Manual

User Guide
GOANG-FANN CO.,LTD.
2007, SUPERLUX I
LB100PS2A01EN (Rev. 1)
nc.
Specifications
Operating voltage
Dc output
Signal separability
Current output
Undulatory voltage
Representative use
CM series recording microphone
S241 recording/ microphoneinstrument
ECM999 M microphoneeasurement
S125 h mheld-and icrophone
PRA518 mConference icrophone
SMKH8K s mtereo icrophone
JUST PLAY IT
Net weight
Dimensions
PS2A
Phantom Power
1400 grams (43.4 oz.)
Power consumption
The PS2A including the product and packages follow the instruction of
EU 2002/95/EC and comply to RoHS.
RoHS
Supplied accessory
AC 100~240V (50~60 Hz)
48+/- 2V
Max 2x6.5 mA (short circuit)
160mm X130mm X 56mm(6.3X5.1X2.2 in)
Supplied with 6.5mm X 1.8M power cable (with option on "U" plug of
US. Standard or "E" plug of Eur. Standard attached)
Φ
?
?
?
?
?
PS2A phantom power unit could be used to power 2ps of
condenser microphone or a pair of stereo condenser
microphone.
Very low undulation and background
noise output (lower than common
mixer's phantom unit around -12dB) suit for use in recording
system.
Fit to power any condenser microphone by 48V particularly
for operating CM-2, CM-5, CM-8 series microphone of
SUPERLUX, it cause low noise natural sound obtainable.
High durability even in use
continuously.
Wide powered range adaptable AC 100V~240V (50~60Hz)
ON/OFF switch attached.
U type
E type
>= 95dB
<=0.15m V
2VA
