User's Manual

®
User Manual
Package Contents:
▪ M2M signal booster
▪ Magnetic mount antenna
▪ RG58 extension cable
▪ AC power supply
▪ Velcro and screw mounting kit
▪ User manual(this document)
FCC Information
SureCall M2M Signal Booster
Upli nk Freq. Ra nge (MHz) 1850-1910 824-849
Downl ink Freq. Range
1930-1990 869-894
Supported sta nda rds
Input/Output i mpeda nce
Max ga in
Nois e figure
VSWR
AC power transformer
Max output power
Cable
RF connectors
Power cons umpon
Dimensi ons
We ight
FCC ID (USA)
0.57 lb (260g)
RSNM2M
110VAC,60Hz IN / 5-12V DC OUT
1W EIRP
RG58
SMA Fema le (both ends )
4.72”x2.72”x0.98” (120mm x 69mm x 25mm)
M2M Signal Booster Specifications
CDMA, GSM, EDVO,EDGE, HSPA,LTE
50Ω
15dB
5dB
≤2.0
4. Products sold by Cellphone-Mate, Inc. shall not be considered defective or non-conforming to the
Buyers’ order if they satisfactorily fulfill the performance requirements that were published in the
product specification literature, or in accordance with samples provided by Cellphone-Mate, Inc. This
warranty shall not apply to any products or parts thereof which have been subject to accident,
negligence, alteration, abuse, or misuse. Cellphone-Mate, Inc. makes no warranty whatsoever in
respect to accessories or parts not supplied by it.
5. EXCEPT AS EXPRESSLY SET FORTH HEREIN, THERE ARE NO WARRANTIES, CONDITION
GUARANTEES OR REPRESENTATIONS AS TO MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE OR OTHER WARRANTIES, CONDITIONS, GUARANTEES OR REPRESENTATIONS, WHETHER
EXPRESSED OR IMPLIED, IN LAW OR IN FACT, ORAL OR IN WRITING. CELLPHONE-MATE, INC.’S
AGGREGATE LIABILITY IN DAMAGES OR OTHERWISE SHALL NOT EXCEED THE PAYMENT, IF ANY,
RECEIVED BY CELLPHONE-MATE, INC. FOR THE UNIT OF PRODUCT OR SERVICE FURNISHED OR TO BE
FURNISHED, AS THE CASE MAY BE, WHICH IS THE SUBJECT OF CLAIM OR DISPUTE. IN NO EVENT
SHALL CELLPHONE-MATE, INC. BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES,
HOWSOEVER CAUSED.
6. All matters regarding this warranty shall be interpreted in accordance with the laws of the State of
California and any controversy that cannot be settled directly shall be settled by arbitration in
California in accordance with the rules then prevailing of the American Arbitration Association, and
judgment upon the award rendered may be entered in any court having jurisdiction thereof.
7. If one or more provisions provided herein are held to be invalid or unenforceable under applicable
law, then such provision shall be ineffective and excluded to the extent of such invalidity
or unenforceability without affecting in any way the remaining provisions hereof.
CM-M2M 201401 v1.1
888.365.MATE (6283) phone - [phone] fax
www.surecall.com | Fremont, CA 94538 (USA)
<10W
This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have
your provider’s consent. Most wireless providers consent to the use of signal boosters.
Some providers may not consent to the use of this device on their network. If you are
unsure, contact your provider.
You MUST operate this device with approved antennas and cables as specified by the
manufacturer. Antennas MUST be installed at least 20 cm (8 Inches) from any person.
You MUST cease operang this device immediately if requested by the FCC or a
licensed wireless service provider.
WARNING. E911 locaon informaon may not be provided or may be inaccurate for
calls served by using this device.
* Not intended for Mobile Applications *
