Installation & Assembly

Fig.4: Insert end of Support Beam (1) (F1) into Support
Beam (2) (F2) and connect with Bolt (AA) and
Washer (BB)
Fig.5: Connect the assembled Arc Beam (C, D) to
Decorative Connector (G1,G2) with Bolt (AA)
and Washer (BB).
Fig.6: Connect the assembled Support Beam (F1,F2)
to Decorative Connector (G1,G2) with Bolt (AA)
and Washer(BB).
Fig.7: Connect Arc Support (K,L) to Post (H1,H2) with
Bolt(AA) and Washer(BB).
Fig.8: Connect Arc Support 2 (L) to Arc Beam (C,D) by
using Bolt(AA,CC) and Washer(BB).
Fig.9: Connect Arc Support 1 (K) to Support Beam (F1,F2)
by using Bolt(AA,CC) and Washer(BB).
