User Manual

Technical Specications
Hardware
CPU Frequency Quad Core™ 3.3GHz
Hardware Encryption Engine Yes (AES-NI)
Memory 8GB ECC RAM (expandable, up to 32GB)
Internal HDD/SSD 3.5" or 2.5" SATA/SAS 6 Gb/s X 10 (hard drives not included)
Max Internal Capacity
40TB (10 X 4TB HDD) (the actual capacity will differ according to volume types)
External Storage Interface USB 2.0 X 4, SAS expansion port X 2
Size (HxWxD) (mm) 88 X 445 X 570
Weight 15.685 Kg
LAN Gigabit X 4 (optional 10GbE X 2 addon card is supported)
Wake on LAN/WAN Yes
Wireless Support Yes
Noise Level 54.6 dBA
AC Input Power Voltage 100V to 240V AC
Power Frequency 50 / 60Hz, Single Phase
Operating Temperature 5°C to 35°C (40°F to 95°F)
Storage Temperature -10°C to 70°C (15°F to 155°F)
Relative Humidity 5% to 95% RH
Power Consumption
4
Access: 142W, HDD Hibernation: 110W
Applications
File Station Virtual Drive, Remote Folder
Backup Solutions
Network Backup, Local Backup, Desktop Backup (Window: Synology Data Replicator; Mac
®
: Apple
®
Time Machine
®
backup application); Shared Folder Sync - Max Task Number : 32, Conguration Backup
Mail Server Supported Mail Server Protocols: POP3, SMTP, IMAP
FTP Server Bandwidth Control, Custom FTP Passive Port Range, Anonymous FTP, Transfer Log
Web Station Virtual Host (up to 30 websites), PHP/MySQL
®
, 3rd-Party Applications Support
Printer Server
Max Printer #: 2, Printing Protocols: LPR, CIFS, IPP, Apple AirPrint™, Google Cloud Print™, Multi Functional
Print Server (MFP functions are for Windows PC only)
iOS/Android™ Applications DS photo+, DS audio, DS cam, DS le, DS nder
Windows Phone Applications DS nder, DS photo+, DS audio
Connections & Buttons
LAN Ports
LED indicators Power Ports RESETUSB 2.0 Ports
HDD Tray Fans Expansion Ports
Escape
Enter
Power Button LCM Display
SSD Tray (internal)
Up/Down
