sWiFi/all User Manual 5. Console Setting

4. HOW TO CONNECT

This chapter provides information necessary for sWiFi/all to connect and operate with the desired serial

devices, such as wireless LAN and serial connection.

Procedure for connecting sWiFi/all to devices and networks is as follows.

4.1 Power Supply

Check that the input voltage supplied to sWiFi/all matches the model’s specification and supply the

voltage. sWiFi/all starts booting with power on only when power is normally supplied.

There are RDY, SRL/LINK LEDs for checking the status of operating status. Please refer to chapter 3 for

information on the status of the LEDs.

4.2 Connection

With PC and serial port connected and terminal running (9,600bps, 8bit, 1stop, no-parity), you can set

up sWiFi/all by running a dedicated utility of sWiFi/all. Please refer to the next chapter for set ups.
