SUPER ® SC216 CHASSIS Series SC216BAC-R920LPB SC216BE1C-R920LPB SC216BE1C-R920WB SC216BE2C-R920LPB SC216BE2C-R920WB SC216BE16-R1K28LPB SC216BE16-R1K28WB SC216E16-R1200LPB SC216E16-R1200UB SC216E16-R1010LPB SC216BE16-R920WB SC216BE16-R920LPB SC216BE16-R920UB SC216BE-R1K28LPB SC216BE-R1K28WB SC216E26-R1200LPB SC216E26-R1200UB SC216BE26-R920LPB SC216BE26-R920WB SC216BE26-R920UB SC216BA-R1K28WB SC216BA-R1K28LPB SC216BA-R920WB SC216BA-R920LPB SC216BA-R920UB SC216A-R900LPB SC216A-R900UB SC216E1-R900LPB* SC216E
The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note: For the most up-to-date version of this manual, please see our web site at www.supermicro.com. Super Micro Computer, Inc.
Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SC216 2U chassis. Installation and maintenance should be performed by experienced technicians only. This document lists compatible parts and configurations available when this document was published. Always refer to the our Web site for updates on supported parts and configurations at www.supermicro.com.
SC216 Chassis Manual Manual Organization Chapter 1 Introduction The first chapter covers the primary components included with this chassis and describes the main features of the SC216 chassis. This chapter also includes contact information. Chapter 2 Warning Statements for AC Systems This chapter lists warnings, precautions, and system safety.
Preface Contents Chapter 1 Introduction 1-1 Overview.......................................................................................................... 1-1 1-2 Contacting Supermicro..................................................................................... 1-3 1-3 Returning Merchandise for Service................................................................. 1-4 Chapter 2 Standardized Warning Statements for AC Systems 2-1 About Standardized Warning Statements.....................
SC216 Chassis Manual Chapter 5 Chassis Setup and Maintenance 5-1 Overview.......................................................................................................... 5-1 5-2 Removing the Power Cord............................................................................... 5-1 5-3 Removing the Chassis Cover.......................................................................... 5-2 5-4 Installing Hard Drives..........................................................................
Preface 6-5 Rack Mounting Instructions.............................................................................. 6-4 Identifying the Sections of the Rack Rails....................................................... 6-4 Locking Tabs.................................................................................................... 6-5 Releasing the Inner Rail.................................................................................. 6-5 Installing The Inner Rails on the Chassis...................
SC216 Chassis Manual Dual Port and Cascading Configurations D-11 Single and Dual Port Expanders...................................................................D-11 Single Ports....................................................................................................D-11 Dual Ports......................................................................................................D-11 D-12 Failover...............................................................................................
Preface Dual Port and Cascading Configurations E-9 Single and Dual Port Expanders................................................................... E-11 Single Ports.................................................................................................... E-11 Dual Ports...................................................................................................... E-11 E-10 Failover.........................................................................................................
SC216 Chassis Manual Notes x
Chapter 1: Introduction Chapter 1 Introduction 1-1 Overview Supermicro’s SC216 maximizes storage capacity in a 2U form factor by offering twenty-four hot-swappable 2.5" SAS/SATA hard drive bays for applications requiring extra storage. The chassis design optimizes every aspect of interior space without compromising superior cooling capabilities.
SC216 Chassis Manual Model HDD Backplane I/O Slots Power Supply SC216E16R1200UB 24x 2.5” SAS/SATA SAS2216EL1 4x FH, 3x LP 1200W (Gold Level) SC216E16R1010LPB 24x 2.5” SAS/SATA SAS2216EL1 7x LP 1010W DC SC216BE16R920LPB 24x 2.5” SAS/SATA plus 2x2.5" (opt) SAS2216EL1 7x LP 920W (Platinum Level) SC216BE16R920UB 24x 2.5” SAS/SATA plus 2x2.5" (opt) SAS2216EL1 4x FH, 3x LP 920W (Platinum Level) SC216BE16R920WB 24x 2.5” SAS/SATA plus 2x2.
Chapter 1: Introduction I/O Slots Power Supply SAS216EL1 7x LP 900W 24x 2.5” SAS/SATA SAS216EL1 4x FH, 3x LP 900W SC216E2R900LPB** 24x 2.5” SAS/SATA SAS216EL2 7x LP 900W SC216E2R900UB** 24x 2.5” SAS/SATA SAS216EL2 4x FH, 3x LP 900W Model HDD Backplane SC216E1R900LPB** 24x 2.5” SAS/SATA SC216E1R900UB** *Optional with SC216B models: two additional 2.5" drives that mount in the rear of the chassis.
SC216 Chassis Manual 1-2 Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel: +31 (0) 73-6400390 Fax: +31 (0) 73-6416525 Email: sales@supermicro.
Chapter 1: Introduction 1-3 Returning Merchandise for Service A receipt or copy of your invoice marked with the date of purchase is required before any warranty service will be rendered. You can obtain service by calling your vendor for a Returned Merchandise Authorization (RMA) number. When returning to the manufacturer, the RMA number should be prominently displayed on the outside of the shipping carton, and mailed prepaid or hand-carried.
SC216 Chassis Manual Notes 1-6
Chapter 2: Warning Statements for AC Systems Chapter 2 Standardized Warning Statements for AC Systems 2-1 About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components.
SC216 Chassis Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
Chapter 2: Warning Statements for AC Systems . تحذٌز!هذا الزهز ٌعًٌ خطز اًك فً حالة ٌوكي أى تتسبب فً اصابة جسذٌة كي على علن بالوخاطز الٌاجوة عي الذوائز،قبل أى تعول على أي هعذات الكهزبائٍة وكي على دراٌة بالووارسات الىقائٍة لوٌع وقىع أي حىادث استخذم رقن البٍاى الوٌصىص فً ًهاٌة كل تحذٌز للعثىر تزجوتها 안전을 위한 주의사항 경고! 이 경고 기호는 위험이 있음을 알려 줍니다. 작업자의 신체에 부상을 야기 할 수 있는 상태에 있게 됩니다. 모든 장비에 대한 작업을 수행하기 전에 전기회로와 관련된 위험요소들을 확인하시고 사전에 사고를 방지할 수 있도록 표준 작업절차를 준수해 주시기 바랍니다.
SC216 Chassis Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.
Chapter 2: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A.
SC216 Chassis Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
Chapter 2: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché de toutes les sources de puissance ainsi que de son cordon d'alimentation secteur avant d'accéder à l'intérieur du chassis pour installer ou enlever des composants de systéme.
SC216 Chassis Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden. ¡Advertencia! Solamente el personal calificado debe instalar, reemplazar o utilizar este equipo.
Chapter 2: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security. (This warning does not apply to workstations).
SC216 Chassis Manual אזור עם גישה מוגבלת !אזהרה הגישה ניתנת בעזרת.יש להתקין את היחידה באזורים שיש בהם הגבלת גישה .)' מנעול וכד,כלי אבטחה בלבד (מפתח . تم تخصيص هذه انىحذة نتركُبها فٍ مناطق محظورة ،َمكن انىصىل إنً منطقت محظورة فقط من خالل استخذاو أداة خاصت قفم ومفتاح أو أٌ وسُهت أخري نالمألما 경고! 이 장치는 접근이 제한된 구역에 설치하도록 되어있습니다. 특수도구, 잠금 장치 및 키, 또는 기타 보안 수단을 통해서만 접근 제한 구역에 들어갈 수 있습니다. Waarschuwing Dit apparaat is bedoeld voor installatie in gebieden met een beperkte toegang.
Chapter 2: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.
