Chapter 2 Hardware Installation and Service 2-7
● To verify if the fan tray upgrade is installed on a Netra CT 900 server, log into
the Shelf Manager and issue the following command for fan trays 1,2, and 3:
If the “Product Part/Model Number” is 370-7764-xx, the fan trays must be replaced
with high-speed fan trays. Refer to the Netra CT 900 Server Upgrade Guide (820-3255)
for more information.
If the “Product Part/Model Number” is 371-3033-xx or newer, an upgraded fan tray
is already installed.
2.2.2.2 Installing Optional Components
Use the following table to locate your options and installation instructions.
2.2.2.3 Configuring the Advanced Rear Transition Module (ARTM)
If you are using one of the Netra advanced rear transition modules (ARTMs), refer to
the documentation: Netra CP32x0 SAS Storage Advanced Rear Transition Module, Dual
HD User’s Guide (820-3147) (ARTM-HD)
See Section B.3, “Connectors and Pinouts” on page B-2 for detailed connector pin
assignments for the Sun Netra CP3250 blade server.
# clia fruinfo fan_tray 1 | grep "Product Part"
DIMMs “DIMM Requirements” on page 2-19
“Installing a DDR2 DIMM” on page 2-21
Compact Flash card “Installing the Optional Compact Flash Card” on page 2-24
AMC “Compact Flash Location” on page 2-26
