User Manual

Add-on Packages
Surveillance Station
Default IP cam #: 1, MAX IP cam # (licenses required): 70 (with 10 GbE add-on card. One free license
to install one IP camera. Additional licenses can be purchased to expand the license quota.)
Directory Server LDAP Directory Server, Backup and Restore LDAP Database
VPN Server Maximum Connections : 30, VPN Method: PPTP, OpenVPN™
DHCP Server
Independent DHCP Server on Different Network Interfaces, Multiple Subnets Support, Address
Reservation
Syslog Server SSL Connection, Log Rotation, Email Notication
Mail Station
Webmail Interface for Mail Server, Receiving Mails from Multiple POP3 Mailboxes, Customizable SMTP
Server
Antivirus Essential Full System Scan, Scheduled Scan, White List Customization, Virus Denition Auto Update
Time Backup Maximum Task Number : 16, Multiple File Versions Retained, Instant File Restoration
Cloud Station Maximum User Accounts : 64, Retain Historical and Deleted File Versions
DLNA
®
/UPnP
®
Media Server DLNA certied, PS3
®
/Xbox 360
®
Support
Download Station Supported Download Protocols: BT/HTTP/FTP/NZB/eMule Maximum Concurrent Download Tasks : 80
Other Packages Photo Station, Audio Station, iTunes
®
Server, 3rd-party packages
General
Networking Protocols CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN)
File System EXT4, EXT3 (External Disk Only), FAT (External Disk Only), NTFS (External Disk Only)
Storage Management
Max File System Size: 108TB, Max Internal Volume #: 1024, Max iSCSI Target #: 128, Max iSCSI LUN#:
512, Supported RAID Type : Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, Global Hot Spare
Supported RAID Type: RAID 1, RAID 5, RAID 6, RAID 10, Synology Expansion Unit Support: RX1213sas
File Sharing Capability
Max User Account: 4096, Max Group: 512, Max Shared Folder: 512, Max Concurrent CIFS/AFP/FTP
Connections : 1024
Privilege
Windows Access Control List (ACL)
Virtualization VMware vSphere 5, Microsoft
®
Hyper-V, Citrix Ready
Directory Service Windows AD Integration: Domain Users login via Samba (CIFS)/AFP/FTP/File Station, LDAP Integration
Security FTP over SSL/TLS, IP Auto-Block, Firewall, Encrypted Network Backup over Rsync, HTTPS Connection
Utilities Synology Assistant, Synology Data Replicator 3
Supported Clients
Windows XP onward, Mac OS X
®
10.5 onward, Ubuntu 9.04 onward
Supported Browsers Chrome, Internet Explorer
®
: 8, 9, Firefox
®
, Safari
®
(Mac): 5
Language
English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svensk, Nederlands, Русский, Polski, Magyar,
Português do Brasil, Português Europeu, Türkçe, Český,
Environment and Packaging
Environment RoHS Compliant
Package Content RS10613xs+ Main Unit, Installation Disc, Welcome Note, Assembling Kit, AC Power Cord X 2
Optional Accessories Remote, Camera License Pack, Rail Kit, 4GB ECC RAM Module, Expansion Unit (RX1213sas X 8)
Warranty 3 years
*Model specications are subject to change without notice. Please refer to www.synology.com for the latest information.
1. Tested with dual 10 GbE connections using Link Aggregation and fully loaded with Kingston SVP100S2 64GB 2.5” SSD. Performance may vary depending on the environment.
2. Available with DSM 4.1 or newer.
3. RS10613xs+ supports up to eight Synology RX1213sas, purchased separately.
4. Fully loaded with Western Digital
®
2TB WD2002FYPS hard drives. The gures could vary on different environments.