SC216 Chassis Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニットは複数の電源装置が接続されている場合があります。 ユニットの電源を切るためには、すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.
Chapter 2: Warning Statements for AC Systems .قد يكون لهذا الجهاز عدة اتصاالت بوحدات امداد الطاقة يجب إزالة كافة االتصاالت لعسل الوحدة عن الكهرباء 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을 차단하기 위해서는 모든 연결 단자를 제거해야만 합니다. Waarschuwing Deze eenheid kan meer dan één stroomtoevoeraansluiting bevatten. Alle aansluitingen dienen verwijderd te worden om het apparaat stroomloos te maken.
SC216 Chassis Manual מתח בפנל האחורי !אזהרה יש להיזהר במהלך.קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת .העבודה هناك خطز مه التيار الكهزبائي أوالطاقة المىجىدة على اللىحة عندما يكىن النظام يعمل كه حذرا عند خدمة هذا الجهاس 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is. Voorzichtigheid is geboden tijdens het onderhoud.
Chapter 2: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. תיאום חוקי החשמל הארצי !אזהרה .התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים تركيب المعدات الكهربائية يجب أن يمتثل للقىاويه المحلية والىطىية المتعلقة بالكهرباء 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
SC216 Chassis Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. סילוק המוצר !אזהרה .
Chapter 2: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.
SC216 Chassis Manual Power Cable and AC Adapter Warning! When installing the product, use the provided or designated connection cables, power cables and AC adaptors. Using any other cables and adaptors could cause a malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only.
Chapter 2: Warning Statements for AC Systems Attention Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné. L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
SC216 Chassis Manual Notes 2-20
Chapter 3: Chassis Components Chapter 3 Chassis Components 3-1 Overview This chapter describes the most common components included with your chassis. Some components listed may not be included or compatible with your particular chassis model. For more information, see the installation instructions detailed later in this manual. 3-2 Components For the latest shipping lists, visit our Web site at: http://www.supermicro.com. Drives The chassis includes hard disk drive bays, which support twenty-four 2.
SC216 Chassis Manual Power Supply Each SC216 chassis model includes a high-efficiency redundant power supply rated at 900, 920, 1010, 1200, or 1800 Watts. Air Shroud Air shrouds are shields, usually plastic, that funnel air directly to where it is needed. Always use the air shroud included with your chassis. 3-3 Where to get Replacement Components Infrequently, you may need replacement parts for your system.
Chapter 4: System Interface Chapter 4 System Interface 4-1 Overview Several buttons and LEDs indicate the status of the system. The control panel on the front edge of the chassis includes power buttons and status LEDs. There are also LEDs on the drive carriers the indicate the status of the drive. This chapter explains the LED indicators and responses.
SC216 Chassis Manual 4-2 Control Panel Buttons There are two push-buttons located on the front of the chassis. These are a power on/off button and a reset button. Power: The main power switch is used to apply or remove power from the power supply to the server system. Turning off system power with this button removes the main power but keeps standby power supplied to the system. Therefore, you must unplug system before servicing. Reset: The reset button is used to reboot the system.
Chapter 4: System Interface NIC2: Indicates network activity on GLAN2 when flashing. NIC1: Indicates network activity on GLAN1 when flashing. ! Power Failure: When this LED flashes, it indicates a power failure in the power supply. Information LED: Alerts operator of several states, as noted in the table below. Informational LED Status Description Continuously on and red An overheat condition has occured. (This may be caused by cable congestion.
SC216 Chassis Manual 4-4 Drive Carrier LEDs The SC216 chassis supports SAS/SATA drives. SAS/SATA Drives Each SAS/SATA drive carrier has two LEDs. • • Green or Blue: Each hard disk drive carrier has either a green or a blue LED, depending upon the hard disk drives and backplane used. When illuminated, this LED indicates drive activity. A connection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed. .
Chapter 5: Chassis Setup and Maintenance Chapter 5 Chassis Setup and Maintenance 5-1 Overview This chapter covers the steps required to install components and perform maintenance on the chassis. The only tool required is a Phillips screwdriver. Review the warnings and precautions listed in the manual before setting up or servicing this chassis. These include information in Chapter 2: Warnings for AC Systems, and the precautions listed in the setup instructions.
SC216 Chassis Manual 5-3 Removing the Chassis Cover 14 12 12 13 Remove this screw (if necessary) Release Tab Figure 5-1. Removing the Chassis Cover Removing the Chassis Cover 1. Press the release tabs to remove the cover from the locked position. Press both tabs at the same time. 2. Once the top cover is released from the locked position, slide the cover toward the rear of the chassis. 3. Lift the cover off the chassis.
Chapter 5: Chassis Setup and Maintenance 5-4 Installing Hard Drives 12 1 Figure 5-2. Removing Hard Drive The SC216 comes equipped with twenty-four hot-swappable hard drives which can be removed without powering down the system. Only enterprise level SAS or SATA HDDs are recommended. Removing Hard Drive Carriers from the Chassis 1. Press the release button on the drive tray. This extends the drive bay handle. 2. Use the handle to pull the tray out of the chassis.
SC216 Chassis Manual Figure 5-3. Hard Drive Carrier Installing a Hard Drive into a Drive Carrier 1. Insert a drive into the carrier with the PCB side facing down and the connector end toward the rear of the carrier. 2. Align the drive in the carrier so that the mounting holes of both are aligned. Note that there are holes in the carrier marked "SAS" or “SATA” to aid in correct installation. 3. Secure the drive to the carrier with four screws as illustrated above.
Chapter 5: Chassis Setup and Maintenance Installing the Rear 2.5" Hard Drive--SC216B Only The SC216B model chassis supports an optional hard drive cage for two additional 2.5" hot-swappable hard drives. The hard drive cage installs in the rear of the chassis next to the power supply. Once the hard drive cage has been installed, the 2.5" hard drives may be removed without powering down the server. Installing the 2.5" Rear Hard Drive Cage 1.
SC216 Chassis Manual 14 15 13 Figure 5-6. Securing the Rear 2.5" Hard Drive Cage to the Chassis 3. Place the hard drive cage into the chassis. Secure the front of the hard drive cage to the chassis by fastening one screw inside the opening of the hard drive cage as illustrated. 4. Secure the top of the hard drive cage to the chassis frame with two screws, fastened at the upper edge of the hard drive cage above the opening of the hard drive cage. 5.
Chapter 5: Chassis Setup and Maintenance I/O Shield Figure 5-7. I/O Shield Placement 5-5 Installing the Motherboard I/O Shield The I/O shield holds the motherboard ports in place. Install the I/O shield before installing the motherboard. If the motherboard you purchased did not include a standard I/O shield, contact the motherboard vendor for a compatible shield. Installing the I/O Shield 1. Review the documentation that came with your motherboard.
SC216 Chassis Manual Permanent and Optional Standoffs Standoffs prevent short circuits by creating space between the motherboard and the chassis surface. The SC216 chassis includes permanent standoffs in locations used by most motherboards. These standoffs accept the rounded Phillips head screws included in the accessories package. Some motherboards require additional screws for heatsinks, general components or non-standard security. Optional standoffs are included for these motherboards.
Chapter 5: Chassis Setup and Maintenance Motherboard Installation Installing the Motherboard 1. Review the documentation that came with your motherboard. Become familiar with component placement, requirements, precautions, and cable connections. 2. Power down the system as described in Section 5-2 and open the chassis cover. 3. If necessary, remove the air shroud and riser card bracket. 4. Ensure that the I/O shield has been installed correctly. 5.
