Specification Sheet

3 1/8"
80mm
2 1/8"
54mm
Flange w/ Integral Stop Assembly, Polished Chrome, 1/2" NPT Female Inlet
1:2
Product Specifications:
Scale:
T&S BRASS AND BRONZE WORKS, INC.
01/18/16JRM
00JJ
Item No.
2 Saddleback Cove / P.O. Box 1088
Drawn:
of
1Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
JHB
JBC
Approved:
Travelers Rest, SC 29690
Model No.
2
Checked: Date:
This Space for Architect/Engineer Approval
Job Name
__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
Product Compliance:
ASME A112.18.1 / CSA B125.1
NSF 61 - Section 9
NSF 372 (Low Lead Content)
Female
Inlet
1/2" NPT
Screwdriver
Stop w/ Cap
2 1/2"
64mm
2"
51mm
