2-16 Sun Netra CP3250 Blade Server User’s Guide • April 2009
The Sun Netra CP3250 blade server supports virtual LAN configuration for the Sun
10 GbE Multithreaded Networking Technolgy ports (MAC addresses 4, 5, 6, and 7).
When configured, the virtual LAN feature enables the assignment of multiple MAC
address to one port.
TABLE 2-3 lists the extra MAC addresses available for the Sun 10
GbE Multithreaded Networking Technolgy ports.
00:14:4f:xx.yy.zz+4 nxge0 (Sun 10 GbE
Multithreaded
Networking
Technolgy 10 GB)
Extended Fabric 0 Slot 7
0:14:4f.xx.xn+5 nxge1 (Sun 10 GbE
Multithreaded
Networking
Technolgy 10 GB)
Extended Fabric 1 Slot 8
0:14:4f.xx.xn+6 nxge2 (Sun 10 GbE
Multithreaded
Networking
Technolgy 1 GB)
AMC and ARTM
0:14:4f.xx.xn+7 nxge3 (Sun 10 GbE
Multithreaded
Networking
Technolgy 1 GB)
AMC and ARTM
TABLE 2-3 Extra MAC Addresses for Virtual LAN Configuration
Primary MAC Address Additional MAC Addresses
0:14:4f.xx.xn+4 0:14:4f.xx.xn+8 through 0:14:4f.xx.xn+14
0:14:4f.xx.xn+5 0:14:4f.xx.xn+15 through 0:14:4f.xx.xn+21
0:14:4f.xx.xn+6 0:14:4f.xx.xn+22 through 0:14:4f.xx.xn+28
0:14:4f.xx.xn+7 0:14:4f.xx.xn+29 through 0:14:4f.xx.xn+35
TABLE 2-2 Netinstall Boot Device Table (Continued)
MAC Address Solaris
Device
Hardware
Device Connects to...
Switch Slot
Connection
