ÄÄ Overview of the PTC-860 The Telxon PTC-860 is a battery-powered hand-held computer used to collect, store, and transmit data. The PTC-860 automates your data collection procedures and is custom programmed to efficiently handle your organization’s unique data collection jobs. Options for scanning bar codes and printing are also available.
Through the keyboard Entering data through the keyboard is similar to operating a calculator. As you press a key on the PTC’s keyboard, the corresponding number or letter appears on the display. Pressing the ENTER key stores data in the PTC’s memory. With a bar-code reader A second method of entering data is with a bar-code reader. When you pass the reader across a bar code the PTC is programmed to read, the PTC and reader interpret the data and store it in the PTC’s memory.
Once the host computer receives the data from the PTC, it uses that data to update its master files and records. In some cases, the host computer may even transmit data back to the PTC, asking you, as the PTC’s operator, to perform a new task. © Models This manual covers the three optical models of the PTC-860: PTC-860, PTC-860ES, and PTC-860NI. These three models are similar but have the following differences: • The PTC-860 has a wand port (used to connect bar-code readers) on its side.
ÄÄ Getting started © PTC-860 optical models (PTC-860, PTC-860ES, and PTC-860NI) This manual collectively refers to all three PTC-860 optical models as PTC-860. Instances in which PTC-860 refers specifically to the PTC-860 unit will be obvious (for instance, in a comparison between models). To determine which model you have, refer to the “Models” section on page 15.
1. Remove the PTC from the box. 2. Remove all packing material from the PTC. Save the packing material in case the PTC is ever stored or shipped to Telxon for service. 3. Check the contents of the package to make sure you have received everything ordered. 4. Check the PTC and accessories for shipping damage. Pay particular attention to the PTC case, display lens, and bar-code reader, if included. If anything is missing or damaged, notify your Telxon sales representative.
FIGURE 1 Backup battery switch Interior view BATTERY COMPARTMENT BACKUP BATTERY COMPARTMENT BOTTOM OF PTC PEN OR PENCIL Interior side view PUSH DOWN PEN OR PENCIL BACKUP BATTERY SWITCH 18
5. If the AFAT battery pack or the plastic case containing batteries is in the PTC-860’s battery compartment, remove it. Refer to the “Removing the batteries” section on page 44 for the correct procedure. 6. The backup battery switch is located in a small opening just inside the battery compartment and to the right, when the PTC is facedown (see Figure 1). Insert the tip of a pen or pencil into the opening and apply direct pressure to push down the switch. Make sure the switch is pressed down completely. 7.
Equipment required: • One battery charger for each PTC • An electrical outlet within 6 feet (1.8 meters) providing 110 volts AC in the U.S. or Canada or 220 volts AC elsewhere Note: If you are charging the PTC’s battery pack outside the U.S. or Canada, you need a charger designed for use in a 220-volt AC electrical outlet. The PTC-860 can be recharged either by itself or with a Telxon microprinter attached.
4. Plug the charger into the wall outlet. The green charging indicator above the display lights. 5. Charge the PTC’s battery pack for 14 hours. © Checking the PTC-860 1. Press the ON/OFF key to turn on the PTC. 2. Look at the PTC’s display. What appears on the display depends on the program your organization uses.
ÄÄ Parts Figure 2 shows the parts of the PTC-860. © 25-pin connector On the top of the PTC is a female RS-232-type 25-pin connector for accessories and communication. A cable or the connector on the bottom of some accessories plugs into this connector to communicate with the PTC. The 25-pin connector can also be used to attach the PTC’s battery charger. The connector is between a slot, a screw, and a latch plate, which are used to hold accessories in place when they are connected directly to a PTC.
© Backup battery All models of the PTC-860 have a built-in backup battery. The backup battery provides enough power to protect data stored in the PTC’s memory when the main batteries are being changed or if they run out of power. A switch inside the PTC, accessible through the battery door, lets you turn on the backup battery. The PTC-860 is shipped from the factory with this switch turned off to conserve the backup battery power.
