Specification Sheet

8 3/16"
208mm
72mm
2 13/16"
11 7/8"
302mm
8"
203mm
w/ Laminar Flow Device
3" equip Rigid Gooseneck
5SP-03
Quarter-Turn
equip Lever Handles
Ceramic Cartridges &
w/ Color Coded Screws
Mounting Surface
Female Inlets
Ø 2" [51mm]
Flanges w/
1/2" NPT
Adjustable From
7 3/4" to 8 1/4"
[197mm to 210mm]
B-0425-M
Supply Nipple Kit
(Sold Separately)
ASME A112.18.1 / CSA B125.1
JHB
Product Specifications:
8" Deck Mount Mixing Faucet w/ Quarter-Turn Ceramic Cartridges,
Sheet:
NSF 372 (Low Lead Content)
1:5 2
of
1
Female Inlets
Architect/Engineer_________________________________
equip Lever Handles, 3" equip Rigid Gooseneck & 1/2" NPT
ANSI A117.1 (ADA)
NSF 61 - Section 9
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Travelers Rest, South Carolina 29690
Phone: [phone] Fax: [phone]
equip.tsbrass.com
Model Number
2 Saddleback Cove, P.O. Box 1088
Scale:JRM Date:Checked:
Drawn:
Approved:JBC
5F-8DLX03
by
Accessories
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Product Compliance:
equip
Foodservice
10/24/16
11 3/4"
298mm