SC216 Chassis Manual 5-6 Installing the Expansion Cards For the LP models, such as SC216BAC-R920LPB, the chassis slots are vertical and allow the addition of low profile expansion cards. For the W models such as SC216BE1C-R920WB, and the U models such as SC216E16-R1200UB the chassis slots are horizontal. The U models allow a Supermicro universal I/O (UIO) card in addition to expansion cards. The motherboard must be installed before expansion cards.
Chapter 5: Chassis Setup and Maintenance Figure 5-10. Installing the Low-Profile Expansion Card Expansion Cards for a W or U Model Chassis The W or U model chassis accomodates expansion cards using riser cards. If your motherboard supports a Supermicro universal I/O (UIO) card, the U model chassis supports an additional three full-height expansion cards and three low profile expansion cards.
SC216 Chassis Manual Installing an Expansion Card for a W or U Model Chassis 1. If this is the first expansion card, start by locating the riser card bracket in your chassis accessory bag, and one or two riser cards, which are purchased separately. One riser card accomodates the full-height expansion cards and another riser card accomodates the three low profile expansion cards. 2. Power down the system as described in Section 5-2 and remove the cover. 3.
Chapter 5: Chassis Setup and Maintenance Shield Clamp for Full-Height Card This U model chassis is pictured without the riser card bracket. Shield Clamp for Low Profile Card Figure 5-12. Remove an Expansion Card Slot Shield 5. For a full-height extension card, release the clamp that secures all four PCI shields. Looking at the rear of the chassis, this clamp is in the right corner. Unscrew the single screw that secures the clamp and rotate the clamp away from the shields.
SC216 Chassis Manual 5-7 Installing the Air Shrouds Figure 5-13. Installing the Air Shroud Air shrouds concentrate airflow to maximize fan efficiency. They do not require screws for installation. Installing the Air Shrouds in the Chassis Installing the Air Shrouds 1. Power down the system as described in Section 5-2 and open the chassis cover. 2. Ensure that the motherboard, CPU, heatsink and memory are all properly installed. 3.
Chapter 5: Chassis Setup and Maintenance 14 13 Figure 5-14. Installing the Additional Air Shroud An additional air shroud is required for high-powered CPUs, to provide extra cooling. Install the additional air shroud if necessary. Installing the Additional Air Shroud Installing the Additional Air Shroud in the Chassis 1. Power down the system as described in Section 5-2 and open the chassis cover. 2. Remove the left side break-away piece of the main air shroud. 3.
SC216 Chassis Manual 5-8 Checking the Airflow Checking the Server's Airflow 1. Make sure there are no objects to obstruct airflow in and out of the server. In addition, if you are using a front bezel, make sure the bezel filter is replaced periodically. 2. Do not operate the server without drives or drive carriers in the drive bays. Use only recommended server parts. 3. Make sure no wires or foreign objects obstruct airflow through the chassis.
Chapter 5: Chassis Setup and Maintenance 5-9 System Fans Three heavy-duty fans provide cooling for the chassis. These fans circulate air through the chassis as a means of lowering the chassis internal temperature. The SC216 fans are hot-swappable, enabling the fans to be replaced without powering -down the system. Release Tab Figure 5-15. System Fan Replacing a System Fan 1. If necessary, open the chassis while the power is running to determine which fan requires changing.
SC216 Chassis Manual Figure 5-16.
Chapter 5: Chassis Setup and Maintenance 5-10 Power Supply The SC216 chassis has two redundant power supplies. The power modules are hot-swappable, enabling the power supplies to be changed without powering down the system. These power supplies are auto-switching capable. This enables the power supply to automatically sense and operate at a 100v to 240v input voltage. An amber light will be illuminated on the power supply when the power is off.
SC216 Chassis Manual 4. Replace the failed power module with the same model power supply. 5. Push the new power supply module into the power bay until the tab clicks into the locked position. 6. Plug the AC power cord back into the module and the replacment power module will automatically power-up.
Chapter 5: Chassis Setup and Maintenance Figure 5-18. Replacing the Power Distributor Power Distributor The power distributor provides failover and power supply redundancy, and is pre-installed in the chassis. In the rare event that you have to replace the power distributor, follow the steps below. Changing the Power Distributor 1. Power down the system as described in Section 5-2 and open the chassis cover. 2.
SC216 Chassis Manual 5-11 Removing the Backplane The SC216 chassis backplane is located behind the hard drives and in front of the front system fans. In order to change jumper settings on the backplane, it may be necessary to remove the backplane from the chassis. Removing the Backplane from the Chassis 1. Power down the system as described in Section 5-2 and open the chassis cover. 2. Disconnect the cabling to the backplane. 3. Remove all of the hard drive trays from the front of the chassis. 4.
Chapter 5: Chassis Setup and Maintenance 5. Loosen the three screws in the spring bar, located on the floor of the chassis, indicated by the arrows below. 6 Figure 5-20. Loosening the Spring Bar Screws in the Floor of the Chassis 6. Gently ease the backplane up and out of the chassis.
SC216 Chassis Manual 5-12 Installing the Backplane Installing the Backplane into the Chassis 1. Power down the system as described in Section 5-2 and open the chassis cover. 2. Ensure that all of the hard drive carriers have been removed from the bays in the front of the chassis and that the spring bar has been loosened as directed in the previous section. 3. Slide the backplane into the chassis at a slight angle, pushing it up against the side of the chassis. 4.
Chapter 5: Chassis Setup and Maintenance Notes 5-25
Chapter 6: Rack Installation Chapter 6 Rack Installation 6-1 Overview This chapter provides a quick setup to get your chassis up and running. Following these steps in the order given should enable you to have the system operational within a minimal amount of time. 6-2 Unpacking the System You should inspect the box which the chassis was shipped in and note if it was damaged in any way. If the chassis itself shows damage, you should file a damage claim with the carrier who delivered it.
SC216 Chassis Manual 6-4 • Warnings and Precautions Rack Precautions Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full weight of the rack resting on them. • In single rack installations, stabilizers should be attached to the rack. • In multiple rack installations, the racks should be coupled together. • • • • • • • • Always make sure that the rack is stable before extending a component from the rack.
Chapter 6: Rack Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (TMRA).
SC216 Chassis Manual 6-5 Rack Mounting Instructions This section provides information on installing the chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly from the instructions provided. You should also refer to the installation instructions that came with the rack unit you are using. Note: This rail will fit a rack between 26.5" and 36.4" deep.
Chapter 6: Rack Installation Locking Tabs Each inner rail has a locking tab. This tab locks the chassis into place when installed and pushed fully into the rack. These tabs also lock the chassis in place when fully extended from the rack. This prevents the server from coming completely out of the rack when when the chassis is pulled out for servicing. Releasing the Inner Rail Releasing Inner Rail from the Outer Rails 1. Identify the left and right outer rail assemblies as described on page 6-4. 2.
SC216 Chassis Manual 14 Inner Rails 2 14 3 Figure 6-3. Installing the Inner Rails Figure 6-4. Inner Rails Installed on the Chassis (The chassis above are an example only. Actual chassis may differ slightly) Installing The Inner Rails on the Chassis Installing the Inner Rails 1. Confirm that the left and right inner rails have been correctly identified. 2. Place the inner rail firmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail. 3.
Chapter 6: Rack Installation 1 L-min=676.00(26.61")(outer rail) 12 14 21D01 13 Figure 6-5. Extending and Releasing the Outer Rails Installing the Outer Rails on the Rack Installing the Outer Rails 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3. Hang the hooks of the front of the outer rail onto the slots on the front of the rack. If necessary, use screws to secure the outer rails to the rack, as illustrated above. 4.
