Specification Sheet

Note:
1. Material: Aluminum
Sheet:
1
of
1
Product Specifications:
Scale:
Model No.
Item No.
T&S BRASS AND BRONZE WORKS, INC.
Travelers Rest, SC 29690
REG. #A2601
ISO #9001
05/26/09
GEF
017670-45
www.tsbrass.com
JHB
KJG
Approved
Drawn Checked
1:1
Waste Drain Installation Tool
Travelers Rest, SC: 800-476-4103 Simi Valley, CA: 800-423-0150
Fax: [phone]
2 Saddleback Cove / P.O. Box 1088
Date:
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
1/4"
[6mm]
2 1/2"
3 1/8"
2 3/4"
[64mm]
[79mm]
[70mm]
[95mm]
3 3/4"
9/16"
[14mm]