25-PIN CONNECTOR OPTICAL COUPLER BATTERY RECHARGE POST ELASTIC STRAP FIGURE 2 Parts of the PTC-860 DISPLAY KEYBOARD WAND PORT BATTERY COMPARTMENT 24
CAUTION! Do not use a bar-code reader with a PTC-860NI in a hazardous location. Accessories are approved for use with the PTC-860NI only in non-hazardous locations. The bar-code reader lets you enter data into your PTC by passing the reader across bar-code labels (scanning). Your PTC’s data collection program determines the types of bar-code labels you can read. © Battery charger The battery charger is used to recharge the nickel-cadmium battery pack in the PTC.
© Battery recharge posts The battery recharge posts, one on each side of the optical coupler, make contact with spring-loaded posts on an optical communication cradle and are used to recharge the PTC’s nickel-cadmium battery pack. © Display The PTC-860’s display screen shows the information you type or scan into the PTC and messages and instructions from the PTC or the host computer. The screen is a supertwist liquid crystal display (LCD).
Data keys are the letter and number keys, A-Z and 0-9. You use them to type data into the PTC. Function keys include the F1-F5, CLEAR, ENTER/YES, and SEND keys. These keys may have different labels on your PTC. They are used to perform a special procedure or function. For example, your program may use the SEND function key to transmit the PTC’s data to the host computer. ENTER/YES key How you use the ENTER/YES key depends on your organization’s data collection program.
© Keyboard overlay The keyboard overlay is a small sheet of plastic cut out to fit over the PTC’s keyboard. Labels for the special function keys used by your organization’s data collection program are printed on the overlay. © Optical coupler On the back of the PTC-860 is a small red window. Behind the window are five LEDs that the PTC can use to communicate with your host computer.
ÄÄ Features © Automatic off To conserve battery power, the PTC-860 turns itself off automatically after approximately 1 minute of inactivity. The exact length of time depends on the program. © Automatic return at on When you turn the PTC-860 off (or when the PTC-860 turns itself off), it remembers where it was in the data collection program. Then, when you turn the PTC-860 back on, it returns to that same point in the program.
© Beeper The PTC-860’s internal beeper is used by the PTC and your data collection program to warn you of problems or to prompt you to take an action. For example, if your program has temporarily turned off a key, the PTC beeps if you press it. © Clock The PTC-860’s built-in clock keeps track of the date (month, day, year, and day of the week) and the time (hours, minutes, and seconds). The clock operates continuously. How the clock is used depends on your data collection program.
ÄÄ Connecting accessories Many accessories are available for the PTC-860. These include printers, adaptors, modems, and bar-code readers. All accessories connect to the PTC-860ES and PTC-860NI through the 25-pin connector. Bar-code readers can be connected to the PTC-860 through a wand port on the unit’s side. Some accessories plug directly into the 25-pin connector on the PTC; some require a cable between the PTC and the accessory. The same general procedure is used to connect accessories and cables.
FIGURE 3 Accessory fasteners LATCH PLATE LOCKING SLOT LOCKING SCREW 3. If the accessory uses a locking latch, find the latch plate on the top of the PTC. The latch plate has a keyhole-shaped opening in it. Note which side the wider part of the opening is on. See Figure 3. Locate the sliding latch button on the bottom of the accessory; then locate the locking latch on the front of the accessory and slide it into the open position (to the left). See Figure 4. 4.
FIGURE 4 Using the accessory locking latch LOCKING LATCH 6. If you are connecting an accessory directly to the PTC, tighten the PTC’s locking screw and slide the accessory’s locking latch as far to the right as it will go to lock the accessory onto the PTC. If you are connecting a cable, connect the other end to the accessory using the same procedure. Through the wand port (PTC-860 only) 1.
© Removing an accessory From the 25-pin connector 1. Turn off the PTC-860. 2. To remove an accessory that connects directly to the PTC, slide the accessory’s locking latch as far to the left as it will go and loosen the PTC’s locking screw. 3. Pull the accessory or the cable’s connector directly away from the PTC’s 25-pin connector. Do not pull at an angle. Do not use a rocking or twisting motion when pulling the connectors apart. From the wand port (PTC-860 only) 1.
ÄÄ Scanning bar-code labels Follow this procedure if you are scanning labels with a pencil-wand bar-code reader. If you are using another type of reader, see the instructions shipped with the reader. 1. Place the tip of the bar-code reader to the left or right of the bars on the bar-code label. Make sure the reader touches the label and is within 30 degrees of vertical in any direction. 2. Draw the bar-code reader across the label with a smooth, quick motion.
