On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 Thank you for selecting this uninterruptible power supply (UPS). It provides you with protection for connected equipment.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 2. Important Safety Instructions (SAVE THESE INSTRUCTIONS) CAUTION! (UPS having Internal Batteries): Risk of electrical shock – Hazardous live parts inside this unit are energized from the battery supply even when the input AC power is disconnected. CAUTION! (No User serviceable Parts): Risk of electrical shock, do not remove cover. No user serviceable parts inside.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 CAUTION The unit has a dangerous amount of voltage. If the UPS indicator is on, the unit’s outlets may have a dangerous amount of voltage even when not plugged into the wall outlet because the battery may continue to supply power.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 3. Introduction The information provided in this manual covers single phase SX-BDL-1500, SX-BDL-2000, UPS-1500-OL, UPS2000-OL, UPS-3000-OL uninterruptible power systems, their basic functions, operating procedures, options available and emergency situations. It also includes information on how to ship, store, handle, and install the equipment.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 Figure 1 – Block Diagram Diagnostic Tests When the UPS is started, a diagnostic test is automatically executed, checking the electronics and batteries, reporting any problems on the LCD display. A diagnostic test can also be performed manually from the front panel at any time. 5. System Configuration The UPS device and the internal batteries make up the system.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 SX-BDL-1500/UPS-1500-OL REAR VIEW SX-BDL-2000/UPS-2000-OL REAR VIEW © SurgeX | Technical Support: 800-645-9721 | surgex.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 UPS-3000-OL REAR VIEW LED Description The UPS has three LED’s on the front control panel. These LED’s allow the user to quickly understand if any action is needed. Red LED If this LED is illuminated it indicates a fault and the UPS will have no output.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 LED Descriptions There are four lines of information in the LCD display. Each line provides specific information related to the unit status and/or operation. Line information will be described from top to bottom with the top being line one.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 SNMP Communications Option The UPS provides an intelligent slot for internal or external network card. This special intelligent network card can be compatible with popular software and hardware found on the web and in operating systems. It can support operating systems such as HP Open View, IBM Netview, SUN Netmanager, etc. This enables the UPS to provide instant UPS and power information over the network.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 7. Hardware Installation Guide Inspect the UPS upon receipt. The packaging is recyclable; keep it for reuse or dispose of properly. A. Safety Information Information presented here is vital to all personnel. Please read all Safety information. B. Storage and Transportation Please handle the UPS and associated equipment with extreme caution since a high amount of energy is contained in the batteries.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 D. Rack-Mount Accessories Standard Brackets 2U 5 IN 1 BRACKET FOR SX-BDL-1500 / UPS-1500-OL 3U 5 IN 1 BRACKET FOR SX-BDL-2000/UPS-2000-OL, UPS-3000-OL 19” Cabinet Ear Installation SX-BDL-1500 / UPS-1500-OL Use M4 x 6 screws on places marked with a letter A SX-BDL-2000 / UPS-2000-OL / UPS-3000-OL Use M4 x 6 screws on places marked with letter A © SurgeX | Technical Support: 800-645-9721 | surgex.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 Vertical Installation Steps SX-BDL-1500 / UPS-1500-OL Use M4 x 6 screws on places marked with letter A SX-BDL-2000 / UPS-2000-OL / UPS-3000-OL Use M4 x 6 screws on places marked with letter A Wall-Mounted Installation Steps SX-BDL-1500 / UPS-1500-OL Use M5 x 12 screws on places marked with letter B SX-BDL-2000 / UPS-2000-OL / UPS-3000-OL: Use M5 x 12 screws on places marked with letter B © SurgeX | Technic
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 19” Rack Mount Using 5 in 1 Bracket SX-BDL-1500 / UPS-1500-OL Use M5 x 12 screws on places marked with letter B SX-BDL-2000 / UPS-2000-OL / UPS-3000-OL Use M5 x 12 screws on places marked with letter B © SurgeX | Technical Support: 800-645-9721 | surgex.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 8. Installation of Rack Mount and Accessories A. 2U EAR FOR UPS OR BPX MOUNTING IN CABINET B. EXPANDABLE RAIL FOR UPS OR BPX MOUNTING IN CABINET C. MOVEABLE NUT FOR MOUNTING RAIL KIT IN CABINET © SurgeX | Technical Support: 800-645-9721 | surgex.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 D. UPS FRONT VIEW AFTER INSTALLING 2U EARS E. ASSEMBLE THE RAIL ONTO THE CABINET U-BAR WITH SCREWS AT FRONT & BACK USING MOVABLE NUTS © SurgeX | Technical Support: 800-645-9721 | surgex.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 F. PUSH THE UPS OR BPX INTO THE CABINET VIA THE RAIL FROM THE FRONT G. ATTACHE UPS OR BPX EAR ONTO CABINET U-BAR WITH SCREWS ON BOTH LEFT & RIGHT SIDES NOTE: Any external Battery Packs must be installed next to or under the UPS. Please refer to Appendix A: Battery Pack User Guide for more information when installing these. © SurgeX | Technical Support: 800-645-9721 | surgex.