SC216 Chassis Manual Ball-Bearing Shuttle Figure 6-6. Installing into a Rack Note: Figures are for illustrative purposes only. Always install servers into racks from the bottom up. Standard Chassis Installation Installing the Chassis into a Rack 1. Confirm that the inner rails are properly installed on the chassis. 2. Confirm that the outer rails are correctly installed on the rack. 3.
Chapter 6: Rack Installation Optional Quick Installation Method The following quick installation method may be used to install the chassis onto a rack. Installing the Chassis into a Rack 1. Install the whole rail assembly onto the rack as described on page 6-7. 2. Release the inner rail without retracting the middle rail. 3. Install the inner rails on the chassis as previously described on page 6-6. 4. Install the chassis onto the middle rail as described in the previous section.
SC216 Chassis Manual Notes 6-10
Appendix A Chassis Cables Appendix A SC216 Chassis Cables A-1 Overview This appendix lists supported cables for your chassis system. It only includes the most commonly used components and configurations. For more compatible cables, refer to the manufacturer of the motherboard you are using and our Web site at: www.supermicro.com.
SC216 Chassis Manual A-3 Compatible Cables These cables are compatible with the SC216 chassis. Alternate SAS/SATA Cables Some compatible motherboards have different connectors. If your motherboard has only one SAS connector that the SAS/SATA cables must share, use one of the following cables. These cables must be purchased separately. Cable Name: SAS Cable Quantity: 1 Part #: CBL-0175L Alt.
Appendix A Chassis Cables Extending Power Cables Although Supermicro chassis are designed to be efficient and cost-effective, some compatible motherboards have power connectors located in different areas. To use these motherboards you may have to extend the power cables to the mother boards. To do this, use the following chart as a guide. Power Cable Extenders Number of Pins Cable Part # Length 24-pin CBL-0042 7.9” (20 cm) 20-pin CBL-0059 7.9” (20 cm) 8-pin CBL-0062 7.
SC216 Chassis Manual Notes A-4
Appendix B Power Supply Specifications Appendix B SC216 Power Supply Specifications This appendix lists power supply specifications for the SC216 chassis. 920 Models, such as SC216BAC-R920LPB 920W MFR Part # PWS-920P-SQ with PDB AC Input 100-240 V, 4.5-11 Amp, 50-60 Hz DC Output +12V 75 Amp +5V standby 4 Amp +5V 45 Amp +3.3V 24 Amp -12V 0.
SC216 Chassis Manual 1200 Models, such as SC216E16-R1200LPB 1200W MFR Part # PWS-1K21P-1R with PDB AC Input DC Output +12V 100 - 140V, 50 - 60Hz, 8 - 11.5 Amp 180 - 240V, 50 - 60Hz, 5.5 - 8 Amp 1000W, 83 Amp @ 100-140V 1200W, 100 Amp @ 180-240V +5 Standby 4 Amp +5V 45 Amp +3.3V 24 Amp -12V 0.6 Amp SC216E16-R1010LPB 1010W MFR Part # PWS-1K11P-1R DC Input DC Output +12V 850W: -36--42V; 30-25Amp 1010W: -43 -76V; 30-17Amp 850W, 70 Amp 1010W, 83 Amp +5 Standby 4 Amp +5V 50 Amp +3.3V 30 Amp -12V 0.
Appendix C SAS-216A Backplane Specifications Appendix C SAS-216A Backplane Specifications To avoid personal injury and property damage, carefully follow all the safety steps listed below when accessing your system or handling the components. C-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic components. To prevent damage to your system, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD.
SC216 Chassis Manual C-3 A Note to Users All images and layouts shown in this user's guide are based upon the latest PCB Revision available at the time of publishing. The card you have received may or may not look exactly the same as the graphics shown in this manual. C-4 Introduction to the SAS-216A Backplane The SAS-216A backplane has been designed to utilize the most up-to-date technology available, providing your system with reliable, high-quality performance. This manual reflects SAS-216A Revision 1.
Appendix C SAS-216A Backplane Specifications C-5 Front Connector Locations JSM6 6 13 SAS IN#6 5 12 JP95 I2C#2 1 A1 + JP36 1 C139 BZ1 1 + + + 8 4 C327 1 JP48 8 4 C244 C253 C239 + JP109 1 JP46 4 8 C201 + 1 C197 + + C323 C220 C153 C294C295 1 JP13 8 4 1 JP10 4 C6 C47 C5 D4 D9 C A D9:ALARM#3 D3 R6 8 4 B1 R7 JP110 6 R8 1 C224 U30 C420 C24 C157 5 I2C#3 U91 R608 U88 C399 JP80 C297 C298 3 JP84 JSM2 JSM3 R365 C213 JP52 + 2 3 3 C38
SC216 Chassis Manual C-6 Front Connectors and Pin Definitions 1. Upgrade Connectors The upgrade connectors are designated JP69, JP78 and JP115 are used for manufacturer's diagnostic purposes only. 2. - 7. I2C Connectors I2C Connector Pin Definitions The I C Connectors, designated JP37, JP95, JP52, JP96, JP115 and JP116 are used to monitor HDD activity and status. See the table on the right for pin definitions. 2 Pin# Definition 8.
Appendix C SAS-216A Backplane Specifications C-7 Front Jumpers SAS IN#6 16 U53 SAS IN#4 SAS IN#5 C280 C250 R431 R287 SAS IN#3 R282 R283 JP95 I2C#2 A1 + JP36 1 C139 BZ1 JP52 R608 U88 C399 JP80 18 + + + C327 1 JP48 4 C244 C253 C239 + 4 1 JP46 C201 4 + JP109 C197 + 1 C220 C153 C294C295 1 JP13 4 1 JP10 4 C6 C47 C5 D4 D9 C A D9:ALARM#3 D3 R6 + C323 C224 R7 4 B1 R8 JP110 6 U30 1 5 I2C#3 U91 C415 C420 3 JP84 JSM2 JSM3 R365 C213 3 3 C2
SC216 Chassis Manual I2C and SGPIO Modes and Jumper Settings This backplane can utilize I2C or SGPIO. SGPIO is the default mode and can be used without making changes to your jumper. The following information details which jumper must be configured to use SGPIO mode or restore your backplane to I2C mode.
Front LED Indicators + JSM6 SAS IN#6 U53 SAS IN#4 SAS IN#5 C280 C250 R431 R287 R430 SAS IN#3 C44 SAS IN#2 BAR CODE R283 JP95 I2C#2 A1 + R281 R286 JP96 R280 JP36 1 + 2 1 C212 C139 Y2 BZ1 3 3 C383 R585 JP52 3 JP84 JSM2 JSM3 R365 C213 JP117 JP36 9072#2 RST 1-2:RST 2-3:NO RST JSM4 1 R432 C247 R268 R267 3 JSM5 C249 C246 R273 I2C#4 1 REV: 1.