ÄÄ Communicating data The PTC-860 is able to communicate with other computers and PTCs. How it communicates and how it is connected depends on your data collection program and how your PTC-860 is equipped. The PTC-860 can be set up for either one-way or two-way communication. It can communicate through its optical coupler or through its RS-232-type 25-pin connector.
Communicating through the optical coupler requires the use of an optical communication cradle. See the Guide to the CS-860 Optical Communication Station or the Guide to the MCO-860 Four-Bay Cradle for instructions. CAUTION! Do not use a PTC-860NI with a CS-860 or an MCO-860 in a hazardous location. Accessories are approved for use with the PTC-860NI only in non-hazardous locations.
6. Turn on the PTC and then turn on the device it is connected to. 7. To communicate, follow the instructions for your data collection program. Disconnecting a cable CAUTION! When removing the cable from the PTC or other device, grasp the cable connector head to remove the cable. Pulling on the cable can break the wiring from the cable connector. 1. Turn off the PTC-860. 2. Turn off the other computer or PTC. 3. Pull the cable’s connector directly away from the PTC’s 25-pin connector.
1. Perform any preparations for cloning. 2. Connect a clone cable to the 25-pin connector on the primary PTC and to the 25-pin connector on the secondary PTC. 3. Follow your application’s cloning procedure. 4. When the data or program has been cloned successfully, disconnect the clone cable from both PTCs.
ÄÄ Maintaining the PTC-860 © Operating conditions Each of the PTC-860 optical models can be operated at temperatures between –20 degrees F (–29 degrees C) and 120 degrees F (49 degrees C). PTC-860 The PTC-860 unit is designed to operate in environments that are normally free of dust, dirt, and moisture. PTC-860ES The PTC-860ES is designed to work in rugged environments. It has been specially sealed to resist dust, dirt, and moisture.
CAUTION! Do not operate a PTC-860NI with any attached accessories in a hazardous location. Accessories are approved for use with the PTC-860NI only in non-hazardous locations. © Handling the PTC-860 The following information can help to ensure you receive reliable, trouble-free service from your PTC-860. • Do not open the PTC-860’s case. Only a trained technician can service the parts inside the PTC’s case.
© Storing the PTC-860 CAUTION! Do not store a PTC-860 for over two months without charging the battery pack or replacing the alkaline batteries. Otherwise, both the primary batteries and the backup battery will drain, and any data or programs loaded into the PTC’s memory will be lost. • Do not store the PTC-860 in temperatures below –20 degrees F (–29 degrees C) or above 160 degrees F (71 degrees C). • Do not store the PTC-860 in a damp or humid environment. 1.
Do not use a paper towel on any part of the PTC-860, including the display. If the PTC-860 becomes extremely dirty or if liquids, dirt, or other foreign materials get inside the case, contact your Telxon service representative. © Servicing the PTC-860 Do not attempt to service the PTC. Only a trained Telxon technician may service the PTC.
ÄÄ Replacing the batteries The PTC-860’s AFAT nickel-cadmium battery pack or AA alkaline batteries may be replaced when necessary. CAUTION! Do not remove or install a PTC-860NI’s battery pack in a hazardous location. These procedures are approved for use with the PTC-860NI only in non-hazardous locations. Note: Once you remove the PTC’s batteries, the backup battery, if used continuously, will protect stored programs and data for up to twenty days.
5. Lay the battery door facedown on your work surface. The gasket on the inside of the door should be facing up. CAUTION! Keep the gasket and the inside of the battery door clean and free of dust and dirt. Dust or dirt on the gasket could keep it from sealing properly. 6. Pick up the PTC. 7. Hold your free hand near the bottom of the PTC and tilt the unit so the nickel-cadmium battery pack or battery case with AA alkaline batteries slides out into your hand.
3. Make sure the + sign on the battery pack is on the same side as the + sign on the PTC and the straight edge of the battery pack is facing up (see Figure 5); then insert the battery pack directly into the bottom of the PTC. The battery pack has a spacer to prevent it from being inserted incorrectly. 4. Pick up the battery door and look at the gasket on the inside. Make sure the gasket is clean of dust and dirt. If necessary, wipe it with a soft cloth. 5.
