B-12 Sun Netra CP3250 Blade Server User’s Guide • April 2009
B.3.5.4 Zone 3 (J33) Connector PIN Assignments
TABLE B-9 shows the J33 connector pin assignments, which are used ARTM signals.
8RTM
LAN1
(SerDes)
SLAN_TX
1+
SLAN_TX
1-
GND SLAN_RX
1+
SLAN_RX
1-
GND No
Connect
No
Connect
GND
9RTM
LAN2/L
AN4
(SerDes)
SLAN_TX
2+
SLAN_TX
2-
GND SLAN_RX
2+
SLAN_RX
2-
GND SLAN_TX
4+
SLAN_TX
4-
GND
10 RTM
LAN3/L
AN4
(SerDes)
SLAN_TX
3+
SLAN_TX
3-
GND SLAN_RX
3+
SLAN_RX
3-
GND SLAN_RX
4+
SLAN_RX
4-
GND
TABLE B-8 J33 Connector Pin Assignments
Row Interface AB BG CD DG EF FG
1 PCIe x8
Lane
PETx0+ PETx0- GND PERx0+ PERx0- GND FCLKA+ FCLKA- GND
2 PCIe x8
Lane
PETx1+ PETx1- GND PERx1+ PERx1- GND TCLKA+ TCLKA- GND
3 PCIe x8
Lane
PETx2+ PETx2- GND PERx2+ PERx2- GND TCLKB+ TCLKB- GND
4 PCIe x8
Lane
PETx3+ PETx3- GND PERx3+ PERx3- GND TCLKC+ TCLKC- GND
5 PCIe x8
Lane
PETx4+ PETx4- GND PERx4+ PERx4- GND TCLKD+ TCLKD- GND
6 PCIe x8
Lane
PETx5+ PETx5- GND PERx5+ PERx5- GND TCK TMS GND
7 PCIe x8
Lane
PETx6+ PETx6- GND PERx6+ PERx6- GND TRST# TDO GND
8 PCIe x8
Lane
PETx7+ PETx7- GND PERx7+ PERx7- GND TDI PCI_RST
#
GND
9 Reserved No
Connect
No
Connect
GND No
Connect
No
Connect
GND ARTM# PCI_CFG GND
10 Reserved No
Connect
No
Connect
GND No
Connect
No
Connect
GND PS0# Enabled# GND
TABLE B-7 J32 Connector Pin Assignments (Continued)
Row Interface AB BG CD DG EF FG
