User's Manual Part 1

seconds to turn on the intelligent battery. The battery power indicator will be solid red and the battery level

indicator will indicate current battery capacity level after power on.

Powering off: When the battery is powered on, press the battery power button once and then press and hold for 2

seconds to turn off the intelligent battery. The LED indicators all go out after power off.

Checking the battery level

When the battery is powered off; pressing the battery power button once will indicate the current battery level.

Refer to the table below for details.

The battery level indicators will show the current battery level during both the charging and

discharging process as well as battery life. The indicators are defined below.

: The LED is solid on : The LED will blink regularly

: The LED is light off

Battery level during discharging process

LED1

LED2

LED3

LED4

Current battery level

87.5%~100%

75%~87.5%

62.5%~75%

50%~62.5%

37.5%~50%

25%~37.5%

12.5%~25%

0%~12.5%

<0%

Checking the battery life

When the battery is powered off;press and hold the battery power button for 5 seconds to check the battery life.

The battery level indicators will show the life and the battery power indicator will blink for 10 seconds, then all

LEDs will light out andthe intelligent battery will turn off.

Battery life

LED1

LED2

LED3

LED4

Current battery life

90%~100%

80%~90%

70%~80%

60%~70%

50%~60%
