1-14 Sun Netra CP3250 Blade Server User’s Guide • April 2009
■ Blade server part number (for example, 3753529), which is the first seven digits on
the part number label
■ Product dash number (for example, -01)
■ Revision number (for example, REV: 01)
The MAC address label contains the base MAC address for the blade server in
printed and barcode form. It is an orange label located on the Zone 1 connector.
FIGURE 1-5 Netra CP3250 Blade Server Barcode Labeling
1.7.2 Viewing the Electronic Blade Server ID
Information
The Sun Netra CP3250 blade server can be electronically identified through its IPMI
FRU ID PROM, which is accessible through standard fru utilities.
The IPMI FRU ID PROM format follows the Intel Specification IPMI Platform
Management FRU Information Storage Definition, v1.0 Document, Revision 1.1,
September 27, 1999.
Part number label
Serial number label