FIGURE 6 Inserting AA alkaline batteries into the plastic battery case 3. Hold the battery case in one hand with the opening up and the polarity marks facing you. 4. Insert the battery case, open end first, into the battery compartment. CAUTION! Do not force the battery case into the battery compartment. A raised tab on the left side of the battery case prevents the case from being inserted incorrectly. 5. Pick up the battery door and look at the gasket on the inside.
Backup battery Under average conditions, the backup battery will last a number of years. When the backup battery fails, a warning message displays on the PTC’s screen. Because the backup battery is attached to one of the internal circuit boards, it can be replaced only by a trained Telxon service engineer. Send the PTC to a Telxon service depot to have the backup battery replaced.
ÄÄ Troubleshooting © The PTC does not turn on • Charge or replace the nickel-cadmium battery pack or replace the alkaline batteries. © The bar-code reader fails to read a label • Try scanning across the top or bottom of the bars on the label. • Make sure the bar-code reader is connected securely to the PTC. • Wipe off the bar-code label. • Wipe off the tip of the bar-code reader. © The PTC shows a “Backup Battery Fault” message when you turn it on • Turn on the backup battery.
ÄÄ A ppendix A © Specifications Electrical Data communications via 25-pin connector: Power: Full duplex, 300 to 19.
Weight: (w/ AFAT battery pack) (w/ AA batteries) 25.5 oz/.7 kg 24 oz/.
ÄÄ A ppendix B © Hardware part numbers The following table contains part numbers for ordering accessory hardware for the PTC-860 optical models.
Item Printers IP-24 Microprinter MP-830 Microprinter 24-column version 24-column version kit 42-column version 42-column version kit RM-80 Printer Part number 16603-102 16489-000 16489-700 16489-003 16489-703 16406-004 Adaptors BCM-6 TBM-160 12664-001 10854-001 Modems TCM-100 TCM-212R TCM-224** 10095-202 11231-100 14580-00X Cradles CS-860 Optical Communication Station w/o mounting hardware w/ table mount hardware w/ wall mount hardware MCO-860 Four-Bay Cradle w/o a modem w/ a 202 modem w/ a 212/224 mo
Item Cables PTC-to-IBM PC/AT cable*** PTC-to-IBM PC/XT cable**** Clone cable PTC-to-1/2 duplex modem cable*** PTC-to-full duplex modem cable*** PTC-to-host (DTE) cable*** Manuals Guide to the FLASH Utilities (TCAL or MS-DOS Version) Guide to Maintaining NiCd Batteries Guide to the PTC-860 Fast Battery Charger Guide to the CS-860 Optical Communication Station Guide to the MCO-860 Four-Bay Cradle Part number 13656-3X0 10582-XX0 09944-001 10124-0X1 10124-0X2 10124-0X3 16541-000 16488-000 16014-000 15124-000
ÄÄ A ppendix C © Communication connections Figures 7 through 12 provide information on the connections used to establish and maintain communication between the PTC-860 and other devices.
FIGURE 8 PTC-to-IBM PC/XT cable, P/N 10582-XX0 IBM PC/XT Female (000)/ Male (110) PTC-860 Male TXD 2 3 RXD RXD 3 2 TXD RTS 4 6 DSR CTS 5 20 DTR DSR 6 4 RTS GND 7 7 GND DTR 20 5 CTS –5 10 OUT 11 56
FIGURE 9 Clone cable, P/N 09944-001 PTC-860 A PTC-860 B DTR 20 20 DTR DSR 6 6 DSR RTS 4 4 RTS CTS 5 5 CTS TXD 2 3 RXD RXD 3 2 TXD OUT– 11 11 OUT– BAT– 7 7 BAT– GND 1 1 GND 57
FIGURE 10 PTC-to-1/2 duplex modem cable, P/N 10124-0X1 MOD 202/Type I (1/2 Duplex) PTC-860 TXD 2 2 TXD RCV 3 3 RCV DSR 6 6 DSR DTR 20 20 DTR RTS 4 4 RTS CTS 5 5 CTS RI 22 22 RI CD 8 8 CD SG 7 7 SG –5 10 OUT 11 58
FIGURE 11 PTC-to-full duplex modem cable, P/N 10124-0X2 MOD 212/Type II (Full Duplex) PTC-860 TXD 2 2 TXD RCV 3 3 RCV DTR 20 20 DTR DSR 6 6 DSR RI 22 22 RI CD 8 8 CD SG 7 7 SG RTS 4 CTS 5 –5 10 OUT 11 59
FIGURE 12 PTC-to-host (DTE) cable, P/N 10124-0X3 Host/Type III (Full or 1/2 Duplex) PTC-860 RXD 3 2 TXD TXD 2 3 RXD DTR 20 6 DSR DSR 6 20 DTR RTS 4 CTS 5 8 CD 4 RTS CD 8 5 CTS SG 7 7 SG OUT 11 –5 10 60
ÄÄ Glossary alphanumeric Describes a character set that contains letters, numbers, and symbols such as punctuation marks. application A PTC program that is designed to perform a specific task for the user. Examples include route accounting, payroll, price lookup, shipping, and inventory control. application flash EPROM An electronic component soldered into a PTC that contains the unit’s data collection program. It can be erased and reprogrammed while in the PTC.