SC216 Chassis Manual C-8 Rear Components, Connectors and LED Indicators 1 16 16 U24 C100 C102 U66 C359 48 48 33 RP6 J44 J36 J20 J11 J45 J34 J9 J31 J43 J18 J4 J33 J28 J3 J17 J15 J37 J2 J35 J21 J1 J13 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 7 27 33 33 8 9 8 9 33 8 9 33 8 9 33 8 9 33 8 9 9 33 8 9 33 8 33 8 9 33 8 9 33 8 9 33 8 9 33 8 9 33 8 9 33 8 9 33 8 9 33 8 9
Appendix C SAS-216A Backplane Specifications Rear LED Indicators Hard Drive Activity Failure LED SAS #0 Rear LED D12 D5 SAS #1 D22 D23 SAS #2 D40 D37 SAS #3 D102 D107 SAS #4 D13 D6 SAS #5 D24 D29 SAS #6 D41 D38 SAS #7 D104 D108 SAS #8 D14 D7 SAS #9 D25 D30 SAS #10 D42 D39 SAS #11 D106 D109 SAS #12 D15 D8 SAS #13 D26 D31 SAS #14 D87 D88 SAS #15 D111 D110 SAS #16 D18 D19 SAS #17 D27 D32 SAS #18 D100 D103 SAS #19 D118 D119 SAS #20 D21 D20 SAS #2
SC216 Chassis Manual Notes C-10
Appendix D SAS-216EL Backplane Specifications Appendix D SAS-216EL Backplane Specifications D-1 Overview of the SAS-216EL1/EL2 Backplanes The SAS-216EL1/EL2 series of backplanes consists of a SAS-216EB backplane (A) with one or two SAS-216EL daughter cards (B and C) mounted on the rear of the backplane. The SAS-216EL1 model consists of the SAS-216EB backplane (A) and one SAS216EL daughter card (C), mounted on the right-hand side of the backplane.
SC213 Chassis Manaual D-2 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic components. To prevent damage to your system, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. • • • • • Use a grounded wrist strap designed to prevent static discharge. Touch a grounded metal object before removing a component from the antistatic bag.
+ + BC50 BC91 BC82 BC54 BC55 BC81 BC87 BC51 +12V GND GND BC83 +5V +12V BC72 C133 C130 C105 C103 C120 C118 C127 C124 C106 C98 C126 C123 C132 C129 C138 C135 C146 C166 C88 C107 C111 C90 C113 C94 C162 C159 C158 C157 C155 C172 C153 C168 L28 L10 L17 L15 L34 L32 L41 L51 L47 L43 L40 WWN GND GND R72 C339 R104 C171 R8 BC2 C326 C327 C340 L3 L65 L58 L55 L52 L50 L46 L45 L39 L69 L68 L62 L67 L61 L60 L59 L66 L25 L23 L8 L6 R105 R88 C337 R106 R108 R75 C349 C343 C341 C344 C342 C345 C3
SC213 Chassis Manaual D-7 Rear Connectors and Pin Definitions 1. Primary Flash Chips The primary flash chip enhances the backplane memory. 2. Expander Chips This expander chip allows the backplane to support dual ports, cascading, and failover. 3. - 5. SAS Ports The primary and secondary sets of SAS ports provide expander features including cascading and failover From right to left the ports are Primary 1, 2, 3 and Secondary 1, 2 and 3. 6.
+ + + C142 GND GND + +5V +12V GND GND 64 +12V + + + +5V +12V GND +12V GND +5V GND GND +5V +12V GND GND 2 +5V +5V + GND + BC50 BC58 BC60 + BC62 + + BC64 BC53 BC74 BC70 BC76 BC65 BC78 BC68 + BC86 BC90 BC92 + + + + + + + BC91 BC82 C117 BC54 BC55 BC81 BC87 BC51 BC83 BC2 BC1 EC5 EC11 BC72 C48 C48 EC5 BC2 BC1 63 BC96 BC10 BC49 BC67 + C95 BC84 + BC96 BC10 BC12 BC5 + BC13 BC18 BC14 BC20 + + + EC11 C171 R8 + BC2 BC36 BC22 BC26
SC213 Chassis Manaual General Jumper Settings Jumper Jumper Settings Note PRI_MODE1 1-2 Factory setting do not change BUZZER_ENB1 Open: Disable Closed: Enable Buzzer enable* Socket Settings Socket REMOTE_FAN_FAIL_ SOCKET1 Socket Setting Note Front panel fan fail indicator (optional) Connected Front Panel LEDs LED State Specification 12V_LED1 OFF Backplane power failure. Light is on during normal operation. 5V_LED1 OFF Backplane power failure. Light is on during normal operation.
Appendix D SAS-216EL Backplane Specifications MH7 SAS #J23 27 SAS #J22 SAS #J19 C28 C32 SAS #J21 SAS #J18 C25 C26 SAS #J20 SAS #J17 C33 C34 27 SAS #J16 MH6 27 SAS #J15 SAS #J14 MH4 MH2 SAS #J13 SAS #J12 SAS #J11 SAS #J10 MH3 SAS #J9 SAS #J8 SAS #J7 SAS #J6 Rev:1.
SC213 Chassis Manaual Front LED Indicators Hard Drive Activity Failure LED SAS #J0 Front LED ACT #1 FAIL #1 SAS #J1 ACT #2 FAIL #2 SAS #J2 ACT #3 FAIL #3 SAS #J3 ACT #4 FAIL #4 SAS #J4 ACT #5 FAIL #5 SAS #J5 ACT #6 FAIL #6 SAS #J6 ACT #7 FAIL #7 SAS #J7 ACT #8 FAIL #8 SAS #J8 ACT #9 FAIL #9 SAS #J9 ACT #10 FAIL #10 SAS #J10 ACT #11 FAIL #11 SAS #J11 ACT #12 FAIL #12 SAS #J12 ACT #13 FAIL #13 SAS #J13 ACT #14 FAIL #14 SAS #J14 ACT #15 FAIL #15 SAS #J15 ACT #1
Appendix D SAS-216EL Backplane Specifications D-10 Front Connectors and Jumpers Front Components 1. Power Connectors: PWR1, PWR2, PWR3, PWR4, PWR5, and PWR6.
SC213 Chassis Manaual Dual Port and Cascading Configurations D-11 Single and Dual Port Expanders Single Ports SAS-216EL1 backplanes have a single-port expander on the daughter card, that accesses all twenty-four drives and supports cascading.
Appendix D SAS-216EL Backplane Specifications D-12 Failover The SAS-216EL2 backplane has two expanders which allow effective failover and recovery.
SC213 Chassis Manaual D-13 Chassis Power Card and Support Cables Chassis Power Card In a cascaded configuration, the first chassis includes a motherboard and at least one HBA. Other servers in this enclosed system, include a power card. This section describes the supported power card for the SAS-216 series backplane. For more information, see the Supermicro Web site at http://www.supermicro. com. A A A JBPWR2 REV 1.00 Figure D-10.
Appendix D SAS-216EL Backplane Specifications Connectioning an Internal Host Bus Adapter to the Backplane The following section lists the most common cables used to connect the HBA to the backplane.
SC213 Chassis Manaual Cable Name: iPass (Mini-SAS) to iPass (Mini-SAS) Part #: CBL-0108L-02 Length: 39 cm (15 inches) Part #: CBL-0109L-02 Length: 22 cm (9 inches) Part #: CBL-0110L-02 Length: 18 cm (7 inches) Description: This cable has an iPass (SFF-8087/Mini-SAS) connector (36-pin) at each end. It connects from the HBA to the SAS-216EL backplane.
Appendix D SAS-216EL Backplane Specifications Connecting an External Host Bus Adapter to the Backplane This backplane supports external host bus adapters. In this configuration, the HBA and the backplane are in different physical chassis. This allows a JBOD (Just a Bunch Of Drives) configuration from an existing system.
SC213 Chassis Manaual Supported External HBA to Backplane Cable Use the following cable if your external HBA has an InfiniBand connector. Figure D-15. SAS InfiniBand Cable (CBL-0200L) Cable Name: SAS InfiniBand to Mini SAS X4 1M cable, PBF Part #: CBL-0200L Length: 1 meter Description: This cable has an InfiniBand connector (SFF-8470) on one end and an SFF-8088-1X (26-pin) at the other end.
Appendix D SAS-216EL Backplane Specifications Connecting Multiple Backplanes in a Single Channel Environment This section describes the cables used when cascading from a single HBA. These connections use CBL-0167L internal cables and CBL-0166L external cables.
