentrator, and add it
to “Ethernet IP Address Worksheet” on page 8 for later reference when
configuring the cluster.
monitor:: addr
Enter Internet address [0.0.0.0]:: 192.212.87.62
Internet address: 192.212.87.62
Enter Subnet mask [255.255.0.0]:: 192.255.255.0
Subnet mask: 192.255.255.0
Enter Preferred load host Internet address [<any host>]:: 0.0.0.0
Preferred load host address: <any host>0.0.0.0
Enter Broadcast address [0.0.0.0]:: 192.212.87.255
Broadcast address: 192.212.87.255
Enter Preferred dump address [0.0.0.0]:: 0.0.0.0
Preferred dump address: 0.0.0.0
Select type of IP packet encapsulation (ieee802/ethernet)
[<ethernet>]:: ethernet
Type of IP packet encapsulation: <ethernet> :: ethernet
Load Broadcast Y/N [Y]:: N
Load Broadcast: N
monitor:: addr -d
Ethernet address (hex): 00-80-2D-ED-21-23
Internet address: 192.212.87.62
Subnet masks: 192.255.255.0
Preferred load host address: <any host>
Broadcast address: 192.212.87.255
Preferred dump address: 0.0.0.0
Type of IP packet encapsulation: <ethernet>
Load Broadcast: N
monitor:: sequence
Enter a list of 1 to 4 interfaces to attempt to use for downloading
code or upline dumping. Enter them in the order they should be
tried, separated by commas or spaces. Possible interfaces are:
Ethernet: net
SELF: self
Enter interface sequence [net]:: self
Interface sequence: self
