4503-TRM, 4505-TRM, 4506-TRM

Canterbury

™

Trim Series

Operation & Maintenance Manual

Model Numbers Speciﬁcations

4503-TRM Valve Trim with Hand Shower

4505-TRM Shower Trim with Hand Shower

4506-TRM Tub/Shower with Hand

Shower Trim

Tub/shower trim with hand shower and lever handle

includes wall connection, cradle for hand shower

mounting, in-line vacuum breaker, exible metal hose,

non-diverter tub spout (069), 3 mode hand shower (442W)

and 1 mode showerhead (4-163) with standard 2.5 gpm

(9.5 L/min) ow restrictor. Shower trim with hand shower

and lever handle includes all of the above less non-

diverter tub spout. Valve trim with hand shower and lever

handle includes all of the above less non-diverter tub

spout and 1 mode showerhead. Components made from

metal and plastic materials plated in standard polished

chrome nish.

Modiﬁcations Warranty

-1.5 1.5 gpm (5.7 L/min) ﬂow restrictor

-2.0 2.0 gpm (7.6 L/min) ﬂow restrictor

-442HSB 30" slide bar in place of wall cradle on

hand shower units

-STN Satin nickel ﬁnish

Limited Lifetime - to the original end purchaser in

consumer installations.

5 Years - for commercial installations.

Refer to www.symmons.com/warranty for complete

warranty information.

Note: Append appropriate -sufx to model number.

Summary of content (6 pages)

PAGE 1
4503-TRM, 4505-TRM, 4506-TRM Canterbury™ Trim Series Operation & Maintenance Manual Model Numbers Specifications 4503-TRM Valve Trim with Hand Shower 4505-TRM Shower Trim with Hand Shower 4506-TRM Tub/Shower with Hand Shower Trim Modifications Warranty -1.5 1.5 gpm (5.7 L/min) flow restrictor -2.0 2.0 gpm (7.
PAGE 2
Dimensions Measurements B A G C D F J E I H N O M L K R P Q S Floor A Ø 2 1/4", 57 mm B 8 5/8", 219 mm C 2 1/8", 54 mm D 6", 152 mm right or left E 5", 127 mm F 77", 1956 mm G Male 1/2" NPT thread must be recessed 1/4" from finished wall H 7 1/2", 191 mm I 10", 25 mm J 4 3/4", 121 mm K Ø 2 5/8", 67 mm L 32", 813 mm (4506-TRM) 45", 1143 mm (4503-TRM, 4505-TRM) M 12", 305 mm N 3", 76 mm O 3", 76 mm P 1/2" NPT Q 1/2", 13 mm R (Rough-in) 2 3/8" ± 1/2", 60 mm ± 1
PAGE 3
Parts Breakdown Replacement Parts E D B Q O A C P L M N H F G S K J I M H F J G K R I T Item Description Part Number B Wall Elbow EF-105 C Showerhead 4-163 D E Shower Arm Flange 300 F G H I Set Screw Plug Button Handle Star Washer T-226 J K Lock Nut Dome Cover T-19/20-PL L M N Diverter Excutcheon Mounting Screws Mounting Plate T-531 O P Q Wall Cradle Cradle Mounting Screws Cradle Mounting Plate EF-106 M R Mounting Screws Shower Escutcheon T-225 S Hand Shower 44
PAGE 4
Installation Note: For valve body installation, please see valve body installation guides. 4) Install dome covers (K) to valves and secure with lock nuts (J). 1 1) Install shower escutcheon (R) to shower valve. Secure with two screws (M). 6) I nstall tub spout (T) to pipe fitting. Turn clockwise to secure. K 1 T 2 R 1 J M 7) Install wall elbow (B) to stub out pipe. Tighten Allen screw (3 mm) to secure. K 1 2 J 1 2 B 2) Attach mounting plate (N) to diverter valve (4505 and 4506 only).
PAGE 5
Installation Option: Place cradle mounting plate (Q) in position, mark and drill 3/16" holes into wall. Install anchors. 10) Attach shower arm (D) and flange (E) to vertical shower pipe turning clockwise to tighten. 1 1 Q 2 E 12) Attach large end of hand shower hose (U) to hand shower (S). Attach small end of hand shower hose (U) and gasket to in-line vacuum breaker (A). Connect in-line vacuum breaker to wall elbow (B). Turn clockwise to tighten.
PAGE 6
Operation Temperature Control Diverter Control 1) Turn shower handle counterclockwise approximately 1/4 turn to put valve in cold position. 1) Diverter handle facing straight down is for diverter function 1. 2) Turn shower handle counterclockwise approximately 1/2 turn to put valve in warm position. 2) 4 503-TRM & 4505-TRM: Turn diverter handle counterclockwise one full revolution for diverter function 2. 4506-TRM: Turn diverter handle counterclockwise 1/4 turn for diverter function 2.