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 9. Initial Connection and Startup Ensure that the UPS and optional battery packs are mounted correctly, and the UPS is disconnected from input power before proceeding. A. Connections Installation 1.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 5. Connect to Utility Power For UPS-1500-OL, UPS-2000-OL, UPS-3000-OL Models only: (For SX-BDL-1500 and SX-BDL-2000 connection installation, skip to instructions below) A. Plug the UPS into a 3-wire grounded receptacle of proper size per UPS specifications.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 B. Startup Installation 1. Start and configure the UPS • On/Off Button Function Button Inquiry Button Press and hold the ON/OFF button for more than 3 seconds to turn on the UPS. The UPS should now start its inspection of the internal functions, main synchronization, and inverter startup. Then power should start to be supplied via the outlets.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 4. After charging is complete, connect the loads to the UPS while monitoring the load levels via the UPS LCD or via the software. • Do not connect any devices that have the possibility of overloading the UPS. Refer to the Troubleshooting section and/or Technical Support with any problems during setup. 10.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 Self Test Operation Please refer to the three operating buttons on the front panel of the UPS. • Confirm the UPS is in “Utility Mode”. • Press and hold the “Function” button for a minimum of two seconds. The self-test will last for 10 seconds, during this time the LED’s will be lit in a sequential, repeating fashion Audible Alarm silence in DC Mode or Fault Mode • • 11.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 Slide the plastic cover to the right Remove the M5 x 10 screws on the right side Remove plastic front cover Locate the battery tray on the right front side of the UPS Remove (4) M4x6 screws marked with letter A. Remove the battery tray from the UPS. © SurgeX | Technical Support: 800-645-9721 | surgex.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 12. Troubleshooting Issue The “Input” letters in the second row of the LCD are flashing The “Input” letters in the second row of the LCD are flashing Battery Indicator Flashing Audible Alarm Two Beeps per second at startup for 8 total seconds Alarm Description The Input Voltage or frequency may be beyond the normal acceptable range.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 13. LCD Fault Codes BUS FAULT INV FAULT OVERHEAT OP SHORT OVERLOAD FAN FAULT CHARGE FAULT BAT OVER BYP MODE 62 61、63 33 / / 36 07 11 © SurgeX | Technical Support: 800-645-9721 | surgex.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 14. Specifications Voltage SX-BDL-1500 SX-BDL-2000 UPS-3000-OL UPS-1500-OL UPS-2000-OL 120 VAC (80 - 138V at 100% load) 60-138V at 40% load Capacity VA (W) 1500 VA (1050 W) Frequency 60 Hz Power Factor ≥ 0.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 Dimensions SX-BDL-1500 UPS-1500-OL W x D x H (inches) Unit Dimensions 17.3" x 25.6" x 3.4" 17.3" x 21.7" x 5.2" Shipping Dimensions 22.3" x 31.4" x 9.2" 22.3" x 27.4" x 11.0" Unit Weight 57.3 lbs 79.4 lbs 81.6 lbs Shipping Weight 68.4 lbs 91.5 lbs 93.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 INPUT CHARGER OUTPUT BATTERY PHYSICAL EXTENDED BATTERY PACK MODELS Voltage UPS-BPX 1500 UPS-BPX-2000 120 VAC AC Current 2.2A Frequency 50/60 Hz auto sensing Input Protection circuit breaker DC Voltage 55.0 ±0.5V DC Current 2.5A (max) Output Protection Fuse Battery Type sealed, non-spillable, maintenance free, valve regulated, lead acid Extended Battery Packs EBP2 2 strings of (4) 12V 7.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 15. Appendix A: Extended Battery Pack (EBP) User Guide Estimated Run Time for UPS with Extended Battery Packs MODEL SX-BDL-1500 UPS-1500-OL SX-BDL-2000 UPS-2000-OL LOAD VA WATTS RUNTIME FOR QTY OF EXTENDED BATTERY PACKS IN MIN.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 Extended Battery Pack 2 for SX-BDL-1500 / UPS-15000-OL Extended Battery Pack 3 for SX-BDL-2000 / UPS-2000-OL / UPS-3000-OL df BATTERY FRONT PANEL © SurgeX | Technical Support: 800-645-9721 | surgex.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 LED Description The Charging LED GREEN indicates that the battery charger in the Extended Battery Pack is charging normally with the AC power cord attached to the Battery pack. The Battery Test LED GREEN indicates that the DC output of the Extended Battery Pack (EBP) is normal.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 2. The EBP’s use a cable shipped with each EBP to “daisy chain” together additional EBP’s to the first EBP being connected to the UPS in the appropriately labeled connector, or for connecting the first EBP to the UPS. 3. The AC input cord is for connecting AC utility to operate the Charger contained in each EBP 4.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 Extended Battery Pack Installation CAUTION: Extended Battery Pack (EBP) Installation should be performed by qualified service personnel. 1. 2. 3. 4. 5. Verify that the DC circuit breaker on the rear panel of the EBP is in the OFF position. Turn the UPS OFF and disconnect the UPS Input Cord from the AC wall outlet. Remove the EBP connector cover from the UPS rear panel.
On-Line UPS User Manual Models: UPS-1500-OL, UPS-2000-OL, UPS-3000-OL SX-BDL-1500, SX-BDL-2000 Extended Battery Pack Q&A 1. Which EBP’s do I connect to an AC input source? It is possible to plug in every EBP into an AC input source. The more connected the faster the recharge time. It is recommended that every third EBP be connected to incoming AC utility to properly charge the batteries in a complete system.
