TABLE C-2 Disk Array to Hub Connections
From Device
From
Location To Device To Location
Cable
Length/Type
Disk array No. 1 (data) F100 No. 1 FC-AL hub No. 1 Port No. 3 5m/F100 fiber
optic
Disk array No. 2 (mirror) F100 No. 2 FC-AL hub No. 2 Port No. 3 5m/F100 fiber
optic
Disk array No. 1 (data) 10BASE-T Ethernet hub Port No. 0 RJ-45
Disk array No. 2 (mirror) 10BASE-T Ethernet hub Port No. 1 RJ-45
TABLE C-3 FC-AL Hub to Server Connections
From
Device
From
Location To Device To Location
Cable
Length/Type
FC-AL
No. 1
Port No. 4 System No. 1 (node 1) System board 3, onboard
FC-AL host adapter, port
No. 0
F100 fiber
optic
FC-AL
No. 1
Port No. 5 System No. 2 (node 2) System board 7, onboard
FC-AL host adapter, port
No. 1
F100 fiber
optic
FC-AL
No. 2
Port No. 4 System No. 1 (node 1) System board 3, onboard
FC-AL host adapter, port
No. 0
F100 fiber
optic
FC-AL
No. 2
Port No. 5 System No. 2 (node 2) System board 7, onboard
FC-AL host adapter, port
No. 1
F100 fiber
optic
TABLE C-4 Management Server Connections
From Device From Location To Device To Location
Cable
Length/Type
Management
server
Serial port A Terminal
concentrator
Serial port No. 1 Serial cable
Management
server
Onboard
Ethernet eri0
Ethernet hub 10BASE-T Port 5 RJ-45
