12 Sun StorageTek Dual 4 Gb FC Dual GbE HBA, Emulex Installation Guide • July 2008
▼ To Connect the Optical Cable
Note – The HBA does not allow normal data transmission on an optical link unless
it is connected to another similar or compatible Fibre Channel (FC) product (that is,
multimode to multimode).
Use multimode fiber-optic cable, which is intended for short-wave lasers, that
adheres to the specifications in
TABLE 2-1.
1. Connect the fiber-optic cable to an LC connector on the HBA.
TABLE 2-1 Optical Cable Specifications
Fiber-Optic Cable Maximum Length Minimum Length Connector
62.5/125 µm
(multimode)
300 meters at 1.0625 Gbps
150 meters at 2.125 Gbps
70 meters at 4.25 Gbps
2 meters LC
50/125
µm
(multimode)
500 meters at 1.0625 Gbps
300 meters at 2.125 Gbps
150 meters at 4.25 Gbps
2 meters LC
