User's Manual (1.0b)

SC216 Chassis Manual
B-2
1200 Models, such as SC216E16-R1200LPB
1200W
MFR Part # PWS-1K21P-1R with PDB
AC Input
100 - 140V, 50 - 60Hz, 8 - 11.5 Amp
180 - 240V, 50 - 60Hz, 5.5 - 8 Amp
DC Output +12V
1000W, 83 Amp @ 100-140V
1200W, 100 Amp @ 180-240V
+5 Standby 4 Amp
+5V 45 Amp
+3.3V 24 Amp
-12V 0.6 Amp
900 Models, such as SC216A-R900LPB
900W
MFR Part # PWS-902-1R with PDB
AC Input 100 - 240V, 60-50Hz, 11-4.5 Amp
DC Output +12V 75 Amp
+5V standby 4 Amp
+5V 45 Amp
+3.3V 24 Amp
-12V 0.6 Amp
SC216E16-R1010LPB
1010W
MFR Part # PWS-1K11P-1R
DC Input
850W: -36--42V; 30-25Amp
1010W: -43 -76V; 30-17Amp
DC Output +12V
850W, 70 Amp
1010W, 83 Amp
+5 Standby 4 Amp
+5V 50 Amp
+3.3V 30 Amp
-12V 0.6 Amp
