PL360/460 Cradle Quick Reference Guide
PL360/460 Cradle © 2001 - 2006 SYMBOL TECHNOLOGIES, INC. All rights reserved. Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
Quick Reference Guide Introduction The PhaserLink 360/460 cradle acts as a stand, host communication interface, and charger for the Phaser scanner. For convenience, the cradle can sit on a desktop or be mounted on a wall. The cradle receives data from the scanner via connectors in the bottom of the scanner and the top of the cradle. It then transmits that data to the host device through an attached cable. The cradle also provides power for charging the scanner battery pack (in the scanner).
PL360/460 Cradle Parts Scanner Support Tab Charging/Communication Contacts Charging LED Indicator COM 1 COM 2 Power Port Wall-mounting Socket 1 Wall-mounting Socket 2
Quick Reference Guide 5 Connecting to the Host There are three ports on the bottom of the cradle. COM 1 COM 2 Power Port COM 1 connects to the host computer; COM 2 is used for daisy-chaining multiple cradles together; and, the Power Port supplies power to the cradle. 1. Insert the independent power plug into the Power Port. (The cradle cannot be powered by the host computer.) 2. Insert the cable from the host computer into COM 1. 3. Insert the cable to the other cradles, if any, into COM 2.
PL360/460 Cradle Wall Mounting Before wall-mounting the cradle, the scanner support tab must be changed from the desk-mount position to the wall-mount position. 1 1. Lift the scanner support tab out of 2. 3. Desk Mount Wall Mount 2 4. 5. 3 the top part of the cradle and replace it in the wall-mount position as shown. Seat the cables from the bottom of the cradle in the grooves along the length of the cradle so that the bottom of the cradle is smooth and flat.
Quick Reference Guide 7 Inserting Phaser in the Cradle Place the Phaser scanner in the cradle so that the top of the scanner sits in the larger part of the cradle and the metal contacts on the bottom of the scanner touch the contacts on the cradle. Sending Data to the Host Computer To set up the PhaserLink cradle for communication between a Phaser scanner and a host computer: 1. Connect the cradle to the host computer as described in Connecting to the Host on page 5. 2.
PL360/460 Cradle Troubleshooting If the cradle does not work after following the operating instructions in this guide: • • • check the system power. check for loose cable connections. ensure the scanner is sitting properly in the cradle. Cleaning Wipe the cradle periodically with a lens tissue or other material suitable for cleaning optical material, such as eyeglasses. CAUTION Do not pour, spray or spill any liquid on the cradle.
Quick Reference Guide - 9 Reduce or eliminate vibration. Reduce or eliminate direct pressure. Provide adjustable workstations. Provide adequate clearance. Provide a suitable working environment. Improve work procedures. Vehicle or Forklift Installation Position your device within easy reach. Be able to access your device without removing your eyes from the road. Laser Devices Complies with 21CFR1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated July 26, 2001.
PL360/460 Cradle In accordance with Clause 5, IEC 825 and EN60825, the following information is provided to the user: ENGLISH CLASS 1 CLASS 2 HEBREW CLASS 1 LASER PRODUCT LASER LIGHT DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT DANISH / DANSK KLASSE 1 KLASSE 1 LASERPRODUKT KLASSE 2 LASERLYF SE IKKE IND I STRÅLEN KLASSE 2 LASERPRODUKT ITALIAN / ITALIANO CLASSE 1 PRODOTTO AL LASER DI CLASSE 1 CLASSE 2 LUCE LASER NON FISSARE IL RAGGIOPRODOTTO AL LASER DI CLASSE 2 DUTCH / NEDERLANDS KLASSE 1 KLASSE-1
Quick Reference Guide 11 indicate the recycling marks on the batteries used in sales, giveaway or promotion. Contact a qualified Taiwanese recycler for proper battery disposal. Symbol Rechargeable Batteries Symbol rechargeable battery packs are designed and constructed to the highest standards within the industry. However, there are limitations to how long a battery can operate or be stored before needing replacement.
PL360/460 Cradle Marking and European Economic Area (EEA) Statement of Compliance Symbol Technologies, Inc., hereby, declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A Declaration of Conformity may be obtained from http://www2.symbol.com/doc/. Waste Electrical and Electronic Equipment (WEEE) English: For EU Customers: All products at the end of their life must be returned to Symbol for recycling.
Quick Reference Guide 13 Magyar: Az EU-ban vásárlóknak: Minden tönkrement terméket a Symbol vállalathoz kell eljuttatni újrahasznosítás céljából. A termék visszajuttatásának módjával kapcsolatos tudnivalókért látogasson el a http://www.symbol.com/environmental_compliance weboldalra. Nederlands: Voor klanten in de EU: alle producten dienen aan het einde van hun levensduur naar Symbol te worden teruggezonden voor recycling. Raadpleeg http://www.symbol.
PL360/460 Cradle Wall Mounting Template 1 5/16” Wall Mounting Socket 1 Center Line of Cradle Use 1/8” drill bit for the screw holes.
Quick Reference Guide This page is intentionally blank.
Service Information Before you use the unit, it must be configured to operate in your facility’s network and run your applications. If you have a problem running your unit or using your equipment, contact your facility’s Technical or Systems Support.