SC213 Chassis Manaual Single HBA Configuration Cables Single Port Cable Assembly Figure D-17. Single Port Internal Cable (CBL-0167L) Cable Name: SAS EL2/EL1 Backplane Cable (Internal) with 2-port Cascading Cable, 68 cm Part #: CBL-0167L (SFF-8087 to SFF-8088 x1) Ports: Single Placement: Internal cable Description: Internal cable. Connects the backplane to the HBA or external port. Used in single port environments Figure D-18.
Appendix D SAS-216EL Backplane Specifications Connecting Multiple Backplanes in a Dual Channel Environment This section describes the cables used when cascading from dual HBAs. These connections use CBL-0168L internal cables and CBL-0166L external cables.
SC213 Chassis Manaual Dual HBA Configuration Cables Dual Port Cable Assembly Figure D-20. Dual Port Internal Cable (CBL-0168L) Cable Name: SAS Dual-port Cable Assembly, 68/76 cm Part #: CBL-0168L Placement: Internal cable Ports: Dual Description: Internal cascading cable. Connects the backplane to the HBA or external port. Used in dual port environments. Figure D-21.
Appendix D SAS-216EL Backplane Specifications D-14 Supported Cascading Configurations Cascading allows the system to access data at a faster rate by allowing several backplanes to share resources to reduce latency time. The first backplane in a cascaded system requires a motherboard and HBA. Other servers require a power control card with no motherboard and no HBA.
SC213 Chassis Manaual Server System with Single SAS HBA The expanders allow horizontal branching. This configuration also applies to dual ports.
Appendix D SAS-216EL Backplane Specifications Dual SAS HBA and Cascaded Configuration C133 C130 C105 C103 C120 C118 C127 C124 C106 C98 C172 C155 C158 C157 C162 C159 C126 C123 C132 C129 C138 C135 C146 C166 C88 C107 C111 C90 C113 C94 C153 C168 C133 C130 C155 C158 C157 C162 C159 C126 C123 C132 C129 C138 C135 C146 C166 C88 C107 C111 C90 C113 C94 C106 C98 C105 C103 C120 C118 C127 C124 C172 C153 C168 WWN L51 L47 L43 L40 L41 L34 L32 L17 L15 L28 L10 R95 R79 R74 R85 R98 R86 R102
SC213 Chassis Manaual Dual SAS HBA and Cascaded Configuration with Branching C133 C130 C106 C98 C105 C103 C120 C118 C127 C124 C172 C155 C158 C157 C162 C159 C126 C123 C132 C129 C138 C135 C146 C166 C88 C107 C111 C90 C113 C94 C153 C168 C133 C130 C105 C103 C120 C118 C127 C124 C106 C98 C172 C155 C158 C157 C162 C159 C126 C123 C132 C129 C138 C135 C146 C166 C88 C107 C111 C90 C113 C94 C153 C168 L17 L15 L34 L32 L41 L51 L47 L43 L40 WWN L28 L10 R102 C347 R87 C348 R101 R77 R97
Appendix E SAS2-216EL1/EL2 Backplane Specifications Appendix E SAS2-216EL1/EL2 Backplane Specifications Overview of the SAS2-216EL1/EL2 Backplanes The SAS2-216EL1/EL2 model backplanes consists of a SAS2-216EB backplane (A) with one or two SAS2-216EL daughter cards (B and C) mounted on the rear of the backplane. The SAS2-216EL1 model consists of the SAS2-216EB backplane (A) and one SAS2-216EL daughter card (B), mounted on the right-hand side of the backplane.
SC216 Chassis Manual E-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic components. To prevent damage to your system, it is important to handle the backplane very carefully. The following measures are generally sufficient to protect your equipment from ESD. Use a grounded wrist strap designed to prevent static discharge. • • • • • E-2 Touch a grounded metal object before removing a component from the antistatic bag.
Appendix E SAS2-216EL1/EL2 Backplane Specifications E-4 Introduction to the SAS2-216EL1/EL2 Backplane The SAS2-216EL1/EL2 model backplane has been designed to utilize the most up-to-date technology available, providing your system with reliable, high-quality performance. This manual reflects the SAS2-216EL Revision 1.02 backplane, the most current release available at the time of publication. This manual also describes the SAS2-216EL daughter card, Revision 1.
SC216 Chassis Manual Connectors 8 REMOTE_FAN_FAIL2 REMOTE_FAN_FAIL1 A29 A56 B43 B56 BPN-SAS2-216EB REV: 1.
Appendix E SAS2-216EL1/EL2 Backplane Specifications E-6 Front Connector and Pin Definitions 1. Flash Chips The flash chip enhances the backplane memory. 2. Expander Chips This expander chip allows the backplane to support dual ports, cascading, and failover. 3. - 5. SAS Ports The primary and secondary sets of SAS ports provide expander features including cascading and failover. From right to left the ports are Primary 1,2,3 and Secondary 1,2,3. 6.
SC216 Chassis Manual E-7 Jumper Locations and Settings REMOTE_FAN_FAIL1 BUZZER_ENB1 REMOTE_FAN_FAIL2 + 4 BUZZER1 2 +5V A GND GND 1 +12V 4 BPN-SAS2-216EB REV: 1.
Appendix E SAS2-216EL1/EL2 Backplane Specifications General Jumper Settings Jumper Jumper Settings Note PRI_MODE1 Pins 2-3 Factory setting, do not change PRI_MODE2 Pins 2-3 Factory setting do not change REMOTE_FAN_FAIL1 Open: Enable (Default) Closed: Disable Enables / disables the fan speed reporting.
SC216 Chassis Manual FANFAIL1 B56 U2 A1 P1 A15 B1 FAN2 A29 B29 B15 C F2 A43 A56 B43 1 C 4 5V_LED1 BPN-SAS2-216EB REV: 1.
Appendix E SAS2-216EL1/EL2 Backplane Specifications MH7 SAS #J23 SAS #J22 SAS #J21 SAS #J20 SAS #J19 MH6 SAS #J18 SAS #J17 SAS #J16 SAS #J15 SAS #J14 MH4 SAS #J13 SAS #J12 MH3 SAS #J11 SAS #J10 SAS #J9 SAS #J8 SAS #J7 SAS #J6 SAS #J5 SAS #J4 MH1 SAS #J3 SAS #J2 SAS #J1 Front Connectors and LED Indicators SAS #J0 E-8 MH8 MH5 MH2 C65 J3 J2 J6 J8 J7 J9 J10 J16 J17 J18 J19 A C A C FAIL18 ACT18 R40 A FAIL19 7 27 8 8 21 22 21 22 J21 J20 9 33 33 9 21 MH9
SC216 Chassis Manual Front LED Indicators Front LED Hard Drive Activity Failure LED SAS #J0 ACT #0 FAIL #0 SAS #J1 ACT #1 FAIL #1 SAS #J2 ACT #2 FAIL #2 SAS #J3 ACT #3 FAIL #3 SAS #J4 ACT #4 FAIL #4 SAS #J5 ACT #5 FAIL #5 SAS #J6 ACT #6 FAIL #6 SAS #J7 ACT #7 FAIL #7 SAS #J8 ACT #8 FAIL #8 SAS #J9 ACT #9 FAIL #9 SAS #J10 ACT #10 FAIL #10 SAS #J11 ACT #11 FAIL #11 SAS #J12 ACT #12 FAIL #12 SAS #J13 ACT #13 FAIL #13 SAS #J14 ACT #14 FAIL #14 SAS #J15 ACT #15 F
Appendix E SAS2-216EL1/EL2 Backplane Specifications Dual Port and Cascading Configurations E-9 Single and Dual Port Expanders Single Ports SAS2-216EL1 model backplanes have a single-port expander on the daughter card that accesses all of the drives and supports cascading. Port A Primary Ports Expander 1 C C861 15 C862 10 + DESIGNED IN USA 20 25 28 MH2 C858 5 + P_ICE_TDO + + EC1 1 + Rev:1.
