Appendix B Physical Characteristics B-11
B.3.5.3 Zone 3 (J32) Connector PIN Assignments
TABLE B-8 shows the J32 connector pin assignments, used for ARTM signals.
5 AMC0
EO
RTM_TX20
+ (AMC0
EO_Rx7+)
RTM_TX20
- (AMC0
EO_Rx7-)
GND RTM_RX
19+
(AMC0
EO_Tx6+
)
RTM_RX
19-
(AMC0
EO_Tx6-)
GND RTM_TX19
+ (AMC0
EO_Rx6+)
RTM_TX19
- (AMC0
EO_Rx6-)
GND
6 AMC0
EO
Reserved Reserved GND Reserved Reserved GND RTM_RX20
+ (AMC0
EO_Tx7+)
RTM_RX20
- (AMC0
EO_Tx7-)
GND
7 Reserved Reserved Reserved GND Reserved Reserved GND Reserved Reserved GND
8 Reserved Reserved Reserved GND Reserved Reserved GND Reserved Reserved GND
9 Reserved Reserved Reserved GND Reserved Reserved GND Reserved Reserved GND
10 Reserved Reserved Reserved GND Reserved Reserved GND Reserved Reserved GND
TABLE B-7 J32 Connector Pin Assignments
Row Interface AB BG CD DG EF FG
1 Reserved Reserved Reserved GND Reserved Reserved GND Reserved Reserved GND
2 SAS
AMC0
SAS TX0+
(AMC0
SAS0_Rx+)
SAS TX0-
(AMC0
SAS0_Rx-)
GND SAS RX0+
(AMC0
SAS0_Tx+)
SAS RX0-
(AMC0
SAS0_Tx-)
GND RTS (Serial
0)
DTR
(Serial 0)
GND
3 Reserved Reserved Reserved GND Reserved Reserved GND TXD
(Serial 0)
RXD
(Serial 0)
GND
4 SAS
AMC0
SAS TX2+
(AMC0
SAS1_Rx+)
SAS TX2-
(AMC0
SAS1_Rx+)
GND SAS RX2+
(AMC0
SAS1_Rx+)
SAS RX2-
(AMC0
SAS1_Rx+)
GND DSR
(Serial 0)
CTS (Serial
0)
GND
5 Reserved Reserved Reserved GND Reserved Reserved GND No
Connect
No
Connect
GND
6RTM
LAN0
(Mgmt)
LAN0_A+ LAN0_A- GND LAN0_CT
V
LAN0_CT
V
GND LAN0_B+ LAN0_B- GND
7RTM
LAN0
(Mgmt)
LAN0_C+ LAN0_C- GND ACT_LED
#
LINK_LE
D#
GND LAN0_D+ LAN0_D- GND
TABLE B-6 J31 Connector Pin Assignments (Continued)
Row Interface AB BG CD DG EF FG
