10 Sun StorageTek Dual 4 Gb FC Dual GbE HBA, Emulex Installation Guide • July 2008
■ Place the HBA on a properly grounded antistatic work surface pad when it is out
of its protective antistatic bag.
Installing the Hardware
The hardware installation process involves the following general steps, described in
this section:
■ “To Install the HBA” on page 10
■ “To Connect the Optical Cable” on page 12
■ “To Connect the Ethernet Cable” on page 14
■ “To Apply Power” on page 14
■ “To Verify Proper Installation (for the Solaris OS)” on page 17
■ “To Verify Attached Storage (for the Solaris OS)” on page 17
▼ To Install the HBA
1. Attach an antistatic strap (refer to “Observing ESD and Handling Precautions”
on page 9).
2. Refer to your system installation or service manual to determine an appropriate
ExpressModule slot in which to install the HBA.
3. Press down on the plastic tab to release the ExpressModule latch and pull the
lever out until it is nearly perpendicular to the ExpressModule front panel.