display The LCD screen on the front of the PTC. It shows data entered into the PTC and warning prompts. DSR Data set ready signal. The modem sends DSR to the attached device to indicate that the modem is connected, on, and ready. DTE Data terminal equipment. A device comprising the data source. For example, the host computer. DTR Data terminal ready signal. The signal sent by the terminal device to the modem to indicate that the terminal is ready for transmission.
optical coupler A device that converts electronic signals inside the PTC into pulses of light that can be detected by an optical communication station. prompt Messages shown by the PTC that guide the operator through the steps of a data collection program. Prompts vary for different programs. PTC Portable Tele-Transaction Computer. A battery-powered, hand-held, programmable device used to collect, store, and transmit data. RAM Random access memory.
ÄÄ Index 25-pin connector, 22 communicating data, 37-38 connecting an accessory, 31-33 removing an accessory, 34 A Accessories, 15, 41 connecting, 31-33 removing, 34 used with PTC-860NI, 15 Accessory fasteners latch plate, 22, 31-34 locking screw, 22, 31-34 slot, 22, 31-32 Adaptors, 31 part numbers, 53 Alkaline batteries, 15, 25, 50 inserting, 46-47 removing, 44-45 when weak, 19, 25, 30 Application flash EPROM, 22 Automatic off, 29 Automatic return at on, 29 B Backlight, 29 Backup battery, 23, 44 replac
inserting the battery case, 47 joining connectors, 20, 32, 37 keeping battery door clean, 45 PTC-860ES accessories, 40 reprogramming a PTC-860NI’s flash EPROM, 22 storing a PTC-860, 23, 25, 42 using a bar-code reader with a PTC-860NI, 25 using a PTC-860NI with a cradle, 37 Charging the nickel-cadmium battery pack, 19-25 Charging time, 21, 25 Cleaning the PTC-860, 42-43 Clock, 30 Clone cable, 39, 54, 57 Cloning, 14, 38-39 Communicating data, 14-15, 36-39 Communication connections, 55-60 Cradles, 20, 26, 28,
M P Maintaining the PTC-860, 40-43 Manuals part numbers, 54 MCO-860, 20, 36-37 part numbers, 53 Memory, 30 Messages, 13 backup battery, 21, 48, 49 low battery, 21, 25 Models of PTC-860s, 15, 16 Modems, 14, 31, 36 part numbers, 53 Packing material saving, 17 using, 42 Parts, 22-28 Physical specifications, 50-51 Power backup system, 30 Printers, 20, 31 part numbers, 53 Prompts, 13 PTC-860 checking, 21 cleaning, 42-43 compared to other models, 15 dimensions, 50 entering data, 13-14 failure to turn on, 49 fe
R W RS-232 connector, 28, 36 Wand port, 23, 28, 31 connecting a bar-code reader, 33 disconnecting a bar-code reader, 34 Warnings, 21, 48 PTC-860NI, 10 S Safety information, 9-12 disposing of battery packs, 12 PTC-860NI, 9-12 Scanning, 25, 35 failures, 35, 49 Screwdriver, 28 Servicing the PTC-860, 43 Shipping damage, 17 Specifications electrical, 50 environmental, 50 physical, 50-51 Storage temperature, 42, 50 Storing the PTC-860, 42 T Temperatures operating, 40, 50 storage, 42, 50 Troubleshooting, 49 b
