SPR-E-Flex-100 Specification sheet




 
SunPower
®
Flexible Solar Panels
|
SPR-E-Flex-110
Please read the safety and installation guide.
Document # 523809 Rev F / LTR_US
High Power and Flexible
Made with SunPower’s highest power Gen II back contact cells,
SunPower’s flexible panels deliver the highest power output and the
highest charging capacity in their product class. SunPower‘s panels
are constructed with top-grade, light-weight polymer materials,
allowing for easy transport, installation and panel flexing up to 30
degrees.

Designed for Toughness
The SunPower Maxeon
®
Solar Cell is the only cell built on a solid
copper foundation. Flexible panels made with SunPower cells are
resistant to power loss via cracking and corrosion, unlike
conventional cells, which are much more likely to lose power when
bent or subjected to a moist environment. SunPower flexible panels
are the #1 choice for customers due of the combination of high
power and cell ruggedness.
Maxeon
®
Solar Cells: Fundamentally better
Engineered for performance, designed for durability.
Easy and Low Cost Installation
The panel can be installed with adhesives and/or use of stainless
steel grommets in the panel. The panels have standard quick-
connect cables. An easy-to-follow installation guide is provided with
each panel.
Warranty: 5 years limited power warranty of 80% of the minimum
specified power rating. Designed in the USA. Assembled in France.
Typical Electrical Data
at STC: 25C, 1000 W/m
2
and AM 1.5
Model SPR-E-Flex-110 SPR-E-Flex-100
Nominal Power (Pnom) 110 W 100 W
Power Tolerance +6/–3% +6/–3%
Rated Voltage (Vmpp) 18.8 V 17.1 V
Rated Current (Impp) 5.9 A 5.9 A
Open-circuit voltage (Voc) 22.8 V 21.4 V
Short-curcuit current (Isc) 6.3 A 6.3 A
Power Temp Coeffiecient
–0.35%/° C
Voltage Temp Coefficient
–58.9 mV/° C
Current Temp Coefficient
2.6 mA/° C
Max. System Voltage 1000 V DC IEC, 600 V DC UL
Series Fuse Rating 15 A

Mechanical Data
Solar Cells
Prime monocrystalline
25% and 23% efficiency SunPower IBC cells
Junction Box TE 1-21-2152049-1 with by-pass diode
Connectors PV4-S (Compatible with MC4)
Cables
4 mm
2
(0.16 in
2
), 12 AWG,
450 mm (17.7 in) long
Grommets 316 Stainless Steel
Charge Controller None provided
Weight 4.4 lb (2 kg)
Panel
Dimensions
1165 x 556 x 20 mm with Jbox, 2 mm w/o Jbox
(45.9 x 21.9 x 0.8 in)

©May 2018 SunPower Corporation. All rights reserved. SUNPOWER, the SUNPOWER logo and MAXEON are
trademarks or registered trademarks of SunPower Corporation. Specifications included in this datasheet are
subject to change without notice.
