Specification Sheet

Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
Sheet:
Travelers Rest, SC 29690
10/05/09
JRM
002840-40CV
Big-Flo Base Faucet w/ Intergral Check Valve Assembly
2 Saddleback Cove / P.O. Box 1088
2
1:4
of
1
DMH
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
JHB
Approved
Date:
Architect/Engineer_________________________________
Checked
Drawn
This Space for Architect/Engineer Approval
Job Name
__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Color Coded Indexes
4 Arm Handles w/
Adjustable From
7 3/4" to 8 1/4"
[197mm to 210mm]
8" c/c
[203mm]
2"
51mm
3/4" NPT
Female Inlets
Integral Check Valves
in Faucet Body
2 1/2"
64mm