SC216 Chassis Manual E-10 Failover The SAS2-216EL2 model backplane has two expanders which enable effective failover and recovery. SAS HBA Y9 J2 BPN-SAS2-216EL U16 A MH2 Rev:1.
Appendix E SAS2-216EL1/EL2 Backplane Specifications E-11 Failover with RAID Cards and Multiple HBAs The SAS-216EL backplane may be configured for failover with multiple HBAs using either RAID controllers or HBAs to acheive failover protection. RAID Controllers: If RAID controllers are used, then the failover is accomplished through port failover on the same RAID card.
SC216 Chassis Manual E-12 Chassis Power Card and Support Cables Chassis Power Card In a cascaded configuration, the first chassis includes a motherboard and at least one Host Bus Adapter. Other servers in this enclosed system must be equipped with a power card. This section describes the supported power card for the SAS2216EL series backplane. For more information, see the Supermicro Web site at http://www.supermicro. com.
Appendix E SAS2-216EL1/EL2 Backplane Specifications Connecting an Internal HBA to the Backplane The following section lists the most common cables used to connect the HBA to the backplane.
SC216 Chassis Manual Cable Name: iPass (Mini-SAS) to iPass (Mini-SAS) Part #: CBL-0108L-02 Length: 39 cm (15 inches) Part #: CBL-0109L-02 Length: 22 cm (9 inches) Part #: CBL-0110L-02 Length: 18 cm (7 inches) Description: This cable has an iPass (SFF-8087/Mini-SAS) connector (36-pin) at each end. It connects from the HBA to the SAS2-216EL model backplane.
Appendix E SAS2-216EL1/EL2 Backplane Specifications Connecting an External HBA to the Backplane This backplane supports external host bus adapters. In this configuration, the HBA and the backplane are in different physical chassis. This allows a JBOD (Just a Bunch Of Drives) configuration from an existing system. Single External Host Bus Adapter 20 25 28 C MH2 C862 15 + 10 1 C861 DESIGNED IN USA C858 5 + + + P_ICE_TDO EC1 EXPDBG1 + L37 Rev:1.
SC216 Chassis Manual Supported External HBA to Backplane Cable Use the following cable if your external HBA has an InfiniBand connector. Figure E-16. SAS InfiniBand Cable (CBL-0200L) Cable Name: SAS InfiniBand to Mini-SAS X4 1M cable, PBF Part #: CBL-0200L Length: 1 meter Description: This cable has an InfiniBand connector (SFF-8470) on one end and an SFF-8088-1X (26-pin) connector at the other end.
Appendix E SAS2-216EL1/EL2 Backplane Specifications Connecting Multiple Backplanes in a Single Channel Environment This section describes the cables used when cascading from a single HBA. These connections use CBL-0167L internal cables and CBL-0166L external cables.
SC216 Chassis Manual Single HBA Configuration Cables Single Port Cable Assembly Figure E-18. Single Port Internal Cable (CBL-0167L) Cable Name: SAS EL2/EL1 Backplane Cable (internal) with 2-port Cascading Cable, 68 cm Part #: CBL-0167L (SFF-8087 to SFF-8088 x1) Ports: Single Placement: Internal cable Description: Internal cable. Connects the backplane to the HBA or external port. Used in single port environments Figure E-19.
Appendix E SAS2-216EL1/EL2 Backplane Specifications Connecting Multiple Backplanes in a Dual Channel Environment This section describes the cables used when cascading from dual HBAs. These connections use CBL-0168L internal cables and CBL-0166L external cables.
SC216 Chassis Manual Dual HBA Configuration Cables Dual Port Cable Assembly Figure E-21. Dual Port Internal Cable (CBL-0168L) Cable Name: SAS Dual-port Cable Assembly, 68/76 cm Part #: CBL-0168L Placement: Internal cable Ports: Dual Description: Internal cascading cable. Connects the backplane to the host bus adapter or external port. Used in dual port environments. Figure E-22.
Appendix E SAS2-216EL1/EL2 Backplane Specifications E-13 Supported Cascading Configurations Cascading allows the system to access data at a faster rate by allowing several backplanes to share resources to reduce latency time. The first backplane in a cascaded system requires a motherboard and an HBA. Other servers require a power control card with no motherboard and no HBA. For more information, specific chassis manuals are available at www.supermicro.com.
SC216 Chassis Manual Server System with Single SAS HBA The expanders allow horizontal branching. This configuration also applies to dual ports.
Appendix E SAS2-216EL1/EL2 Backplane Specifications Dual SAS HBA and Cascaded Configuration A C A 1 1 1 + R159 PRI_MODE2 R161 PRI_MODE1 R158 R157 SMART_UART BCA236 BCA234 3 3 C2926 4 SAN JOSE,CA 95131 PROJECT NAME: TEL:408-503-8000 FAX:408-503-8008 BPN-SAS2-216EL PRI_J2 A PRI_J1 MDIOINTERFACE SUPER TOLERANCES DECIMAL ANGLE X .1 30 XX .03 MACH FINISH XXX.010 1.
SC216 Chassis Manual Dual SAS HBA and Cascaded Configuration with Branching Port B Ex.
Appendix F SAS3-216A Backplane Specifications Appendix F SAS3-216A Backplane Specifications F-1 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic components. To prevent damage to your system, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. • • • Use a grounded wrist strap designed to prevent static discharge. Touch a grounded metal object before removing a component from the antistatic bag.
SC216 Chassis Manual F-3 A Note to Users All images and layouts in this user's guide are based upon the latest PCB revision available at the time of publishing. The card you have received may not look exactly the same as the graphics in this manual.
Appendix F SAS3-216A Backplane Specifications F-5 Front Connector and Pin Definitions 1. Upgrade Connectors The upgrade connectors are used for manufacturer diagnostic purposes only. 3. Backplane Main Power Connectors Backplane Main Power 4-Pin Connector The 4-pin connectors, designated JP10, JP13, JP46, JP48, JP109 and JP110 provide power to the backplane. See the table on the right for pin definitions. Pin# Definition +12V 1 2 and 3 Ground 4 4. - 9.
SC216 Chassis Manual F-7 Rear Components, Connectors and LED Indicators U38 U18 U64 CG1 U63 U1 2 1 6 5 U66 CG2 R162 C322 J44 J36 J20 J11 J45 J34 J19 J9 J43 J31 J18 J4 J33 J28 J17 J3 J37 J27 J15 J2 J35 J21 J13 J1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S1 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S8 S7 S
Appendix F SAS3-216A Backplane Specifications Rear LED Indicators Hard Drive Activity Failure LED SAS #0 Rear LED D12 D5 SAS #1 D22 D23 SAS #2 D40 D37 SAS #3 D102 D107 SAS #4 D13 D6 SAS #5 D24 D29 SAS #6 D41 D38 SAS #7 D104 D108 SAS #8 D14 D7 SAS #9 D25 D30 SAS #10 D42 D39 SAS #11 D106 D109 SAS #12 D15 D8 SAS #13 D26 D31 SAS #14 D87 D88 SAS #15 D111 D110 SAS #16 D18 D19 SAS #17 D27 D32 SAS #18 D100 D103 SAS #19 D118 D119 SAS #20 D21 D20 SAS
SC216 Chassis Manual Notes F-6
Appendix G SAS3-216EL Backplane Specifications Appendix G BPN-SAS3-216EL Backplane Specifications G-1 Overview of the SAS3-216EL1/EL2 Backplanes The BPN-SAS3-216EL1/EL2 model backplanes consists of a BPN-SAS3-216EB backplane (X) with one or two BPN-SAS3-216EL daughter cards (Y and Z) mounted on the rear of the backplane. The BPN-SAS3-216EL1 model consists of the BPN-SAS3-216EB backplane (X) and one BPN-SAS3-216EL primary daughter card (Y), mounted on the right-hand side of the backplane.
