Replacement Part List

O
K
BB
EE
CC
AA
L
EE
CC
K
DD
Make sure the Frontgate Logo goes to the back of the Fire Pit below the Ash Catcher.
Step 2：
Connect Fire bowl Base (O) and Connector (K) by 5/16-18x0.6 Bolt (BB), Ф8 Spring washer (EE) and Ф8 Flat
washer (CC).
O
K
Step 1:
Connect Base (L) and Connector (K) by 5/16-18x1.125 Bolt (AA), Ф8 Spring washer (EE), 5/16-18 Nut (DD)
and Ф8 Flat washer
(
CC
)
.
