Specification Sheet

Washer
(Included)
1/2" NPT
Female Inlet
1 15/16"
48mm
Screwdriver Stop
Ø 2"
[51mm]
2 1/2"
64mm
3 9/16"
90mm
of
1
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
10/04/13
DMH
00XX
1
2 Saddleback Cove / P.O. Box 1088
1/2" NPT Female Flange Adjustable Inlet w/ Screwdriver Stop
Travelers Rest, SC 29690
Date:
(Chrome Finish)
Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
JHB
KJG
Approved
Drawn
1:2
Architect/Engineer_________________________________
Checked
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
