22” WIDESCREEN LED TV MODEL NO.: SC-2211 USER MANUAL Please read this manual carefully before using, and keep it for future reference.
IMPORTANT INSTRUCTIONS SAFETY INSTRUCTIONS WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR SERIOUS PERSONAL INJURY: ● This product shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. ● Situate this product away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.
● Connect this product to the power outlet which has protective earth connection. CAUTION- TO REDUCE THE RISK OR PERSONAL INJURY OR PRODUCT/PROPERTY DAMAGE: ● This product is intended solely for non-commercial, non-industrial, personal use as a television. Do not use this product for any other purpose. ● Do not subject the product to violent shocks, extreme temperatures, or lengthy periods of direct sunlight. ● Keep the product away from magnetic objects, motors, and transformers.
TABLE OF CONTENTS GETTING STARTED IMPORTANT INSTRUCTIONS...................................................................................1-2 ACCESSORIES……….......................................................................................................2 FEATURES....................................................................................................................4 GENERAL PARTS..............................................................................................................
FEATURES 22" LED DISPLAY This player has a built-in 22” LED display to provide clear vision and low radiation.
GENERAL PARTS MAIN UNIT Front View Top View 1. LED display screen 2. Remote control sensor 3. Power indicator- In standby mode the indicator light is red; when switching on the unit the indicator light is blue color. 4. Stand holder 5. POWER button- To turn the TV ON/OFF. 6. SOURCE button- To select the input source. 7. MENU button- To enter menu setting page. 8. CH +/- button- To select next/previous channel or move up/down. 9. VOL +/- button- To increase/decrease the volume level or move left/right.
GENERAL PARTS Back View 1. Power input terminal 2. USB input terminal- For MUSIC/PHOTO playback. 3. HDMI input terminal 4. VGA input terminal 5. PC AUDIO input terminal 6. YPbPr input terminals 7. RF input terminal- To connect the external antenna. 8. EARPHONE output terminal 9. CVBS and AUDIO R/L input terminals 10. COAXIAL output terminal 11.
REMOTE CONTROL 1. POWER: Pres to enable standby mode; press again to turn on. 2. NUMBER BUTTONS (0-9): To input the number information, such as channel number and so on. 3. -/--: To select additional channels (digital) being broadcast by the same station. For example, to select channel “15-3”, press “1” and “5”, then press “-/--” and “3”. 4. GREEN button 5. RED button 6. VOL +/-: Press VOL+ button to increase the volume, or press VOL- button to decrease the volume. 7.
REMOTE CONTROL 16. MUTE: To mute the sound. 17. : To return to previous channel. 18. YELLOW button 19. BLUE button 20. CH+/-: Press CH+ button to play next channel, or press CH- button to play previous channel. 21. INFO: To display current program information. 22. SOURCE: To switch the input source. 23. SOUND: To switch the sound mode in TV mode. 24. ENTER: To confirm a selection. 25. EXIT: To exit menu page. 26. AUTO: To adjust the screen automatically (in PC mode). 27.
REMOTE CONTROL PREPARATION BATTERY INSTALLATION Install the batteries as the following pictures. Be sure + and – terminals are positioned as indicated in the battery compartment (Fig1). SERVICE LIFE OF BATTERIES - The batteries normally last for one year although this depends on how often the remote control is used. - If the remote control fails to work even when it is operated near the player, replace the batteries. - Use two size AAA dry batteries.
BASIC CONNECTION ● Ensure all the cables are disconnected from the main unit before connecting to AC power source. ● Read through the instructions before connecting other equipments. CONNECTING TO AC POWER SOURCE Main unit To power outlet AC Adaptor CONNECT EXTERNAL ANTENNA TO UNIT Install external antenna into antenna jack for best picture.
COMPOSITE AV CONNECTION For basic connection, use the composite Audio L/R (white/red) and CVBS cable to connect the unit with other devices.
