Specification Sheet

Surface
Mounting
1/2" NPT Male Inlet
Lock Nut &
Lock Washer
Washer
Maximum
5mm
Thickness
1 3/16"
29mm
53mm
2 1/8"
3/16"
1 5/16"
33mm
Hex
Chrome Plated Brass
1
of
1
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
08/29/12
DHL
00CC
Sheet:
1/2" NPT Male Inlet Faucet Flange
2 Saddleback Cove / P.O. Box 1088
Travelers Rest, SC 29690
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
JHB
DMH
Approved
Drawn
Checked
Date:
1:1
Architect/Engineer_________________________________
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