SC216 Chassis Manaual G-2 ESD Safety Guidelines Electrostatic Discharge (ESD) can damage electronic components. To prevent damage to your system, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. • • • • • Use a grounded wrist strap designed to prevent static discharge. Touch a grounded metal object before removing a component from the antistatic bag.
Appendix G SAS3-216EL Backplane Specifications This manual also describes the BPN-SAS3-216EL daughter card, Revision 1.01, the most current release available at the time of publication. Always refer to the Supermicro Web site at www.supermicro.com for the latest updates, compatible parts and supported configurations.
SC216 Chassis Manaual G-7 Front Connector and Pin Definitions 1. Flash Chips The flash chip enhances the backplane memory. 2. Expander Chips This expander chip allows the backplane to support dual ports, cascading, and failover. 3. UART Connector The UART connector is designated UART and J5. It is used for manufacturer's diagnostic purposes only. 4. SDB Connector The SDB connector is designated SDB and J10. It is the debug connector and is used for manufacturer's diagnostic purposes only. 5.
Appendix G SAS3-216EL Backplane Specifications SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS SAS #J0 #J1 #J2 #J3 #J4 #J5 #J6 #J7 #J8 #J9 #J10 #J11 #J12 #J13 #J14 #J15 #J16 #J17 #J18 #J19 #J20 #J21 #J22 #J23 G-8 Front Connectors and LED Indicators 4 3 2 1 1 4 1 4 3 2 4 1 1 J0 J1 J2 J3 J4 J5 J9 J8 J13 J12 J23 S1 S1 S1 C4 C10 S7 S8 S7 S8 C29 C36 S1 C28 C32 S7 S8 C30 C31 S7 1 S8 C15 C16 S14 P1 S14 P1 P15 P15 S14 P1 P1 S14
SC216 Chassis Manaual Front LED Indicators Front LED Hard Drive Activity Failure LED SAS #J0 ACT #0 FAIL #0 SAS #J1 ACT #1 FAIL #1 SAS #J2 ACT #2 FAIL #2 SAS #J3 ACT #3 FAIL #3 SAS #J4 ACT #4 FAIL #4 SAS #J5 ACT #5 FAIL #5 SAS #J6 ACT #6 FAIL #6 SAS #J7 ACT #7 FAIL #7 SAS #J8 ACT #8 FAIL #8 SAS #J9 ACT #9 FAIL #9 SAS #J10 ACT #10 FAIL #10 SAS #J11 ACT #11 FAIL #11 SAS #J12 ACT #12 FAIL #12 SAS #J13 ACT #13 FAIL #13 SAS #J14 ACT #14 FAIL #14 SAS #J15 ACT #15
Appendix G SAS3-216EL Backplane Specifications G-9 Single and Dual Port Expanders Single Ports BPN-SAS3-216EL1 model backplanes have a single-port expander on the daughter card that accesses all of the drives and supports cascading. Port A Primary Ports Expander 1 From HBA or Higher Backplane P7 P8 U2 U15 BPN-SAS3-216EL C1 C2 REV:1.
SC216 Chassis Manaual G-10 Failover The BPN-SAS3-216EL2 model backplane has two expanders which enable effective failover and recovery. SAS HBA Single Host Bus Adapter P7 P8 U2 U15 BPN-SAS3-216EL C1 C2 REV:1.
Appendix G SAS3-216EL Backplane Specifications G-11 Failover with RAID Cards and Multiple HBAs The BPN-SAS3-216EL backplane may be configured for failover with multiple HBAs using either RAID controllers or HBAs to acheive failover protection. RAID Controllers: If RAID controllers are used, then the failover is accomplished through port failover on the same RAID card.
SC216 Chassis Manaual G-12 Chassis Control Card and Support Cables Chassis Control Card In a cascaded configuration, the first chassis includes a motherboard and at least one host bus adapter (HBA). Other servers in this enclosed system must be equipped with a control card. This section describes the supported control card for the BPN-SAS3-216EL series backplane.
Appendix G SAS3-216EL Backplane Specifications Connecting an Internal HBA to the Backplane The following section lists the most common cables used to connect the HBA to the backplane. HBA BPN-SAS3-216EL C1 C2 REV:1.
SC216 Chassis Manaual Cable Name: Internal iPass (Mini-SAS) to HD (Mini-SAS) Part #: CBL-SAST-0508-01 Length: 50 cm (19 inches) Part #: CBL-SAST-0507-01 Length: 80 cm (31 inches) Description: This cable has an iPass (SFF-8087/Mini-SAS) connector (36-pin) at one end and a Mini-SAS HD (SFF-8643) connector at the other end. It connects from the SAS2 HBA to the BPN-SAS3-216EL model backplane.
Appendix G SAS3-216EL Backplane Specifications Connecting an External HBA to the Backplane This backplane supports external host bus adapters. In this configuration, the HBA and the backplane are in different physical chassis. This allows a JBOD (Just a Bunch Of Drives) configuration from an existing system. Single External Host Bus Adapter P7 P8 U2 U15 BPN-SAS3-216EL C1 C2 REV:1.
SC216 Chassis Manaual Connecting Multiple Backplanes in a Single Channel Environment This section describes the cables used when cascading from a single HBA. These connections use CBL-SAST-0531 internal cables and CBL-SAST-0573 external cables. P7 P8 U2 U15 BPN-SAS3-216EL C1 C2 REV:1.
Appendix G SAS3-216EL Backplane Specifications Single HBA Configuration Cables Figure G-17 External Mini-SAS HD to External Mini-SAS HD Cable Cable Name: 1 Meter External Mini-SAS HD to External Mini-SAS HD Cable Part #: CBL-SAST-0573 Ports: Single Placement: External Cable Description: External cascading cable, connects ports between servers and JBODs. Figure G-18.
SC216 Chassis Manaual Connecting Multiple Backplanes in a Dual Channel Environment This section describes the cables used when cascading from dual HBAs. These connections use CBL-SAST-0531 internal cables and CBL-SAST-0573 external cables. Port B Expander 2 Port A Expander 1 P7 P8 U2 U15 BPN-SAS3-216EL P7 P8 U2 U15 BPN-SAS3-216EL C1 C2 REV:1.
Appendix G SAS3-216EL Backplane Specifications G-13 Supported Cascading Configurations Cascading allows the system to access data at a faster rate by allowing several backplanes to share resources to reduce latency time. The first backplane in a cascaded system requires a motherboard and an HBA. Other servers require a chassis control card with no motherboard and no HBA. For more information, specific chassis manuals are available at www.supermicro.com. P7 P8 U2 U15 BPN-SAS3-216EL C1 C2 REV:1.
SC216 Chassis Manaual Dual SAS HBA and Cascaded Configuration P7 P8 U2 U15 BPN-SAS3-216EL C1 C2 REV:1.
Appendix G SAS3-216EL Backplane Specifications Notes G-19
SC216 Chassis Manaual Disclaimer (cont.) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
