20 Sun StorageTek Dual 4 Gb FC Dual GbE HBA, Emulex Installation Guide • July 2008
1. Use the cfgadm command to identify the HBA to be removed.
2. Use the cfgadm -c unconfigure command to unconfigure the attachment
point ID (Ap_Id) for the HBA.
3. Use the cfgadm -c disconnect command to prepare the HBA for removal.
A flashing Power indicator LED indicates that the HBA is being prepared for
removal. A dark Power indicator LED indicates that the HBA is ready to be
removed.
▼ To Remove the HBA Hardware
1. Disconnect all cables.
2. Press the HBA latch to disengage the HBA, and then pull forward and down to
eject it.
You can now remove the HBA.
cfgadm
Ap_Id Type Receptacle Occupant Condition
pcie5 fibre/hp connected configured ok
pcie6 fibre/hp connected configured ok
