Chapter 2 Hardware Installation and Service 2-29
FIGURE 2-11 Installing an AMC
Caution – Do not use excessive force when installing the AMC into the slot. You
might damage the AMC connector on the Sun Netra CP3250 blade server, causing
permanent damage to the AMC or the blade server. If the AMC does not seat
properly when you apply even pressure, remove the AMC and carefully reinstall it.
