Specification Sheet

ManualsBrandsT and S Brass ManualsfaucetsT and S Brass 8"W Deck Mounted Utility Faucet with 12" Swing Nozzle - Includes Wrist Blade Handles

12 1/8"

308mm

6 3/16"

157mm

16"

407mm

203mm

4 5/8"

117mm

B-0425-M

(Included)

Supply Nipple Kit

Rough-In Requirement:

(2)

1" [25mm] Mounting Holes

8 5/8"

219mm

DHL

Checked

Product Specifications:

Scale

12/09/135F-8DWS12

Date

& 1/2" NPT Supply Nipple Kit

Phone: 800.891.4808 Fax: 800.868.0084

2 Saddleback Cove, P.O. Box 1088

Contractor_______________________________________

Customer/Wholesaler______________________________

Model Specified_____________________ Quantity______

Model Number

Travelers Rest, South Carolina 29690

Architect/Engineer_________________________________

Drawn

Approved

JHB

1:5

This Space for Architect/Engineer Approval

Job Name__________________________Date_________

equip Foodservice Accessories

8" Deck Mount Mixing Faucet w/ Ceramic Cartridges,

equip 4" Wrist Action Handles, 12" equip Swing Nozzle

DMH

7 3/4" to 8 1/4"

[197mm to 210mm]

equip 4" Wrist Action Handles

Flanges w/

Female Inlets

w/ Color Coded Screws

Ceramic Cartridges &

Ø 2" [51mm]

1/2" NPT

Mounting Surface

Adjustable from

5SP-12

12" equip Swing Nozzle

w/ Laminar Flow Device.

Rigid Conversion Requires

014200-45 Lock Washer

(Sold Separately)