HDMI CONNECTION HDMI cable (Optional) Use HDMI cable to connect the unit with other devices to receive high-definition multimedia signal. Back of DVD/VCR PC/VGA CONNECTION Audio cable (Optional) VGA cable (Optional) Back of DVR or PC Use VGA cable and Audio cable to connect the unit with TV or PC, and use this product as a monitor.
CONNECTING TO USB MEMORY DEVICE USB Memory Device (Optional) COAXIAL OUT CONNECTION Use coaxial cable to connect the unit with amplifier or other audio decoding devices for coaxial audio signal output.
MAKE SURE ALL THE EQUIPMENTS AND POWER ADAPTOR ARE CONNECTED PROPERLY AND THE UNIT IS SET IN CORRECT MODE BEFORE OPERATING. BASIC OPERATIONS - Press POWER button on the unit or remote control to power ON the unit (indicator will glow blue); press it again to power OFF (standby mode) the unit (indicator will glow red). - Press SOURCE button on the unit or remote control to switch the unit to TV mode. SELECT DESIRED PROGRAM 1. Press CH+ button to play next channel. 2.
SOUND MODE - Press SOUND button on remote control repeatedly to select desired sound mode. Available options: User, Music, Movie, Standard. CLOSED CAPTION - Press CC button on remote control repeatedly to set the CLOSED CAPTION function On or Off. SLEEP TIMER SETTING - Press SLEEP button on remote control repeatedly to select desired sleep time. Available options: Off, 5 min, 10 min, 15 min, 30 min, 45 min, 60 min, 90 min, 120 min, 180 min, 240 min.
FREEZE FUNCTION - During normal playing, press FREEZE button on remote control to hold the picture, and press it again to resume normal playing. USB OPERATION - Before following operations, insert a USB memory device first, which contains Photo and Music files. - Press SOURCE button on the unit or remote control to set the unit in USB mode. - Press LEFT/RIGHT navigation button to select Photo/Music in the main menu. - Press UP/DOWN navigation button to select preferred file.
During normal playing: - Press UP/DOWN navigation button to play previous/next photo. - Press LEFT/RIGHT navigation button to rotate a photo counterclockwise/clockwise. - Press EXIT button to return to file selecting page. Music Playback - Select Music item in the main menu. - Press UP/DOWN navigation button to select preferred folder/file and press ENTER button to enter a folder or play selected file. During normal playing: - Press INFO button to display/hide the tool bar.
MAIN MENU ● The unit contains different setting menus. Once the initial programming is entered, it will be remained in the memory until change, and the unit can always be operated under the same conditions. ● The settings will be remained in the memory until the settings are changed, even after setting the player to standby mode. Common procedure for initial settings ● ● ● ● ● ● ● ● Press MENU button on the unit or remote control to display the main menu.
1. PICTURE 1.1 Picture Mode Available options: User, Standard, Dynamic, Mild. 1.2 Contrast The value of Contrast can be adjusted from 0-100. 1.3 Brightness The value of Brightness can be adjusted from 0-100. 1.4 Color The value of Color can be adjusted from 0-100. 1.5 Tint The value of Tint can be adjusted from -50 to 50. NOTE: Tint is adjustable only in certain TV system. 1.6 Sharpness The value of Sharpness can be adjusted from 0-100.
2. AUDIO 2.1 Sound Mode Available options: User, Music, Movie, Standard. 2.2 Bass The value of Bass can be adjusted from 0-100. 2.3 Treble The value of Treble can be adjusted from 0-100. 2.4 Balance The value of Balance can be adjusted from -50 to 50. NOTE: If the value of Bass, Treble, or Balance has been changed, the sound mode will turn to User automatically. 2.5 Surround This item is used to turn on/off Sound Surround function. 2.6 AVC (Auto Volume Control) Available options: On, Off. 2.
