Specification Sheet

Sensor Cable
Water Resistant
25mm][610mm
Sensor Cable
Connection on
Cable Connector
Control Module
Attaches to Faucet
24"
1"
Flat Lens w/ Scratch
Resistant Coating
and Sensor
Housing Assembly
Accessories
by
Phone: [phone] Fax: [phone]
of
Checked:
1Sheet:
JBC
Approved:
Drawn:
JHB
Travelers Rest, South Carolina 29690
1:1
Model Number
1
Flat Lens and Sensor Wire Assembly
Product Specifications:
5EF-0003
Product Compliance:
equip.tsbrass.com
Equip and ChekPoint Electronic Faucet:
Scale:JRM Date:
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
2 Saddleback Cove, P.O. Box 1088
equip
Foodservice
04/23/16
