Chapter 2 The Cluster Platform 4500/3 System 21
6. Terminate your tip session by entering ~.(tilde and period). Power-cycle the
terminal concentrator to enable the IP address changes and wait at least two
minutes for the terminal concentrator to activate its network.
Note – Double-check to ensure that the Ethernet hub is connected to the local area
network. An RJ-45 cable must connect the Ethernet hub to the administration
network backbone.
a. Disconnect the RJ-45 serial cable (Part No. 5121A) from Port 1 of the terminal
concentrator and from the Sun workstation.
b. Reconnect the serial cable (Part No. 9524A) back into Port 1 of the terminal
concentrator.
Note – At this time, the cluster configuration should be cabled as originally shipped
from the factory.
7. From the Sun workstation, verify that the terminal concentrator responds to the
new IP address:
Note – The Sun workstation must be connected to the same subnet to which the
terminal concentrator was configured.
monitor:: ~ .
# usr/sbin/ping -I 5 148.212.87.62
PING 148.212.87.62: 56 data bytes
64 bytes from scotch (148.212.87.62): icmp_seq=0. time=1. ms
64 bytes from scotch (148.212.87.62): icmp_seq=1. time=0. ms
64 bytes from scotch (148.212.87.62): icmp_seq=2. time=0. ms
64 bytes from scotch (148.212.87.62): icmp_seq=3. time=0. ms
^C