3. TIME 3.1 Sleep Timer Available options: Off, 5 min, 10 min, 15 min, 30 min, 45 min, 60 min, 90 min, 120 min, 180 min, 240 min. 3.2 Time Zone Available options: Eastern, Central, Mountain, Pacific, Alaska, Hawaii, Atlantic. 3.3 Daylight Saving Time Available options: On, Off. NOTE: This item is adjustable only for digital programs. 3.4 Clock When an available digital program is present, this unit will get Date and Time information automatically from current program. And it’s not user adjustable. 4.
4.1 Menu Language This item is used to select preferred OSD menu language. 4.2 Transparency This item is used to turn on/off Transparent OSD menu. 4.3 Zoom Mode This item is used to select preferred zoom mode of display screen. Available options: Normal, Wide, Zoom, Cinema. NOTE: The available zoom mode may be different for different input source. 4.4 Noise Reduction Available options: Off, Weak, Middle, Strong. 4.5 Advanced This item is adjustable only for PC/VGA input signal. 4.6 Closed Caption 4.
FG Color Available options: Default, White, Red, Green, Blue, Yellow, Magenta, Cyan. BG Color Available options: Default, Black, Red, Green, Blue, Yellow, Magenta, Cyan. FG Opacity Available options: Default, Solid, Flashing, Translucent, Transparent. BG Opacity Available options: Default, Solid, Flashing, Translucent, Transparent. 4.7 DLC This item is used to turn on/off Dynamic Luminance Control. 4.8 Restore Default This item is used to reset to factory default settings. 5. CHANNEL 5.
5.22 Start to Scan - Press RIGHT or ENTER button to start auto scanning. - Press MENU or EXIT button to exit auto channel searching. 5.3 Favorite - Press RIGHT or ENTER button to enter it. - Press UP or DOWN navigation button to select preferred channel. - Press ENTER button to label the selected channel as a favorite one or not. 5.4 Show/Hide - Press RIGHT or ENTER button to enter it. - Press UP or DOWN navigation button to select preferred channel.
AV AND OTHER MODES - Press SOURCE button on the unit or remote control to select desired input source. - For PICTURE, AUDIO, TIME and SETUP menus, please refer to the menu operations of TV mode. PC/VGA MODE - Press SOURCE button on the unit or remote control to set the unit in VGA mode. - Press MENU button to display the main menu and select Setup item. Then press DOWN navigation button to enter Setup menu page.
WALL MOUNTING WARNING: ● Contact a professional for assistance when wall mounting your TV. We are not responsible for any damage to the product or injury to yourself, if you mount the TV on your own. ● Do not wall mount the TV while TV is turned on or connected to power. It may cause personal injury due to electric shock. ● Use standard M4*10mm screws (4 pieces; not included) to mount this TV.
STAND INSTALLATION Your TV may be packaged with the Stand and the Cabinet separated. Before enjoying this TV, please carry out the Stand Installation according to the instructions below. Step 1 Place the TV faced down on a soft cloth or cushion to prevent the panel from being damaged. Step 2 Align the stand and the bottom of this TV. Step 3 Tighten the included screws with a screw driver. NOTES: - Unplug the power plug first when installing or removing the TV Stand.
MAINTENANCE ● Be sure to press POWER button to set the player to the standby mode and disconnect the power plug before maintaining the player. ● Wipe the player with a dry, soft cloth. ● If the surface is extremely dirty, wipe clean with a cloth which has been dipped in a weak soap-water solution and wrung out thoroughly, and then wipe again with a dry cloth. ● Never use alcohol, benzene, thinner, cleaning fluid or other chemicals. And do not use compressed air to remove dust.
GENERAL TROUBLESHOOTING Check the following points before assuming malfunctions of this unit: Symptom No power. No picture. ● No sound. ● Distorted sound. No operations can be performed with the remote control unit. No key operation (by the main unit and/or the remote control unit) is effective. Symptom(TV) No or poor picture. No sound or poor sound. Noise or other interference Remedy Insert the power plug securely into the power outlet. Ensure that the equipment is connected properly.
