INSTALLATION INSTRUCTIONS Swiss Madison Drop-in Bathtub Share your pictures for a feature! using #SwissMadison www.swissmadison.com | 19 Stults Rd, Dayton, NJ 08810 | 1-434-623-4766 | info@swissmadison.
Prior to Installation: Inspect bathtub to ensure no damages have occurred while in shipping Observe all plumbing and building codes in accordance with your state and local requirements Additional floor and wall preparations may be necessary to avoid damage to the product To ensure this product is installed properly, please read all instructions before you begin Professional help is recommended All dimensions are nominal! Be sure to measure your bathtub prior to installation General Recommendations: Read in
Thank you for your purchase Thank you for purchasing a Swiss Madison Bathtub. We appreciate your business and know you will enjoy your tub for many years to come. If you have any questions or require assistance we would be happy to help, please contact us at 1-434-6234766 or info@swissmadison.com. To learn more about our products, please visit: www.swissmadison.
DROP-IN BATHTUB MODELS 48” SM-DB561 48” x 32” x 20” *Left-Hand Drain SM-DB560 60” x 30” x 20” *Right-Hand Drain 20” 20” 20” 32” 32” 32” SM-DB562 48” x 32” x 20” *Right-Hand Drain 32” 30” 30” 60” SM-DB559 60” x 30” x 20” *Left-Hand Drain 48” 20” 20” 20” 60” 60” 60” SM-DB563 60” x 32” x 20” *Left-Hand Drain SM-DB564 60” x 32” x 20” *Right-Hand Drain *COMPATIBLE DRAIN SOLD SEPARATELY, STANDARD 2” DRAIN Bathtub drains NOT sold by Swiss Madison — 3 —
DROP-IN BATHTUB MODELS SM-DB567 72” x 36” x 19.5” *Reversible Drain SM-DB566 66 “x 32” x 20” *Right-Hand Drain 22” 22” 19 ½” 36” 30” 36” SM-DB568 66” x 36” x 19.
DROP-IN BATHTUB INSTALLATION INSTRUCTIONS L H W SUGGESTED TOOLS AND MATERIALS Safety Glasses Level Utility Knife Screwdriver 30mm Screws (Zinc/Stainless; Plain/Roundhead) Tape Measure Square Drop Cloth Caulk Gun Adhesive 1 tube Sealant 1 tube Shims Phillips Bit Extension Bit Holder (for use with Phillips Bit) Pencil Drill 5mm Drill Bit 1/4” V-Notched Trowel CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE.
DROP-IN BATHTUB INSTALLATION INSTRUCTIONS WARNING: All plumbing installations must be done in accordance to legal regulations. 1. 2. 3. 4. 5. 6. Read the complete instruction manual before beginning installation. Confirm that your model will fit in intended location and plumbing fixtures are located where legally required before beginning installation. Not all drawings on this manual are drawn to scale. Please refer to the model chart. Walls and sub-floor must be solid, and square.
DROP-IN BATHTUB INSTALLATION INSTRUCTIONS 2. Position Tub Do not install the product with any air gaps under the bottom support or product damage will occur. TIP: If installation surface is not level, use leveling compound or mortar bed for proper installation. 3. Ensure Tub is Level 4. Drill and Install Plumbing Fixtures NOTE: Swiss Madison is not responsible for any damages to the tub or home during entire installation process.
DROP-IN BATHTUB INSTALLATION INSTRUCTIONS 4. Mark and Pre-Drill Screw Hole Locations 5. Finally Screw Into Place Lay mortar bed and carefully lower bathtub into predetermined location. Secure tub by screwing flange into the predrilled holes from step 4. TIP: Place drop cloth in bathtub and stand inside bathtub to press it into floor when securing to wall studs. NOTE: Swiss Madison is not responsible for any damages to the tub or home during entire installation process.
Swiss Madison ONE YEAR LIMITED WARRANTY 1-434-MADISON (623-4766) 19 Stults Rd., Dayton, NJ 08810 www.swissmadison.com Swiss Madison® products are made with quality materials and excellent craftsmanship to provide the customers a long lasting product.
